矿井带式输送机火灾烟流特性及其预警防控综述

doi:10.16265/j.cnki.issn1003-3033.2024.03.0393

摘要/Abstract

摘要：

为有效防控煤矿井下带式输送机火灾事故,保障煤矿工作人员的生命财产安全,系统分析矿井带式输送机火灾的起火原因、燃烧特性、烟流特性、监测预警技术及防治措施,并基于当前研究现状提出展望。结果表明:引发带式输送机火灾的主要原因是摩擦温升、电气设备故障及明火;研究带式输送机火灾燃烧和烟流特性采用的巷道火灾模型及数值模拟相关参数具有一定局限性,需综合考虑运输巷道实际工况及环境等参数;国内虽有针对带式输送机火灾的监测预警系统,但其尚有不足,需引入5G、大数据及人工智能等新兴技术予以完善,并结合硬件探测及人员管理等方面,健全煤矿带式输送机火灾防治体系,进而全面推动煤矿安全智能化建设。

关键词: 带式输送机火灾, 烟流特性, 监测预警, 起火原因, 燃烧特性, 防治措施

Abstract:

To effectively prevent and control coal mine underground belt conveyor fire accidents and ensure the safety of lives and property of coal mine workers, the fire causes, combustion characteristics, smoke flow characteristics, monitoring and early warning technologies, and prevention measures of mine belt conveyor fires were systematically analyzed. Then, further prospects were proposed based on the current research status. The results showed that the main causes of belt conveyor fire were friction temperature rise, electrical equipment failure, and open flame. There were some limitations for the tunnel fire model and corresponding numerical simulation parameters used to study the fire combustion and smoke flow characteristics of belt conveyors, the actual working conditions and environmental parameters of the transportation tunnel should be comprehensively considered. Although there were monitoring and early warning systems for belt conveyor fires in China, they had some limitations. It was necessary to introduce emerging technologies such as 5G, big data, and artificial intelligence, and combine them with hardware detection and personnel management to improve the coal mine belt conveyor fire prevention and control system, and then comprehensively promote the construction of safety and intelligent in coal mine.

Key words: belt conveyor fire, fire smoke flow characteristics, monitoring and early warning, fire causes, combustion characteristics, prevention and control measures

中图分类号:

徐永亮, 孙萌, 王兰云, 王云刚. 矿井带式输送机火灾烟流特性及其预警防控综述[J]. 中国安全科学学报, 2024, 34(3): 117-128.

XU Yongliang, SUN Meng, WANG Lanyun, WANG Yungang. Review of fire smoke flow characteristics and early warning prevention and control of mine belt conveyor[J]. China Safety Science Journal, 2024, 34(3): 117-128.

图/表 10

图1

图2

图3

表1

图4

图5

表2

图6

图7

图8

参考文献 68

[1]	国家统计局. 中华人民共和国2022年国民经济和社会发展统计公报[EB/OL].[2023-02-18]. https://www.stats.gov.cn/sj/zxfb/.
[2]	马砺, 刘顺, 李超华, 等. 巷道火灾密闭过程中烟气温度及流动特性研究[J]. 中国安全生产科学技术, 2021, 17(2):46-52.
	MA Li, LIU Shun, LI Chaohua, et al. Study on temperature and flow characteristics of smoke during sealing process of roadway fire[J]. Journal of Safety Science and Technology, 2021, 17(2):46-52.
[3]	邓惠英. 釆区上山火灾烟气运动规律及对通风系统影响的数值模拟[D]. 南宁: 广西大学, 2016.
	DENG Huiying. Numerical simulation of the mining area mountain fire smoke movement rules and the influence on the ventilation system[D]. Nanning: Guangxi University, 2016.
[4]	ZHOU Gang, CHENG Weimin, ZHANG Rui, et al. Numerical simulation and disaster prevention for catastrophic fire airflow of main air-intake belt roadway in coal mine: a case study[J]. Journal of Central South University, 2015, 22(6):2359-2368. doi: 10.1007/s11771-015-2761-x
[5]	11·20鸡西杏花煤矿火灾事故[OL].[2023-02-18]. https://baike.baidu.com/.
[6]	国家矿山安全监察局. 重庆能投渝新能源有限公司松藻煤矿“9·27”重大火灾事故案例[EB/OL].[2023-02-18]. https://www.chinamine-safety.gov.cn/zfxxgk/fdzdgknr/sgcc/sgalks/202107/t20210723_392765.shtml.
[7]	徐晓明. 煤矿井下胶带输送机火灾事故分析及预防对策[J]. 煤矿安全, 2010, 41(9):132-134.
	XU Xiaoming. The analysis and prevention measures of fire accident of belt conveyor in coal mine[J]. Safety in Coal Mines, 2010, 41(9):132-134.
[8]	王烨. 矿井胶带火灾烟流蔓延特性与监测方法研究[D]. 西安: 西安科技大学, 2021.
	WANG Ye. Research on the spread characteristics and monitoring methods of belt fire in mines[D]. Xi'an: Xi'an University of Science and Technology, 2021.
[9]	崔健. 基于WSN的矿井皮带传输机火灾监测节点的研究[D]. 阜新: 辽宁工程技术大学, 2014.
	CUI Jian. Research of the belt transport machine fire monitoring node based on WSN[D]. Fuxin: Liaoning Technical University, 2014.
[10]	冯世刚. 煤矿皮带运输集控系统的设计[D]. 重庆: 重庆大学, 2013.
	FENG Shigang. The design of the belt conveyance centralized control system for coal mine[D]. Chongqing: Chongqing University, 2013.
[11]	LIU Yuxin, MA Xiaomin. Application of image segmentation based on the artificial bee colony algorithm in fire detection of mine belt conveyor[C]. Proceedings in 2017 10th International Congress on Image and Signal Processing, BioMedical Engineering and Informatics (CISP-BMEI), 2017: 1-5.
[12]	煤矿安全网. 煤矿事故/事故案例[EB/OL].[2023-02-18]. https://www.mkaq.org/sggl/shigual/.
[13]	赵钰, 高新宇, 王正书, 等. 煤矿用阻燃输送带阻燃剂协同机理[J]. 煤炭科学技术, 2018, 46(增2):187-189.
	ZHAO Yu, GAO Xinyu, WANG Zhengshu, et al. Synergistic mechanism of flame retardant for flame retardant conveyor belt in coal mine[J]. Coal Science and Technology, 2018, 46(S2):187-189.
[14]	王志刚. 胶带输送机火灾发展规律[J]. 煤矿安全, 1998, 29(4):45-47.
	WANG Zhigang. Development law of belt conveyor fire[J]. Safety in Coal Mines, 1998, 29 (4):45-47.
[15]	余明高, 贾海林, 胡祖祥. 矿井火灾防治[M]. 北京: 国防工业出版社, 2013: 32-36.
[16]	张泽. 矿井胶带火灾烟气流动模拟及危险区域划分[D]. 西安: 西安科技大学, 2017.
	ZHANG Ze. Simulation and division of danger areas of smoke flow of belt fire in coal mine[D]. Xi'an: Xi'an University of Science and Technology, 2017.
[17]	侯欣然. 矿井胶带巷火灾风流动态模拟及避灾路线分析[D]. 唐山: 河北联合大学, 2012.
	HOU Xinran. Simulating the dynamic smoke plume and analyzing the route of avoiding disaster on mine's belt roadway fire[D]. Tangshan: Hebei United University, 2012.
[18]	黄刚. 煤矿井下胶带火灾烟气流动及分布规律研究[D]. 廊坊: 华北科技学院, 2018.
	HUANG Gang. Research on smoke flow and distribution of conveyor belt fire in coal mine[D]. Langfang: North China University of Science and Technology, 2018.
[19]	张李荣. 平直巷道胶带火灾温度场及烟气流动规律实验研究[D]. 西安: 西安科技大学, 2016.
	ZHANG Lirong. Experimental study on temperature field and smoke flow of conveyor belt fire in flat tunnel[D]. Xi'an: Xi'an University of Science and Technology, 2016.
[20]	谭波. 基于物理场模型的矿井火灾动态仿真技术研究[D]. 北京: 中国矿业大学(北京), 2010.
	TAN Bo. The research of dynamic simulation for coal mine fire based on physical field model[D]. Beijing: China University of Mining and Technology (Beijing), 2010.
[21]	铁勇. 地下高大空间火灾烟气自由填充试验研究[J]. 热科学与技术, 2019, 18(3):234-242.
	TIE Yong. Experimental analysis of the natural smoke filling in large underground space[J]. Journal of Thermal Science and Technology, 2019, 18(3):234-242.
[22]	方旭. 墙壁与顶棚限制火羽流与火焰扩散燃烧特性研究[D]. 合肥: 中国科学技术大学, 2022.
	FANG Xu. Studies on fire plumes and flame diffusion combustion characteristics under the constraints effects of wall and ceiling[D]. Hefei: University of Science and Technology of China, 2022.
[23]	黄刚, 王玉怀, 赵启峰, 等. 不同风速下巷道火灾烟气蔓延规律的数值模拟[J]. 中国煤炭, 2018, 44(2):109-112.
	HUANG Gang, WANG Yuhuai, ZHAO Qifeng, et al. Numerical simulation of roadway fire smoke flow diffusion with different wind velocities[J]. China Coal, 2018, 44(2):109-112.
[24]	王亚琼, 李勇, 孙铁军, 等. 细水雾与排烟系统共同作用下地铁车站火灾烟气蔓延规律[J]. 中国公路学报, 2021, 34(11):225-235. doi: 10.19721/j.cnki.1001-7372.2021.11.018
	WANG Yaqiong, LI Yong, SUN Tiejun, et al. Analysis of suppression performance of platform water mist system and exhaust system on subway train fires in stations[J]. China Journal of Highway and Transport, 2021, 34(11):225-235. doi: 10.19721/j.cnki.1001-7372.2021.11.018
[25]	FANNELOP T K. Fluid mechanics for industrial safety and environmental protection[J]. Journal of Hazardous Materials, 1996, 48(1):265-266. doi: 10.1016/S0304-3894(96)90010-2
[26]	齐庆杰, 王欢, 董子文, 等. 矿井胶带运输巷火灾蔓延规律的数值模拟研究[J]. 中国安全科学学报, 2016, 26(10):36-41.
	QI Qingjie, WANG Huan, DONG Ziwen, et al. Numerical simulation of belt conveyor fire spreading law in coal mine[J]. China Safety Science Journal, 2016, 26(10):36-41.
[27]	周丹, 李慎宇, 王哲, 等. 隧道坡度对地铁列车火灾烟气蔓延特性影响研究[J]. 安全与环境学报, 2022, 22(2):733-741.
	ZHOU Dan, LI Shenyu, WANG Zhe, et al. Effect of tunnel slope on smoke movement characteristics in subway trains fire[J]. Journal of Safety and Environment, 2022, 22(2):733-741.
[28]	杨宇轩, 程辉航, 龙增, 等. 阻塞效应对隧道火灾烟气温度影响试验研究[J]. 中国安全科学学报, 2022, 32(10):135-141. doi: 10.16265/j.cnki.issn1003-3033.2022.10.1792
	YANG Yuxuan, CHENG Huihang, LONG Zeng, et al. Experimental study on effect of blockage on smoke temperature characteristics in tunnel fire[J]. China Safety Science Journal, 2022, 32(10):135-141. doi: 10.16265/j.cnki.issn1003-3033.2022.10.1792
[29]	贾静, 郭立稳, 朱令起, 等. 矿井巷道火灾烟流逆退数值模拟及临界风速研究[J]. 中国安全生产科学技术, 2020, 16(4):94-100.
	JIA Jing, GUO Liwen, ZHU Lingqi, et al. Study on numerical simulation of smoke backflow and critical wind speed in mine roadway fire[J]. Journal of Safety Science and Technology, 2020, 16(4):94-100.
[30]	高云骥, 罗越扬, 李智胜, 等. 分岔隧道火灾烟气回流长度及温度分布试验研究[J]. 中国安全科学学报, 2022, 32(3):109-115. doi: 10.16265/j.cnki.issn1003-3033.2022.03.015
	GAO Yunji, LUO Yueyang, LI Zhisheng, et al. Experimental study on smoke back-layering length and temperature distribution in bifurcation tunnels[J]. China Safety Science Journal, 2022, 32(3):109-115. doi: 10.16265/j.cnki.issn1003-3033.2022.03.015
[31]	季经纬, 程远平. 火灾动力学[M]. 徐州: 中国矿业大学出版社, 2018: 58-60.
[32]	吴陈燕. 半横向排烟公路隧道火灾烟气扩散和排烟效果研究[D]. 淮南: 安徽理工大学, 2021.
	WU Chenyan. Study on fire smoke diffusion and smoke exhaust effect of semi-transverse smoke exhaust highway tunnel[D]. Huainan: Anhui University of Science and Technology, 2021.
[33]	YAN Zhiguo, GUO Qinghua, ZHU Hehua. Full-scale experiments on fire characteristics of road tunnel at high altitude[J]. Tunnelling and Underground Space Technology, 2017, 66:DOI:10.1016/j.tust.2017.04.007.
[34]	HUANG Youbo, LI Yanfeng, LI Junmei, et al. Experimental investigation on maximum gas temperature beneath the ceiling in a branched tunnel fire[J]. International Journal of Thermal Sciences, 2019, 145:DOI:10.1016/j.ijthermalsci.2019.105997.
[35]	LI Yingzhen, INGASON H. Position of maximum ceiling temperature in a tunnel fire[J]. Fire Technology, 2014, 50(4):889-905. doi: 10.1007/s10694-012-0309-2
[36]	LEI Jiang, MING Xiao. Effect of tunnel slope on the critical velocity of densimetric plumes and fire plumes in ventilated tunnels[J]. Tunnelling and Underground Space Technology, 2022, 123:DOI:10.1016/J.TUST.2022.104394.
[37]	CHEN Changkun, ZHANG Yulun, LEI Peng, et al. Experimental study on fire behaviors in narrow bifurcated channel with a confined portal[J]. Combustion Science and Technology, 2021, 193(13):2194-2216. doi: 10.1080/00102202.2020.1732362
[38]	ZHAO Shengzhong, LIU Fang, WANG Fei, et al. A numerical study on smoke movement in a metro tunnel with a non-axisymmetric cross-section[J]. Tunnelling & Underground Space Technology, 2018, 73:DOI:10.1016/j.tust.2017.12.002.
[39]	LI Kaiyuan, HUO Ran, LIU Yang. On temperature change of tunnel top plume in a longitudinal ventilation[J]. Journal of Safety and Environment, 2006, 274(37):26 503-26 510.
[40]	姚勇征, 宋恪斌, 史聪灵, 等. 纵向通风下T型分岔隧道火灾烟气蔓延特性[J]. 中国安全科学学报, 2022, 32(10):115-120. doi: 10.16265/j.cnki.issn1003-3033.2022.10.1590
	YAO Yongzheng, SONG Kebin, SHI Congling, et al. Fire smoke spread characteristics of T-shaped bifurcated tunnel under longitudinal ventilation[J]. China Safety Science Journal, 2022, 32(10):115-120. doi: 10.16265/j.cnki.issn1003-3033.2022.10.1590
[41]	YANG Dingyi, ZHANG Xiaole, ZHU Shi, et al. Comparative study on carbon monoxide stratification and thermal stratification in a horizontal channel fire[J]. Building & Environment, 2012, 49:1-8.
[42]	SOUFIEN G, JAMIL Z, MAAD R B, et al. Numerical study on the thermal buoyant flow stratification in tunnel fires with longitudinal imposed airflow: effect of an upstream blockage[J]. International Journal of Thermal Sciences, 2019, 145:DOI:10.1016/j.ijthermalsci.2018.10.041.
[43]	雷鹏, 陈长坤, 赵冬月. 纵向通风下分岔隧道火灾烟气蔓延特性及控制实验研究[J]. 铁道科学与工程学报, 2022, 19(7):2117-2124.
	LRI Peng, CHEN Changkun, ZHAO Dongyue. Experimental study on smoke movement characteristics and control in branched tunnel fire under longitudinal ventilation[J]. Journal of Railway Science and Engineering, 2022, 19(7):2117-2124.
[44]	WANG Jie, PAN Yangyue, LU Song, et al. CO concentration decay profile and ceiling jet entrainment in aircraft cargo compartment fires at reduced pressures[J]. Applied Thermal Engineering, 2017, 110:DOI:10.1016/j.applthermaleng.2016.08.213.
[45]	王洁, 樊勇杰, 孔晓威, 等. 低气压对竖井自然排烟隧道内火灾烟气层的影响研究[J]. 安全与环境工程, 2022, 29(6):78-86.
	WANG Jie, FAN Yongjie, KONG Xiaowei, et al. Effect of reduced ambient pressure on the smoke layer of fire in shaft natural exhaust tunnel[J]. Safety and Environmental Engineering, 2022, 29(6):78-86.
[46]	ZHOU Fubao, WANG Deming. Backdraft in descensionally ventilated mine fire[J]. Journal of fire sciences, 2005, 23(3):261-271. doi: 10.1177/0734904105047915
[47]	乔旺. 矿井巷道火灾中火区温度,阻力以及节流效应的研究[D]. 包头: 内蒙古科技大学, 2012.
	QIAO Wang. The temperature and resistance and throttling effect of fire research in mine tunnel fire[D]. Baotou: Inner Mongolia University of Science and Technology, 2012.
[48]	王树刚, 王如竹. 矿井火灾引起节流和浮力效应的理论研究[J]. 中国矿业大学学报, 2002, 31(3):16-19.
	WANG Shugang, WANG Ruzhu. Theoretical research on throttling and buoyancy effects induced by mine fire[J]. Journal of China University of Mining and Technology, 2002, 31(3):16-19.
[49]	李静. 下行通风巷道火灾烟流逆流层形成及阻力效应数值模拟研究[D]. 阜新: 辽宁工程技术大学, 2013.
	LI Jing. Countercurrent layer and the resistance effect research of downstream ventilation fire roadway by numerical simulation[D]. Fuxin: Liaoning Technical University, 2013.
[50]	李宗翔, 王海文, 李腾, 等. 下行风流火灾管道试验与烟流动力特征研究[J]. 安全与环境学报, 2023, 23(2):391-396.
	LI Zongxiang, WANG Haiwen, LI Teng, et al. Downstream airflow fire dust test and smoke flow dynamic characteristics study[J]. Journal of Safety and Environment, 2023, 23(2):391-396.
[51]	郭键. 一种模糊神经网络在矿井胶带机火灾探测中的应用[J]. 兰州理工大学学报, 2007, 33(3):88-91.
	GUO Jian. Application of a fuzzy neural network in fire-detection of belt conveyer in mines[J]. Journal of Lanzhou University of Technology, 2007, 33(3):88-91.
[52]	汪洋. 基于STM32矿用皮带机智能故障诊断系统的研究[D]. 芜湖: 安徽工程大学, 2019.
	WANG Yang. Base on the study of STM32 mine belt intelligent fault diagnosis system[D]. Wuhu: Anhui Polytechnic University, 2019.
[53]	LITTON C, PERERA I E. Evaluation of criteria for the detection of fires in underground conveyor belt haulageways[J]. Fire Safety Journal, 2012, 51:DOI:10.1016/j.firesaf.2012.04.004.
[54]	GUO Jian, ZHU Jie, ZHAO Mingru, et al. Application of self-adaptive neural fuzzy network in early detection of conveyor belt fire[C]. Proceedings in 2009 International Conference on Information Engineering and Computer Science, 2009: 1-5.
[55]	DUSHI A, KONGOLI F, MCBOW I. Optimization of conveyer belts fire-resistant rubber properties using a mathematical model of desirability functions[J]. IFAC Proceedings Volumes, 2013, 46(16):377-384.
[56]	李国财. 煤矿井下带式输送机火灾预防措施[J]. 山东煤炭科技, 2015(3):127-128,130.
	LI Guocai. Fire prevention measures for belt conveyor in underground coal mine[J]. Shandong Coal Science and Technology, 2015, (3):127-128,130.
[57]	岳宁芳, 蔡国斌, 高文静, 等. 矿井胶带蔓延火灾的细水雾抑制影响因素研究[J]. 中国安全生产科学技术, 2022, 18(4):92-97.
	YUE Ningfang, CAI Guobin, GAO Wenjing, et al. Research on influencing factors of water mist suppression for belt spreading fire in mine[J]. Journal of Safety Science and Technology, 2022, 18(4):92-97.
[58]	祁云, 齐庆杰, 汪伟, 等. 胶带运输巷水幕抑制火灾烟气效率影响因素实验研究[J]. 中国安全生产科学技术, 2019, 15(5):123-129.
	QI Yun, QI Qingjie, WANG Wei, et al. Experimental study on influencing factors of fire smoke suppression efficiency by water curtain in belt transportation roadway[J]. Journal of Safety Science and Technology, 2019, 15(5):123-129.
[59]	ZHANG Wang, JIANG Juncheng, SUN Zhihao, et al. Numerical simulation of blocking smoke motion under water mist curtain in the corridor[J]. Fire Science Technology, 2014, 33(1):29-33.
[60]	ZHANG Shuhui. Numerical simulation analysis on fire facilities in an underground garage[J]. Journal of Civil,Architectural Environmental Engineering, 2013, 35(S1):209-211,226.
[61]	YUAN Liming, SMITH A C. Numerical modeling of water spray suppression of conveyor belt fires in a large-scale tunnel[J]. Process Safety and Environmental Protection, 2015, 95:DOI:10.1016/j.psep.2015.02.018.
[62]	ZHU Guoqing, ZHANG Guowei, WANG Xiaolan, et al. Designing and practical computing of fire isolation belt in large space building[J]. Procedia Engineering, 2011, 11:745-751. doi: 10.1016/j.proeng.2011.04.722
[63]	WANG Kai, JIANG Shuguang, MA Xiaoping, et al. Numerical simulation and application study on a remote emergency rescue system during a belt fire in coal mines[J]. Natural Hazards, 2016, 84(2):1463-1485. doi: 10.1007/s11069-016-2538-z
[64]	郝海清, 王凯, 张春玉, 等. 矿井皮带巷火灾风烟流场-区-网演化与调控规律[J]. 中国矿业大学学报, 2021, 50(4):716-724.
	HAO Haiqing, WANG Kai, ZHANG Chunyu, et al. Evolution and regulation law of wind and smoke flow field area network in mine belt roadway fire[J]. Journal of China University of Mining and Technology, 2021, 50(4):716-724.
[65]	张洪亮. 基于虚拟现实技术的煤矿胶带火灾模拟系统[J]. 煤矿安全, 2014, 45(4):128-131.
	ZHANG Hongliang. Coal mine belt fire simulation system based on virtual reality technology[J]. Safety in Coal Mines, 2014, 45(4):128-131.
[66]	张睿, 程卫民, 上官昌培, 等. 胶带巷火灾应急救援系统的应用与实践[J]. 煤矿安全, 2010, 41(12):36-39.
	ZHANG Rui, CHENG Weimin, SHANGGUAN Changpei, et al. Application and practice of belt roadway fire emergency rescue system[J]. Safety in Coal Mines, 2010, 41(12):36-39.
[67]	王凯, 蒋曙光, 张卫青, 等. 矿井火灾应急救援系统的数值模拟及应用研究[J]. 煤炭学报, 2012, 37(5):857-862.
	WANG Kai, JIANG Shuguang, ZHANG Weiqing, et al. Numerical simulation and application research of mine fire emergency rescue system[J]. Journal of China Coal Society, 2012, 37(5):857-862.
[68]	周静. 矿井火灾应急救援预案管理系统的开发与实现[D]. 淮南: 安徽理工大学, 2011.
	ZHOU Jing. Development and realization of mine fire emergency rescue preparedness management system[D]. Huainan: Anhui University of Science and Technology, 2011.

危害形式	特征表现	后果
缺氧窒息	输送带燃烧过程中会消耗大量氧气,产生大量CO₂及其他气体,使得火区氧浓度降低	被困人员缺氧窒息导致死亡
中毒、刺激腐蚀呼吸道	带式输送机火灾产生的大多是CO、H₂S、HCL、SO₂等有毒有害气体	被困人员会出现呼吸不畅、头痛、眩晕、恶心呕吐等症状,甚至会导致死亡
高温烟气灼烧	带式输送机火灾产生的高温烟流随着巷道扩散,会导致更多的区域受到高温的影响	被困人员吸入高温烟气,呼吸系统会被灼伤,轻则导致慢性支气管炎、重则死亡

类别	监测对象	监测技术
带式输送机自身可能发生的故障	输送带打滑故障	速度传感器
	输送带跑偏故障	矿用跑偏传感器
	输送带纵撕故障	矿用撕裂传感器
	输送带断裂故障	矿用张力传感器
	带式输送机的撒料	堆煤传感器
	带式输送机异常噪声	热噪声传感器
	托辊表面温度及其他轴承表面温度	记忆合金型托辊超温传感器
运输巷道内的环境因素	温度和湿度	温湿度传感器
	CO浓度	CO传感器
	煤尘浓度	粉尘传感器
	异常烟气及其浓度	离子烟雾传感器
	异常火星或火苗	红外传感器
	电缆线路	线路热监测器
