大渡河流域库坝安全监测作业多模式应用实践

doi:10.16265/j.cnki.issn1003-3033.2024.S1.0004

中国安全科学学报 ›› 2024, Vol. 34 ›› Issue (S1): 239-245.doi: 10.16265/j.cnki.issn1003-3033.2024.S1.0004

大渡河流域库坝安全监测作业多模式应用实践

李龙飞(), 高志良, 鲁晨阳

国能大渡河流域水电开发有限公司库坝管理中心, 四川成都 614900

收稿日期:2024-03-21 修回日期:2024-05-25 出版日期:2024-06-30
作者简介:
李龙飞 (1988—),男,吉林榆树人,工程硕士,主要从事安全管理方面的工作。E-mail:277548933@qq.com。

Multi-model application practice of reservoir and dam safety monitoring in Dadu River Basin

LI Longfei(), GAO Zhiliang, LU Chenyang

Reservoir and Dam Management Center of Guoneng Dadu River Basin Hydropower Development Co., Ltd., Chengdu Sichuan 614900, China

Received:2024-03-21 Revised:2024-05-25 Published:2024-06-30

摘要/Abstract

摘要：

为提升大渡河流域库坝安全监测水平,构建库坝智能监测体系,首先,全面分析传统库坝监测作业的问题和难点,然后,系统阐述大渡河流域库坝管理中心的库坝监测作业创新模式。结果表明:大渡河流域库坝管理中心引入三维变形智能监测、北斗卫星高精度变形监测、无人机航测监测、水下无人潜航器监测、智能巡检及深部测斜智能监测等技术,通过技术创新,构建库坝智能安全管控体系。该体系集成多项监测技术,融合分析多源数据,能够实现库坝运行安全风险智能管控及快速应急响应。

关键词: 大渡河流域, 库坝安全, 智能监测, 智能安全管控体系, 监测模式创新

Abstract:

In order to improve the level of reservoir and dam safety monitoring and build an intelligent monitoring system for reservoirs and dams in Dadu River Basin, the problems and difficulties of traditional reservoir and dam monitoring operations were analyzed, and the innovative monitoring mode of reservoir and dam management center in Dadu River Basin was discussed. The results show that the reservoir and dam management center in Dadu River Basin has introduced intelligent three-dimensional (3D) deformation monitoring, Beidou satellite high-precision deformation monitoring, unmanned aerial vehicle (UAV) monitoring, underwater unmanned vehicle monitoring, intelligent patrol, intelligent deep inclination measurement monitoring, and other technologies and has built an intelligent safety management and control system for the reservoir and dam through technology innovation. The system integrates a number of monitoring technologies, integrates and analyzes multi-source data, and can realize intelligent management and control of operational safety risks and rapid emergency response.

Key words: Dadu River Basin, reservoir and dam safety, intelligent monitoring, intelligent safety management and control system, innovative monitoring mode

中图分类号:

X924.2安全监测技术与设备

李龙飞, 高志良, 鲁晨阳. 大渡河流域库坝安全监测作业多模式应用实践[J]. 中国安全科学学报, 2024, 34(S1): 239-245.

LI Longfei, GAO Zhiliang, LU Chenyang. Multi-model application practice of reservoir and dam safety monitoring in Dadu River Basin[J]. China Safety Science Journal, 2024, 34(S1): 239-245.

图/表 7

图1

图2

图3

图4

图5

图6

图7

参考文献 12

[1]	高建, 姚福明, 雷晓辉, 等. 水电梯级开发背景下大渡河干流水质评价及水质分布特征研究[J]. 水利水电技术:中英文, 2021, 52(10): 133-145.
	GAO Jian, YAO Fuming, LEI Xiaohui, et al. Study on water quality evaluation and water quality distribution characteristics of main stream of Daduhe River under background of cascade hydropower development[J]. Water Resources and Hydropower Engineering, 2021, 52(10): 133-145.
[2]	李龙飞, 刘聪, 黄会宝. 大坝安全监测作业风险分析及管控措施[J]. 电力系统设备, 2019(20): 173-175.
	LI Longfei, LIU Cong, HUANG Huibao. Risk analysis and control measures for dam safety monitoring operations[J]. Power Management, 2019(20): 173-175.
[3]	梅风波. 水库大坝安全监测自动化建设研究[J]. 中国设备工程, 2020, 443(7): 173-174.
[4]	王川. 探究自动化技术在水库大坝安全管理中的有效运用[J]. 珠江水运, 2020(15): 81-82.
[5]	黄会宝, 马芳平, 沈定斌, 等. 大渡河流域大坝智能监测探索与实践[J]. 水电与抽水蓄能, 2022, 8(3): 16-22, 34.
	HUANG Huibao, MA Fangping, SHEN Dingbin, et al. Exploration and practice of dam intelligent monitoring in Dadu River basin[J]. Hydropower and Pumped Storage, 2022, 8(3): 16-22, 34.
[6]	程翔. 大型堆石坝内部变形监测关键技术研究[D]. 武汉: 武汉大学, 2023.
	CHENG Xiang. Research on key technology of internal deformation monitoring in large Rock-fill Dam[D]. Wuhan: Wuhan University, 2023.
[7]	谢秉辰, 胡志刚. 基于坐标域的恒星日滤波法及其在北斗变形监测中的应用[J]. 测绘地理信息, 2023, 48(5): 27-31.
	XIE Bingchen, HU Zhigang. A sidereal filtering method based on coordinate domain and its application in BeiDou deformation monitoring[J]. Journal of Geomatics, 2023, 48(5): 27-31.
[8]	程海涛, 刘俊男, 武卓琦, 等. 无人机-人工协同巡视技术体系研究[J]. 中国安全科学学报, 2023, 33(增1): 169-173.
	CHENG Haitao, LIU Junnan, WU Zhuoqi, et al. Research on technical system of UAV and manual cooperative inspection[J]. China Safety Science Journal, 2023, 33(S1): 169-173. doi: 10.16265/j.cnki.issn1003-3033.2023.S1.4007
[9]	王琳琳, 李俊杰, 康飞, 等. 基于无人机图像拼接技术的大坝健康监测方法[J]. 人民长江, 2021, 52(12): 236-240.
	WANG Linlin, LI Junjie, KANG Fei, et al. Dam health monitoring method based on image mosaic technology of Unmanned Aearial Vehicle[J]. Yangtze River, 2021, 52(12): 236-240.
[10]	楚立鹏, 鄢宏华, 范强, 等. 国外水下无人潜航器及其通信技术发展综述[J]. 中国电子科学研究院学报, 2022, 17(2): 112-118.
	CHU Lipeng, YAN Honghua, FAN Qiang, et al. Overview of unmanned underwater vehicles and the communication technologies abroad[J]. Journal of China Academy of Electronics and Information Technology, 2022, 17(2): 112-118.
[11]	王念秦, 申辉辉, 鲁兴生. 边坡变形监测技术发展现状及问题对策[J]. 科学技术与工程, 2021, 21(19): 7 845-7 855.
	WANG Nianqin, SHEN Huihui, LU Xingsheng. Development status and problem countermeasures of slope deformation monitoring technology[J]. Science Technology and Engineering, 2021, 21(19): 7 845-7 855.
[12]	王伟, 张思远, 齐庆杰, 等. 地震诱发井工煤矿次生灾害系统研究[J]. 中国安全科学学报, 2023, 33(7): 196-202. doi: 10.16265/j.cnki.issn1003-3033.2023.07.1699
	WANG Wei, ZHANG Siyuan, QI Qingjie, et al. Study on system of secondary disasters induced by earthquakes in underground coal mine[J]. China Safety Science Journal, 2023, 33(7): 196-202. doi: 10.16265/j.cnki.issn1003-3033.2023.07.1699
