鞣花酸对下石节长焰煤氧化自燃的阻化影响研究

doi:10.16265/j.cnki.issn1003-3033.2024.08.1764

中国安全科学学报 ›› 2024, Vol. 34 ›› Issue (8): 78-85.doi: 10.16265/j.cnki.issn1003-3033.2024.08.1764

鞣花酸对下石节长焰煤氧化自燃的阻化影响研究

肖旸¹^,²(), 南世华¹, 尹岚¹, 李青蔚¹^,², 王振平¹^,²

¹ 西安科技大学安全科学与工程学院,陕西西安 710054
² 西安科技大学陕西省煤火灾害防治重点实验室,陕西西安 710054

收稿日期:2024-02-22 修回日期:2024-05-25 出版日期:2024-08-28
作者简介:
肖旸 (1979—),男,贵州湄潭人,博士,教授,主要从事煤火灾害机制及其防治技术的研究与应用。E-mail: xiaoy@xust.edu.cn。
李青蔚,副教授。
王振平, 教授。
基金资助:
国家自然科学基金(52174204); 国家自然科学基金(51974233)

Study on inhibition effect of ellagic acid on oxidation spontaneous combustion of long-flame coal in Xiashijie

XIAO Yang¹^,²(), NAN Shihua¹, YIN Lan¹, LI Qingwei¹^,², WANG Zhenping¹^,²

¹ School of Safety Science and Engineering, X'an University of Science and Technology,X'an Shaanxi 710054, China
² Shaanxi Key Laboratory of Prevention and Control of Coal Fire, X'an University of Science and Technology, X'an Shaanxi 710054, China

Received:2024-02-22 Revised:2024-05-25 Published:2024-08-28

摘要/Abstract

摘要：

为考察鞣花酸(EA)对煤氧化自燃过程的影响,首先将EA与陕西铜川下石节煤矿的长焰煤以2%、4%、6%、8%和10%的质量比均匀混合进行试验;然后采用显微红外光谱试验和激光导热试验研究各个样品的活性官能团含量情况和热输运特性,通过评价煤氧化自燃抑制效果,确定最优质量比为8%;最后利用煤自燃程序升温试验对比4种阻化剂对煤氧化自燃气体释放的影响情况,进一步确定EA对煤氧化自燃的阻化程度。结果表明:EA处理煤(EA-tc)中-CH₃、-CH₂、-OH和-C=O-的峰面积相较于原煤(RC)均减少,但C-O的峰面积增加;在相同煤温下,RC的热扩散系数和导热系数高于EA-tc,其比热容低于EA-tc,且8% EA对RC低温氧化过程的热扩散系数、比热容和导热系数的平均抑制率分别为20.8%、9.8%和13.1%;相比于RC,8% EA-tc的CO释放量在170 ℃时降低52.3%,且EA对煤氧化自燃的阻化率在30~170 ℃内保持在50.5%~72.5%,说明EA对煤氧化自燃的阻化效果比其他3种阻化剂更好。

关键词: 鞣花酸(EA), 煤氧化自燃, 阻化率, 热输运特性, 活性官能团

Abstract:

In order to investigate the effect of EA on the process of coal oxidation spontaneous combustion, EA was uniformly mixed with long-flame coal in Xiashijie at the mass ratios of 2%,4%,6%,8% and 10% to experiment. The contents of active functional groups and the variation characteristics of thermal transport characteristics of each sample were studied using the microscopic infrared spectroscopy test and laser thermal conductivity test. The optimal mass ratio was determined to be 8% through the evaluation of the inhibitory effect of coal oxidation spontaneous combustion. The coal spontaneous combustion temperature-programmed test was used to compare the influence of four inhibitors on the gas release of coal oxidation spontaneous combustion, and the degree of inhibition of EA on coal oxidation spontaneous combustion was further determined. The results showed that the peak areas of -CH₃, -CH₂, -OH and -C=O- in EA-tc are reduced, but the peak area of C-O is increased compared with RC. At the same coal temperature, the thermal diffusivity and thermal conductivity of the RC are higher than those of EA-tc, and its specific heat is lower than those of EA-tc. The average inhibition rates of thermal diffusivity, specific heat capacity and thermal conductivity of 8% EA on low-temperature oxidation process of coal samples are 20.8%, 9.8% and 13.1%, respectively. Compared with RC, CO release amount of 8% EA-tc is reduced by 52.3% at 170 ℃, and the resistance rate of EA on coal oxidation spontaneous combustion is maintained at 50.5% to 72.5% at 30 to 170 ℃. The inhibitory effect of EA on coal oxidation spontaneous combustion is better than that of the other three inhibitors.

Key words: ellagic acid (EA), coal oxidation spontaneous combustion, resistance rate, thermal transport characteristics, active functional groups

中图分类号:

X936
TD752

肖旸, 南世华, 尹岚, 李青蔚, 王振平. 鞣花酸对下石节长焰煤氧化自燃的阻化影响研究[J]. 中国安全科学学报, 2024, 34(8): 78-85.

XIAO Yang, NAN Shihua, YIN Lan, LI Qingwei, WANG Zhenping. Study on inhibition effect of ellagic acid on oxidation spontaneous combustion of long-flame coal in Xiashijie[J]. China Safety Science Journal, 2024, 34(8): 78-85.

图/表 14

表1

表2

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

图11

图12

参考文献 14

[1]	ZHANG Yutao, LIU Yurui, SHI Xueqiang, et al. Risk evaluation of coal spontaneous combustion on the basis of auto-ignition temperature[J]. Fuel, 2018, 233: 68-76.
[2]	张嬿妮, 舒盼, 刘春辉, 等. 乙二胺四乙酸微胶囊阻化煤自燃性能研究[J]. 煤炭科学技术, 2022, 50(8): 108-117.
	ZHANG Yanni, SHU Pan, LIU Chunhui, et al. Study on inhibition of coal spontaneous combustion by ethylenedia mine tetraacetic acid microcapsule[J]. Coal Science and Technology, 2022, 50(8): 108-117.
[3]	肖旸, 叶星星, 刘昆华, 等. 二次氧化煤自燃过程关键官能团的转变规律[J]. 煤炭学报, 2021, 46(增2): 989-1000.
	XIAO Yang, YE Xingxing, LIU Kunhua, et al. Transformation law of key functional groups in the process of coal secondary oxidation[J]. Journal of China Coal Society, 2021, 46(S2): 989-1000.
[4]	戚绪尧, 王涛, 张兰君, 等. 低共熔溶剂抑制煤自燃的机理研究[J]. 煤炭学报, 2024, 49(4): 1 917-1 930.
	QI Xuyao, WANG Tao, ZHANG Lanjun, et al. Mechanism of deep eutectic solvent on coal spontaneous combustion[J]. Journal of China Coal Society, 2024, 49(4): 1 917-1 930.
[5]	LI Jinhu, LI Zenghua, WANG Chaojie, et al. Experimental study on the inhibitory effect of ethylenediaminetetraacetic acid (EDTA) on coal spontaneous combustion[J]. Fuel Processing Technology, 2018, 178: 312-321.
[6]	娄和壮, 贾廷贵. 惰性气氛对煤自燃过程的竞争吸附差异性研究[J]. 中国安全科学学报, 2020, 30(4): 60-67. doi: 10.16265/j.cnki.issn1003-3033.2020.04.010
	LOU Hezhuang, JlA Tinggui. Competitive adsorption differences during coal spontaneous combustion process in noble gas atmosphere[J]. China Safety Science Journal, 2020, 30(4): 60-67. doi: 10.16265/j.cnki.issn1003-3033.2020.04.010
[7]	LI Jinhu, LI Zenghua, YANG Yongliang, et al. Laboratory study on the inhibitory effect of free radical scavenger on coal spontaneous combustion[J]. Fuel Processing Technology, 2018, 171: 350-360.
[8]	WANG Deming, DOU Guolan, ZHONG Xiaoxing, et al. An experimental approach to selecting chemical inhibitors to retard the spontaneous combustion of coal[J]. Fuel, 2014, 117: 218-223.
[9]	GAO Ao, SUN Yong, HU Xiangming, et al. Substituent positions and types for the inhibitory effects of phenolic inhibitors in coal spontaneous combustion[J]. Fuel, 2022, 309: DOI: 10.1016/j.fuel.2021.122104.
[10]	LIU Peiyu, LI Zenghua, ZHANG Xiaoyan, et al. Study on the inhibition effect of citric acid on coal spontaneous combustion[J]. Fuel, 2022, 310: DOI: 10.1016/j.fuel.2021.122268.
[11]	王福生, 张朝阳, 刘向群, 等. 金属离子螯合剂抑制煤自燃试验研究[J]. 煤炭科学技术, 2023, 51(增1): 1-8.
	WANG Fusheng, ZHANG Chaoyang, LIU Xiangqun, et al. Experimental study on suppression of coal spontaneous combustion by metal ion chelating agents[J]. Coal Science and Technology, 2023, 51(S1): 1-8.
[12]	姜峰, 孙雯倩, 李珍宝, 等. 复合阻化剂抑制煤自燃过程的阶段阻化特性[J]. 煤炭科学技术, 2022, 50(10): 68-75.
	JIANG Feng, SUN Wenqian, LI Zhenbao, et al. Stage inhibition characteristics of composite inhibitor in process of inhibiting coal spontaneous combustion[J]. Coal Science and Technology, 2022, 50(10): 68-75.
[13]	WANG Kai, HU Lihong, DENG Jun, et al. Inhibiting effect and mechanism of polyethylene glycol-citric acid on coal spontaneous combustion[J]. Energy, 2023, 275: 127-522.
[14]	LI Dajiang, XIAO Yang, LYU Huifei, et al. Effects of 1-butyl-3-methylimidazolium tetrafluoroborate on the exothermic and heat transfer characteristics of coal during low-temperature oxidation[J]. Fuel, 2020, 273: DOI: 10.1016/j.fuel.2020.117589.
