基于工艺参数驱动的连续式反应器防爆韧性评估

doi:10.16265/j.cnki.issn1003-3033.2026.09.0029

中国安全科学学报 ›› 2026, Vol. 36 ›› Issue (9): 103-110.doi: 10.16265/j.cnki.issn1003-3033.2026.09.0029

基于工艺参数驱动的连续式反应器防爆韧性评估

孙浩¹(), 黄锦¹, 师吉浩²^,³, 王付宇¹, 戚萌⁴

¹ 安徽工业大学管理科学与工程学院, 安徽马鞍山 243032
² 中国石油大学(北京) 安全与海洋工程学院, 北京 102249
³ 香港理工大学智慧消防与城市韧性研究中心, 香港 999077
⁴ 中国石油大学(华东) 化学与化工学院, 山东青岛 266580

收稿日期:2026-04-13 修回日期:2026-07-10 出版日期:2026-10-20
作者简介:
孙浩 (1994—),男,安徽淮北人,博士,副教授,主要从事石油化工系统韧性、石化生产事故智能防控方面的研究。E-mail:sunhao@ahut.edu.cn。
师吉浩教授；
王付宇教授；
戚萌副教授
基金资助:
国家自然科学基金资助(52504194); 安徽省自然科学基金资助(2508085QG281); 安徽省哲学社会科学规划项目(AHSKYQ2024D014)

Methodology for explosion-proof resilience assessment of continuous stirred tank reactors driven by process parameters

Sun Hao¹(), Huang Jin¹, Shi Jihao²^,³, Wang Fuyu¹, Qi Meng⁴

¹ School of Management Science and Engineering, Anhui University of Technology, Maanshan Anhui 243032, China
² College of Safety and Ocean Engineering, China University of Petroleum (Beijing), Beijing 102249, China
³ Research Centre for Smart Urban Resilience and Firefighting, The Hong Kong Polytechnic University, Hong Kong 999077, China
⁴ College of Chemistry and Chemical Engineering, China University of Petroleum (East China), Qingdao Shandong 266580, China

Received:2026-04-13 Revised:2026-07-10 Published:2026-10-20

摘要/Abstract

摘要：

为预防连续式反应器在运行过程中因热失控而发生的爆炸事故,提出一种融合动态模拟与韧性评估的反应器爆炸事故防控方法。首先,基于反应器运行特性及热失控机制,明确温度、压力等关键工艺参数,系统识别潜在干扰事件;其次,利用Aspen Hysys软件开展动态模拟,分析不同干扰事件下反应器关键工艺参数时变特征,在此基础上,考虑工艺参数多维性与时变特征,基于最优最劣算法(BWM)构建工艺参数驱动的反应器系统韧性评估模型,综合评价反应器防爆韧性;最后,以乙烯与苯制乙苯连续式反应器为例,验证该方法的准确性和适用性。研究结果表明:相较于反应器压力和出口流量,反应器温度受进料温度阶跃变化的影响最为敏感;进料温度的阶跃变化会对反应器系统性能和韧性产生显著的非线性影响,当进料温度分别升高12.5%和62.5%时,反应器系统性能分别降至0.9和0.46,对应的系统韧性分别为0.88和0.82;通过提高反应器防爆韧性,可将关键工艺参数控制在安全阈值之内,从而预防爆炸事故发生。

关键词: 工艺参数, 连续式反应器, 防爆韧性评估, 动态模拟, 系统性能

Abstract:

To effectively prevent explosion accidents in continuous reactors due to thermal runaway during operation, this study proposed a reactor explosion accident prevention method that integrates dynamic simulation and resilience assessment. Firstly, based on the operating characteristics of the reactor and the mechanism of thermal runaway, key process parameters such as temperature and pressure were identified, and potential interference events are systematically recognized. Secondly, dynamic simulation was carried out using ASPEN HYSYS to analyze the time-varying characteristics of key process parameters under different interference events. On this basis, considering the multi-dimensional nature and time-varying characteristics of process parameters, a process parameter-driven resilience assessment model for the reactor system was constructed using the optimal-worst algorithm (BWM), and the overall resilience of the reactor system was evaluated. Finally, targeted resilience improvement strategies were proposed based on the assessment results, thereby preventing explosion accidents in continuous reactors. Taking the continuous reactor as an example, typical interference scenarios were simulated and resilience assessment was conducted to verify the accuracy and applicability of the method. The research results show that by coupling dynamic simulation with resilience assessment, the impact mechanism of interference events on the safety status of the reactor can be systematically revealed. By improving the system resilience, the key process parameters of the reactor can be controlled within the safety threshold, providing a theoretical basis and practical path for the transformation from passive response to active prevention in accident prevention.

Key words: process parameter, continuous stirred tank reactors, explosion-proof resilience assessment, dynamic simulation, system performance

中图分类号:

X932爆炸安全与防火、防爆

孙浩, 黄锦, 师吉浩, 王付宇, 戚萌. 基于工艺参数驱动的连续式反应器防爆韧性评估[J]. 中国安全科学学报, 2026, 36(9): 103-110.

Sun Hao, Huang Jin, Shi Jihao, Wang Fuyu, Qi Meng. Methodology for explosion-proof resilience assessment of continuous stirred tank reactors driven by process parameters[J]. China Safety Science Journal, 2026, 36(9): 103-110.

图/表 10

图1

图2

表1

图3

图4

图5

图6

图7

图8

表2

参考文献 16

[1]	罗梦杰, 赵云鹏, 张梦轩, 等. 大模型时代的石油化工行业高质量数据集:挑战与机遇[J]. 化工学报, 2026, 77(1):435-447,538.
	Luo Mengjie, Zhao Yunpeng, Zhang Mengxuan, et al. High-quality datasets for petrochemical industry in era of large language models: challenges and opportunities[J]. CIESC Journal, 2026, 77(1):435-447,538.
[2]	都亮, 别凯, 赵亚洁, 等. 含平面埋藏缺陷的精制加氢反应器安全评定分析[J]. 中国安全科学学报, 2018, 28(11):86-91. doi: 10.16265/j.cnki.issn1003-3033.2018.11.014
	Du Liang, Bie Kai, Zhao Yajie, et al. Safety assessment of refined hydrogenation reactor with plane embedded defects[J]. China Safety Science Journal, 2018, 28(11):86-91. doi: 10.16265/j.cnki.issn1003-3033.2018.11.014
[3]	陈文涛, 杨茗铠, 王文和, 等. 基于SDG和CBR的化工过程风险评价[J]. 中国安全科学学报, 2025, 35(3):77-84. doi: 10.16265/j.cnki.issn1003-3033.2025.03.1368
	Chen Wentao, Yang Mingkai, Wang Wenhe, et al. Chemical process risk assessment utilizing SDG and CBR methodologies[J]. China Safety Science Journal, 2025, 35(3):77-84. doi: 10.16265/j.cnki.issn1003-3033.2025.03.1368
[4]	张术琳, 王澜凝, 鲁义. 基于动态贝叶斯网络的蒽醌法制备双氧水工艺风险评估[J]. 中国安全科学学报, 2024, 34(2):110-116. doi: 10.16265/j.cnki.issn1003-3033.2024.02.1066
	Zhang Shulin, Wang Lanning, Lu Yi. Risk assessment of hydrogen peroxide production technology by using anthraquinone process based on dynamic Bayesian network[J]. China Safety Science Journal, 2024, 34(2):110-116. doi: 10.16265/j.cnki.issn1003-3033.2024.02.1066
[5]	鲁秋实, 叶光华, 周兴贵. 半间歇釜式反应器安全高效操作的数值优化策略[J]. 化工学报, 2021, 72(2):975-983. doi: 10.11949/0438-1157.20201381
	Lu Qiushi, Ye Guanghua, Zhou Xinggui. Strategy for numerical optimization of safe and efficient operation of semi-batch reactors[J]. CIESC Journal, 2021, 72(2):975-983.
[6]	张春义, 朱戈, 田志勇, 等. 加氢反应器接管法兰密封槽失效原因分析及改进措施[J]. 中国安全科学学报, 2024, 34(12): 100-107. doi: 10.16265/j.cnki.issn1003-3033.2024.12.0102
	Zhang Chunyi, Zhu Ge, Tian Zhiyong, et al. Failure analysis and improvement measures of hydrogenation reactor flange sealing groove[J]. China Safety Science Journal, 2024, 34(12): 100-107. doi: 10.16265/j.cnki.issn1003-3033.2024.12.0102
[7]	Sun Hao, Yang Ming, Zio E, et al. A simulation-based approach for resilience assessment of process system: a case of LNG terminal system[J]. Reliability Engineering and System Safety, 2024, 249: DOI:10.1016/j.ress.2024.110207.
[8]	王海顺, 魏利军, 多英全, 等. 化工过程系统韧性研究进展与展望[J]. 中国安全生产科学技术, 2024, 20(6): 40-49.
	Wang Haishun, Wei Lijun, Duo Yingquan, et al. Research progress and prospects on the resilience of chemical process systems[J]. Journal of Safety Science and Technology, 2024, 20(6): 40-49.
[9]	Pawar B, Huffman M, Khan F, et al. Resilience assessment for fast response process systems[J]. Process Safety and Environmental Protection, 2022, 163: 82-93. doi: 10.1016/j.psep.2022.05.016
[10]	Zhang Yanping, Cai Baoping, Ahmed S, et al. A resilience-driven emergency maintenance operation scheme optimization method based on risk[J]. Reliability Engineering & System Safety, 2025, 254: DOI:10.1016/j.ress.2024.110630.
[11]	孔祥北, 陈思凝, 苏明清, 等. 化工园区安全组织韧性指标体系构建及评估模型研究[J]. 中国安全生产科学技术, 2023, 19(增刊2):27-32.
	Kong Xiangbei, Chen Sining, Su Mingqing, et al. Study on index system construction and evaluation model of safety organization resilience in chemical industry parks[J]. Journal of Safety Science and Technology, 2023, 19(S2):27-32.
[12]	Sun Hao, Yang Ming, Wang Haiqing. An integrated approach to quantitative resilience assessment in process systems[J]. Reliability Engineering & System Safety, 2024, 243: DOI:10.1016/j.ress.2023.109878.
[13]	Zio E. Prognostics and health management (PHM): where are we and where do we (need to) go in theory and practice[J]. Reliability Engineering & System Safety, 2022, 218: DOI:10.1016/j.ress.2021.108119.
[14]	Rezaei J. Best-worst multi-criteria decision-making method[J]. Omega, 2015, 53: 49-57. doi: 10.1016/j.omega.2014.11.009
[15]	Wu Qun, Liu Xinwang, Zhou Ligang, et al. An analytical framework for the best-worst method[J]. Omega, 2024, 123: DOI:10.1016/j.omega.2023.102974.
[16]	Al-Malah K. Aspen plus: chemical engineering applications.[M]. Hoboken: John Wiley & Sons, 2016:155-196.

参数	设定值	参数	设定值
乙烯流量/(kmol/h)	360	反应器压力/MPa	1.50
苯流量/(kmol/h)	720	反应器液位/m	8.64
乙烯和苯进料温度/℃	21.85	反应器容积/m³	60
乙烯和苯进料压力/MPa	2	热传递选项	Dynamic
反应器温度/℃	21.85	介质温度/℃	24.85

严重程度	韧性范围	严重程度	韧性范围
正常,可接受	[0.9,1]	中风险,需控制	[0.6,0.8)
低风险,需关注	[0.8,0.9)	高风险,立即停止	[0,0.6)
