煤层底板分阶段疏水降压水害防控方法

doi:10.16265/j.cnki.issn1003-3033.2022.S1.0609

中国安全科学学报 ›› 2022, Vol. 32 ›› Issue (S1): 145-151.doi: 10.16265/j.cnki.issn1003-3033.2022.S1.0609

煤层底板分阶段疏水降压水害防控方法

马莲净¹(), 赵宝峰²^,³^,^**(), 吕玉广⁴^,⁵

¹ 西安建筑科技大学资源工程学院, 陕西西安 710055
² 中煤科工集团西安研究院有限公司,陕西西安 710054
³ 陕西省煤矿水害防治技术重点实验室, 陕西西安 710177
⁴ 中国矿业大学资源与地球科学学院, 江苏徐州 221116
⁵ 内蒙古上海庙矿业有限责任公司, 内蒙古鄂尔多斯 016299

收稿日期:2022-01-06 修回日期:2022-04-16 出版日期:2022-06-30 发布日期:2022-12-30
通讯作者: 赵宝峰
作者简介:
马莲净 (1986—),女,河北衡水人,博士,高级工程师,主要从事矿山安全与环保方面的研究。E-mail: 860909mlj@163.com。
吕玉广研究员
基金资助:
国家重点研发计划项目(2016YFC0501104); 国家自然科学基金资助(41807221)

Water disaster prevention and control method of coal floor of stepwise water drainage and depressurization

MA Lianjing¹(), ZHAO Baofeng²^,³^,^**(), LYU Yuguang⁴^,⁵

¹ School of Resources Engineering, Xi'an University of Architecture and Technology, Xi'an Shaanxi 710055, China
² Xi'an Research Institute of China Coal Technology & Engineering Group Corp,Xi'an Shaanxi 710054,China
³ Shaanxi Key Laboratory of Coal Mine Water Disaster Prevention and Control Technology,Xi'an Shaanxi 710177,China
⁴ School of Resources and Geosciences, China University of Mining and Technology, Xuzhou Jiangsu 221116, China
⁵ Inner Mongolia Shanghai Temple Mining Co. Ltd., Ordos Inner Mongolia 016299, China

Received:2022-01-06 Revised:2022-04-16 Online:2022-06-30 Published:2022-12-30
Contact: ZHAO Baofeng

摘要/Abstract

摘要：

为有效防控侏罗纪煤田深部煤层底板高承压含水层砂岩水害,基于井田单斜构造特征,利用放水试验与地下水流数值模型,构建一种煤层底板高承压砂岩含水层分阶段疏水降压的水害防控方法。结果表明:煤层底板高承压砂岩含水层采用分阶段疏水降压水害防控方法,可有效避免疏放水钻孔揭露高承压含水层,将含水层水位疏降至安全水位以下,达到理想的水害防控效果。利用单孔和多孔放水试验数据识别和校验地下水流数值模型,并定量预测疏放水量、疏放时间和总疏放水量,可实现煤层底板高承压含水层砂岩水害的精准防控。

关键词: 煤层底板, 分阶段疏水降压, 水害防控, 承压含水层, 突水系数

Abstract:

In order to effectively prevent and control the water disaster from the high confined aquifer below the deep coal floor seam of Jurassic coalfield, based on the inclined structure characteristics of the coalfield, by the dewatering test and numerical model of groundwater flow, a kind of water disaster prevention and control thought for high confined sandstone aquifer below the coal seam was constructed. The research shows that the water disaster prevention and control method of coal floor of stepwise water drainage and depressurization can effectively avoid exposing high confined aquifer by drainage borehole, and reduce the water level of the aquifer to below the safe water level, thus achieving the ideal effect of water disaster prevention and control. The numerical model of groundwater was identified and verified by single and multiple boreholes dewatering test data, and drainage amount, drainage time and total drainage amount of water discharged were predicted quantitatively, so as to realize the precise prevention and control of water disaster from high confined aquifer sandstone aquifer below the coal seam.

Key words: coal floor, stepwise water drainage and depressurization, water disaster prevention and control, confined aquifer, water inrush coefficient

马莲净, 赵宝峰, 吕玉广. 煤层底板分阶段疏水降压水害防控方法[J]. 中国安全科学学报, 2022, 32(S1): 145-151.

MA Lianjing, ZHAO Baofeng, LYU Yuguang. Water disaster prevention and control method of coal floor of stepwise water drainage and depressurization[J]. China Safety Science Journal, 2022, 32(S1): 145-151.

图/表 11

表1

图1

图2

表2

图3

图4

图5

图6

表3

图7

表4

参考文献 18

[1]	赵琳琳, 温国锋, 邵良杉. 煤层底板突水危险性GSPCA-LSSVM评价模型[J]. 中国安全科学学报, 2018, 28(2): 128-133. doi: 10.16265/j.cnki.issn1003-3033.2018.02.022
	ZHAO Linlin, WEN Guofeng, SHAO Liangshan. GSPCA-LSSVM model for evaluating risk of coal floor groundwater bursting[J]. China Safety Science Journal, 2018, 28(2): 128-133. doi: 10.16265/j.cnki.issn1003-3033.2018.02.022
[2]	郑文红, 陈广阳, 罗浩, 等. 矿井底板突水过程电荷感应规律试验研究[J]. 中国安全科学学报, 2017, 27(10): 105-110. doi: 10.16265/j.cnki.issn1003-3033.2017.10.018
	ZHENG Wenhong, CHEN Guangyang, LUO Hao, et al. Experimental study on charge induction law of water inrush in mine floor[J]. China Safety Science Journal, 2017, 27(10): 105-110. doi: 10.16265/j.cnki.issn1003-3033.2017.10.018
[3]	秋兴国, 王超. 时序变化率曲面拟合的矿井水害极值预警算法[J]. 中国安全科学学报, 2012, 22(10): 19-23.
	QIU Xingguo, WANG Chao. Mine flood extreme warning algorithm based on temporal variation curved surface fitting[J]. China Safety Science Journal, 2012, 22(10): 19-23.
[4]	武强, 徐华, 赵颖旺, 等. 基于“三图法”煤层顶板突水动态可视化预测[J]. 煤炭学报, 2016, 41(12): 2 968-2 974.
	WU Qiang, XU Hua, ZHAO Yingwang, et al. Dynamic visualization and prediction for water bursting on coal roof on ″three maps method″[J]. Journal of China Coal Society, 2016, 41(12): 2 968-2 974.
[5]	王道坤, 崔亚利, 易德礼. 地面定向钻探技术在煤层底板高承压含水层改造中的应用[J]. 煤田地质与勘探, 2019, 47(增1): 32-36.
	WANG Daokun, CUI Yali, YI Deli. Application of surface directional drilling technology in reforming the confined aquifer with high pressure in coal seam floor[J]. Coal Geology & Exploration, 2019, 47(S1): 32-36.
[6]	HU Weiyue, ZHAO Chunhu. Evolution of water hazard control technology in China's coal mines[J]. Mine Water and the Environment, 2021, 40(2): 334-344. doi: 10.1007/s10230-020-00744-0
[7]	许延春, 张二蒙, 赵霖, 等. 黏度对浆液在裂隙岩体中扩散与充填规律的影响[J]. 矿业科学学报, 2021, 6(1): 71-81.
	XU Yanchun, ZHANG Ermeng, ZHAO Lin, et al. Study on the law of influence by slurry viscosity on the fractured aquifer grouting and diffusion[J]. Journal of Mining Science and Technology, 2021, 6(1): 71-81.
[8]	李涛, 高颖, 艾德春, 等. 基于承压水单孔放水实验的底板水害精准注浆防控[J]. 煤炭学报, 2019, 44(8): 2 494-2 501.
	LI Tao, GAO Ying, AI Dechun, et al. Floor precise grouting of prevention and control of water based on confined water single-hole drainage experiment[J]. Journal of China Coal Society, 2019, 44(8): 2 494-2 501.
[9]	董书宁, 王皓, 张文忠. 华北型煤田奥灰顶部利用与改造判别准则及底板破坏深度[J]. 煤炭学报, 2019, 44(7): 2 216-2 226.
	DONG Shuning, WANG Hao, ZHANG Wenzhong. Judgement criteria with utilization and grouting reconstruction of top Ordovician limestone and floor damage depth in North China coal field[J]. Journal of China Coal Society, 2019, 44(7): 2 216-2 226.
[10]	CHENG Xianggang, QIAO Wei, LI Guofa, et al. Risk assessment of roof water disaster due to multi-seam mining at Wulunshan coal mine in China[J]. Arabian Journal of Geosciences, 2021, 14(12): 1-15. doi: 10.1007/s12517-020-06304-8
[11]	YU Shengchao, XU Jingmin, ZHU Weibing, et al. Development of a combined mining technique to protect the underground workspace above confined aquifer from water inrush disaster[J]. Bulletin of Engineering Geology and the Environment, 2020, 79 (7): 3 649-3 666. doi: 10.1007/s10064-020-01803-0
[12]	武强. 我国矿井水防控与资源化利用的研究进展、问题和展望[J]. 煤炭学报, 2014, 39(5): 795-805.
	WU Qiang. Progress,problems and prospects of prevention and control technology of mine water and reutilization in China[J]. Journal of China Coal Society, 2014, 39(5): 795-805.
[13]	王洋, 武强, 丁湘, 等. 深埋侏罗系煤层顶板水害源头防控关键技术[J]. 煤炭学报, 2019, 44(8): 2 449-2 459.
	WANG Yang, WU Qiang, DING Xiang, et al. Key technologies for prevention and control of roof water disaster at sources in deep Jurassic seams[J]. Journal of China Coal Society, 2019, 44(8): 2 449-2 459.
[14]	董书宁, 姬亚东, 王皓, 等. 鄂尔多斯盆地侏罗纪煤田典型顶板水害防控技术与应用[J]. 煤炭学报, 2020, 45(7): 2 367-2 375.
	DONG Shuning, JI Yadong, WANG Hao, et al. Prevention and control technology and application of roof water disaster in Jurassic coal field of Ordos basin[J]. Journal of China Coal Society, 2020, 45(7): 2 367-2 375.
[15]	乔伟, 王志文, 李文平, 等. 煤矿顶板离层水害形成机制、致灾机理及防治技术[J]. 煤炭学报, 2021, 46(2): 507-522.
	QIAO Wei, WANG Zhiwen, LI Wenping, et al. Formation mechanism,disaster-causing mechanism and prevention technology of roof bed separation water disaster in coal mines[J]. Journal of China Coal Society, 2021, 46(2): 507-522.
[16]	赵宝峰, 吕玉广. 侏罗纪煤田煤层底板砂岩水害特征与防控技术[J]. 中国煤炭, 2021, 47(9): 56-63.
	ZHAO Baofeng, LYU Yuguang. Research on characteristics and prevention and control technology of sandstone water disaster in coal seam floor in Jurassic coalfield[J]. China Coal, 2021, 47(9): 56-63.
[17]	王皓, 董书宁, 姬亚东, 等. 煤矿水害智能化防控平台架构及关键技术[J]. 煤炭学报, 2022, 47(2): 883-892.
	WANG Hao, DONG Shuning, JI Yadong, et al. Key technology and platform development of intelligent prevention and control on coal mine disaster[J]. Journal of China Coal Society, 2022, 47(2): 883-892.
[18]	国家煤矿安全监察局. 煤矿防治水细则[Z]. 2018-06-04.

突水系数P/(MPa·m^-1)	水害危险性分区
<0.06	安全区
0.06<P<0.1	过渡区
>0.1	危险区

层数	含水层	均厚/ m	单位涌水量/ (L·s^-1·m^-1)	渗透系数/ (m·d^-1)
1	新生界	34.04	—	—
2	白垩系	61.53	0.007 1~0.059 7	0.005 5~0.288 3
4	直罗组	43.69	0.010 3~0.120 6	0.023 3~0.281 2
6	煤系间	75.04	0.000 4~0.024 5	0.000 6~0.750 9
8	宝塔山	59.64	0.037 7~1.070 9	0.105 7~2.060 3
9	三叠系	39.69	0.000 5~0.040 6	0.000 7~0.022 1

钻场	1号	2号	3号	4号
高程/m	+880	+913~+918	+771~+776	+750
宝塔山砂岩水位/m	+1 196	+1 190	+1 193	+1 190
带压程度/MPa	3.16	2.72~2.77	4.17~4.22	4.40
疏水降压顺序	1	2	3	4

分阶段疏水降压方案	钻场	水害防控效果	疏放水量/(m³·d^-1)	时间/d	总疏放水量/ (10⁴·m³)
A	1号	未达到	8 000	>730	>584
B	1号+2号	未达到	14 000	>730	>1 022
C	1号+2号+3号	达到	17 000	203	345.1
D	1号+2号+3号+4号	达到	0~96 d:26 000;97~215 d:20 000	215	487.6
