慢行道骑行者心率的空间分布及变化特征解析

doi:10.16265/j.cnki.issn1003-3033.2025.02.0116

中国安全科学学报 ›› 2025, Vol. 35 ›› Issue (2): 186-195.doi: 10.16265/j.cnki.issn1003-3033.2025.02.0116

慢行道骑行者心率的空间分布及变化特征解析

林鑫源(), 刘凯烜, 安兴, 胡喜生, 徐锦强, 王占永^**()

福建农林大学交通与土木工程学院,福建福州 350108

收稿日期:2024-09-28 修回日期:2024-11-21 出版日期:2025-02-28
通信作者:
**王占永(1983—),男,河南临颍人,博士,副教授,主要从事交通环境与健康方面的研究。E-mail:wangzy1026@fafu.edu.cn。
作者简介:
林鑫源 (2000—),男,福建厦门人,硕士研究生,研究方向为道路交通空气污染监测与模拟。E-mail:2606295540@qq.com。
胡喜生教授
徐锦强副教授
基金资助:
国家自然科学基金资助(41701552); 福建省自然科学基金资助(2021J01105)

Analysis of spatial distribution and variation characteristics of cyclists' heart rates in non-motorized lane

LIN Xinyuan(), LIU Kaixuan, AN Xing, HU Xisheng, XU Jinqiang, WANG Zhanyong^**()

School of Transportation and Civil Engineering, Fujian Agriculture and Forestry University, Fuzhou Fujian 350108, China

Received:2024-09-28 Revised:2024-11-21 Published:2025-02-28

摘要/Abstract

摘要：

为指导炎热天气下骑行者健康出行,以福州市西三环快速路沿侧慢行道为试验靶区,构建基于微型传感器的骑行测量平台,采集骑行者心率(HR)以及骑行路线上PM_2.5、PM₁₀和黑碳(BC)等大气颗粒物的高分辨率样本,统计解析骑行者HR变化特征及原因。结果表明:骑行者平均HR呈现小区侧大于沿江侧,与所有颗粒物均表现出较强的长期持续性关联特征;柴油车数量、气温、大气压强分别对全路段、沿江侧和小区侧慢行道的骑行者HR变化有较大解释权重,但骑行者HR也因路侧环境、地形等条件的差异而不同;PM_2.5和BC对骑行者HR的影响具有即时效应,PM₁₀的影响存在滞后性。因此,分路段差异化管控机动车,尤其严控排放对骑行者有即时影响污染物的机动车,并引导选择路侧通透、绿化覆盖率高的路线出行,能够提升骑行者出行品质。

关键词: 慢行道, 骑行者心率(HR), 空间分布, 去趋势互相关分析(DCCA), 颗粒物, 相对危险度(RR)

Abstract:

To guide healthy travel for cyclists in hot weather, a cycling measurement platform using micro-sensors was developed to collect high-resolution data on cyclists' heart rates, as well as atmospheric particulate matter (i.e., PM_2.5, PM₁₀, and BC(Black Carbon) on the non-motorized lanes of the Western Third-Ring Expressway in Fuzhou. Statistical analyses were conducted to characterize and interpret variations in cyclists' heart rates. Results indicate that cyclists' average heart rates near residential zones are higher than that of riverside segments, showing strong and sustained associations with all measured particulates. The number of diesel vehicles, ambient temperature, and atmospheric pressure are found to significantly influence the heart rate changes across sections of the entire route, riverside, and residential sections, respectively. Cyclists' heart rates also fluctuate due to varying environmental and topographical conditions along the route. Immediate effects of PM_2.5 and BC on heart rate are observed, while PM₁₀ effects are delayed. Therefore, implementing road-segment-specific control measures for motor vehicles, particularly strict regulation of those emitting pollutants with immediate effects on cyclists, and guiding the selection of routes with better roadside ventilation and higher greenery coverage, can effectively enhance the travel quality for cyclists.

Key words: non-motorized lane, cyclists' heart rate (HR), spatial distribution, detrended cross-correlation analysis (DCCA), particulate matter, relative risk(RR)

中图分类号:

X968高低温防护

林鑫源, 刘凯烜, 安兴, 胡喜生, 徐锦强, 王占永. 慢行道骑行者心率的空间分布及变化特征解析[J]. 中国安全科学学报, 2025, 35(2): 186-195.

LIN Xinyuan, LIU Kaixuan, AN Xing, HU Xisheng, XU Jinqiang, WANG Zhanyong. Analysis of spatial distribution and variation characteristics of cyclists' heart rates in non-motorized lane[J]. China Safety Science Journal, 2025, 35(2): 186-195.

图/表 8

图1

图2

图3

图4

图5

表1

图6

图7

参考文献 25

[1]	XIE Yuquan, BO Liang, JIANG Shuo, et al. Individual PM_2.5 exposure is associated with the impairment of cardiac autonomic modulation in general residents[J]. Environmental Science and Pollution Research, 2016, 23(10): 10 255-10 261.
[2]	IBALD-MULLI A, TIMONEN K L, PETERS A, et al. Effects of particulate air pollution on blood pressure and heart rate in subjects with cardiovascular disease: a multicenter approach[J]. Environmental Health Perspectives, 2004, 112(3): 369-377.
[3]	WILLIAMS R, BROOK R, BARD R, et al. Impact of personal and ambient-level exposures to nitrogen dioxide and particulate matter on cardiovascular function[J]. International Journal of Environmental Health Research, 2012, 22(1): 71-91. doi: 10.1080/09603123.2011.588437 pmid: 21711166
[4]	RIZZA V, STABILE L, VISTOCCO D, et al. Effects of the exposure to ultrafine particles on heart rate in a healthy population[J]. Science of the Total Environment, 2019, 650: 2403-2410.
[5]	CAKMAK S, DALES R, LEECH J, et al. The influence of air pollution on cardiovascular and pulmonary function and exercise capacity: canadian health measures survey (CHMS)[J]. Environmental Research, 2011, 111(8): 1309-1312. doi: 10.1016/j.envres.2011.09.016 pmid: 22000598
[6]	LIN L, LIN C, LIN Y, et al. The effects of indoor particles on blood pressure and heart rate among young adults in Taipei, Taiwan: indoor particles, blood pressure and heart rate[J]. Indoor Air, 2009, 19(6): 482-488. doi: 10.1111/j.1600-0668.2009.00612.x pmid: 19682103
[7]	CAO Ruhui, LUO Binru, LIU Kaixuan, et al. Characterizing and interpreting the spatial variation of traffic pollution in urban non-motorized lanes using mobile measurements[J]. Air Quality, Atmosphere & Health, 2023, 16: 1907-1929.
[8]	LUO Binru, CAO Ruhui, YANG Wenbin. Analysing and predicting the fine-scale distribution of traffic particulate matter in urban nonmotorized lanes by using wavelet transform and random forest methods[J]. Stochastic Environmental Research and Risk Assessment, 2023, 37(7): 1-20.
[9]	AL-SAREJI O J, GRMASHA R A, HASHIM K S, et al. Personal exposure and inhalation doses to PM1 and PM_2.5 pollution in Iraq: an examination of four transport modes[J]. Building and Environment, 2022, 212: DOI: 10.1016/j.buildenv.2022.108847.
[10]	HAGLER G S W, YELVERTON T L B, VEDANTHAM R, et al. Post-processing method to reduce noise while preserving high time resolution in aethalometer real-time black carbon data[J]. Aerosol and Air Quality Research, 2011, 11(5): 539-546.
[11]	ZHOU Huoyan, FU Liyong, SHARMA R P, et al. A hybrid approach of combining random forest with texture analysis and VDVI for desert vegetation mapping based on UAV RGB data[J]. Remote Sensing, 2021, 13(10): DOI: 10.3390/rs13101891.
[12]	PODOBNIK B, STANLEY H E. Detrended cross-correlation analysis: a new method for analyzing two nonstationary time series[J]. Physical Review Letters, 2008, 100(8): DOI: 10.1103/PhysRevLett.100.084102.
[13]	ENEVOLDSEN J, SIMPSON G L, VISTISEN S T. Using generalized additive models to decompose time series and waveforms, and dissect heart-lung interaction physiology[J]. Journal of Clinical Monitoring and Computing, 2023, 37(1): 165-177.
[14]	DEHGHAN A, KHANJANI N, BAHRAMPOUR A, et al. The relation between air pollution and respiratory deaths in Tehran, Iran- using generalized additive models[J]. BMC Pulmonary Medicine, 2018, 18(1): DOI: 10.1186/s12890-018-0613-9.
[15]	KHOLOD N, EVANS M. Reducing black carbon emissions from diesel vehicles in Russia: an assessment and policy recommendations[J]. Environmental Science & Policy, 2016, 56: 1-8.
[16]	GLADWELL V F, BROWN D K, WOOD C, et al. The great outdoors: how a green exercise environment can benefit all[J]. Extreme Physiology & Medicine, 2013, 2(1): DOI: 10.1186/2046-7648-2-3.
[17]	KIRSCHEN G W, SINGER D D, THODE H C, et al. Relationship between body temperature and heart rate in adults and children: a local and national study[J]. The American Journal of Emergency Medicine, 2020, 38(5): 929-933.
[18]	FITCH D T, SHARPNACK J, HANDY S L. Psychological stress of bicycling with traffic: examining heart rate variability of bicyclists in natural urban environments[J]. Transportation Research Part F, 2020, 70: 81-97.
[19]	REED R, SCARF P, JOBSON S A, et al. Determining optimal cadence for an individual road cyclist from field data[J]. European Journal of Sport Science, 2016, 16(8): 903-911. doi: 10.1080/17461391.2016.1146336 pmid: 26902667
[20]	YANG Weixin, LI Lingguang. Efficiency evaluation of industrial waste gas control in China: a study based on data envelopment analysis (DEA) model[J]. Journal of Cleaner Production, 2018, 179: 1-11.
[21]	SUN Xiaoke, CHEN Hong, LIU Zhizhen, et al. Research on PM_2.5 concentration based on dissipative structure theory: a case study of Xi'an, China[J]. Scientific Reports, 2020, 10(1): DOI: 10.1038/s41598-020-73598-9.
[22]	RICHARDS D, FUNG T, BELCHER R, et al. Differential air temperature cooling performance of urban vegetation types in the tropics[J]. Urban Forestry & Urban Greening, 2020, 50: DOI: 10.1016/j.ufug.2020.126651.
[23]	TRAN B, CHANG C, HSU C, et al. Threshold effects of PM_2.5 exposure on particle-related mortality in China[J]. International Journal of Environmental Research and Public Health, 2019, 16(19): DOI: 10.3390/ijerph16193549.
[24]	YAN Xiaodan, WANG Qiming, TIE Cai, et al. Polydatin protects the respiratory system from PM_2.5 exposure[J]. Scientific Reports, 2017, 7(1): DOI: 10.1038/srep40030.
[25]	BECKERS F, VERHEYDEN B, AUBERT A E. Aging and nonlinear heart rate control in a healthy population[J]. American Journal of Physiology-Heart and Circulatory Physiology, 2006, 290(6): H2560-H2570.

协变量	整条试验路线			A₁路段			B₁路段			B₂路段			A₂路段
协变量	F	VER	p	F	VER	p	F	VER	p	F	VER	P	F	VER	p
s(PM_2.5)	18.91	4.99	<0.001	5.29	2.64	0.022	5.17	4.48	<0.001	4.62	3.39	<0.001	1.41	0.96	0.187
s(PM₁₀)	28.74	7.58	<0.001	1.58	0.79	0.126	5.44	4.71	<0.001	2.74	2.01	0.007	4.27	2.91	<0.001
s(BC)	15.62	4.12	<0.001	9.50	4.74	0.002	0.82	0.71	0.438	4.75	3.49	0.029	8.66	5.91	<0.001
s(AP)	80.15	21.14	<0.001	41.70	20.79	<0.001	9.92	8.60	<0.001	24.77	18.21	<0.001	38.98	26.60	<0.001
s(AT)	61.24	16.15	<0.001	28.02	13.97	<0.001	38.21	33.11	<0.001	12.97	9.54	<0.001	7.23	4.93	<0.001
s(RH)	37.60	9.92	<0.001	9.55	4.76	<0.001	4.50	3.90	<0.001	11.88	8.73	<0.001	4.17	2.84	<0.001
s(DP)	31.80	8.39	<0.001	11.82	5.89	<0.001	6.42	5.56	<0.001	12.87	9.46	<0.001	11.34	7.74	<0.001
s(SG)	9.18	2.42	<0.001	11.70	5.83	<0.001	3.18	2.75	0.037	9.60	7.05	<0.001	2.96	2.02	0.003
s(DE)	14.59	3.85	<0.001	10.35	5.16	<0.001	14.10	12.21	<0.001	13.90	10.22	<0.001	18.93	12.92	<0.001
s(VC)	10.46	2.76	<0.001	2.85	1.42	0.037	4.55	3.94	<0.001	0.41	0.30	0.521	4.66	3.18	<0.001
s(DV)	9.21	2.43	<0.001	46.76	23.32	<0.001	12.04	10.43	<0.001	16.31	11.99	<0.001	24.83	16.94	<0.001
s(TV)	42.90	11.31	<0.001	16.16	8.06	<0.001	9.12	7.90	<0.001	18.41	13.53	<0.001	8.44	5.76	<0.001
te(WS,WD)	18.82	4.96	<0.001	5.28	2.63	<0.001	1.96	1.70	0.027	2.83	2.08	<0.001	10.70	7.30	<0.001
