二硫化钼基杂化物对聚合物火灾安全性影响

doi:10.16265/j.cnki.issn1003-3033.2022.01.014

中国安全科学学报 ›› 2022, Vol. 32 ›› Issue (1): 102-109.doi: 10.16265/j.cnki.issn1003-3033.2022.01.014

二硫化钼基杂化物对聚合物火灾安全性影响

周克清¹^,²(), 翟丹阳¹, 印恋¹, 桂宙²^,^**()

¹中国地质大学(武汉) 工程学院,湖北武汉 430074
²中国科学技术大学火灾科学国家重点实验室,安徽合肥 230026

收稿日期:2021-10-22 修回日期:2021-12-05 出版日期:2022-01-28 发布日期:2022-07-28
通讯作者: 桂宙
作者简介:
周克清(1987—),男,安徽安庆人,博士,副教授,主要从事火灾安全控制技术与方法研究。E-mail: zhoukq@cug.edu.cn。
周克清副教授,桂宙研究员
基金资助:
国家自然科学基金资助(22005277); 国家自然科学基金资助(52074247); 安徽省自然科学基金资助(2008085ME180); 广州市科技计划项目(201806010113); 火灾科学国家重点实验室开放课题(HZ2020-KF10)

Influence of molybdenum disulfide based hybrids on fire safety properties of polymer materials

ZHOU Keqing¹^,²(), ZHAI Danyang¹, YIN Lian¹, GUI Zhou²^,^**()

¹Faculty of Engineering, China University of Geosciences (Wuhan), Wuhan Hubei 430074, China
²State Key Laboratory of Fire Science, University of Science and Technology of China, Hefei Anhui 230026, China

Received:2021-10-22 Revised:2021-12-05 Online:2022-01-28 Published:2022-07-28
Contact: GUI Zhou

摘要/Abstract

摘要：

为改善聚合物材料的火灾安全性,利用二硫化钼(MoS₂)的独特性能,结合纳米复合、催化成炭等设计思路,采用共沉淀法制备CeMnO_x-MoS₂和CeFeO_x-MoS₂双金属氧化物-MoS₂纳米杂化物,并将其分别应用到2种典型聚合物(聚氨酯和环氧树脂)中。结果表明:2种杂化物均匀分散在聚合物基体中,可有效延缓聚合物材料的热降解速率、提高残炭率,复合材料燃烧时释放的可燃性气体以及CO等毒性气体和烟密度明显降低,火灾安全性能明显提高。

关键词: 二硫化钼(MoS₂), 杂化物, 分散性, 聚合物材料, 火灾安全性

Abstract:

In order to improve fire safety of polymer materials, considering unique properties of molybdenum disulfide (MoS₂), and based on nanocomposite and catalytic carbonization technology, CeMnO_x-MoS₂ and CeFeO_x-MoS₂ nanohybrids were synthesized by co-precipitation method and then incorporated into two typical polymer matrices (Thermoplastic polyurethane and Epoxy resin). The results indicate that the two kinds of nanohybrids are uniformly distributed in polymer matrix, which effectively delays thermal degradation of polymer materials and increases char residues at high temperature. Moreover, the addition of nanohybrids leads to the decreases of flammable gas, CO and smoke density during combustion of polymer composites, indicating significant improvement of fire safety performance.

Key words: molybdenum disulfide (MoS₂), hybrids, dispersibility, polymer material, fire safety

周克清, 翟丹阳, 印恋, 桂宙. 二硫化钼基杂化物对聚合物火灾安全性影响[J]. 中国安全科学学报, 2022, 32(1): 102-109.

ZHOU Keqing, ZHAI Danyang, YIN Lian, GUI Zhou. Influence of molybdenum disulfide based hybrids on fire safety properties of polymer materials[J]. China Safety Science Journal, 2022, 32(1): 102-109.

图/表 7

图1

图2

图3

图4

图5

图6

图7

参考文献 28

[1]	ZHOU Keqing, TANG Gang, GAO Rui, et al. In situ growth of 0D silica nanospheres on 2D molybdenum disulfide nanosheets: towards reducing fire hazards of epoxy resin[J]. Journal of Hazardous Materials, 2018, 344: 1078-1089. doi: S0304-3894(17)30881-6 pmid: 30216967
[2]	ZHI Maoyong, LIU Quanyi, ZHAO Yinlong, et al. Novel MoS₂-DOPO hybrid for effective enhancements on flame retardancy and smoke suppression of flexible polyurethane foams[J]. Acs Omega, 2020, 5(6):2734-2746. doi: 10.1021/acsomega.9b03346 pmid: 32095697
[3]	王圣程, 张云峰, 禄利刚, 等. 协同改性聚氨酯保温材料的阻燃性能[J]. 中国安全科学学报, 2017, 27(12):14-19. doi: 10.16265/j.cnki.issn1003-3033.2017.12.003
	WANG Shengcheng, ZHANG Yunfeng, LU Ligang, et al. Flame-retardant properties of polyurethane insulation materials modified collaboratively[J]. China Safety Science Journal, 2017, 27(12):14-19. doi: 10.16265/j.cnki.issn1003-3033.2017.12.003
[4]	RICHARD G G, VYTENIS B, STEPHEN J G, NATHAN D M. Hazards of combustion products: toxicity, opacity, corrosivity, and heat release: the experts' views on capability and issues[J]. Fire and Materials, 2011, 35(2):115-127. doi: 10.1002/fam.1043
[5]	韩骥, 单雪影, 邵辉, 等. 改性β-CD的制备及其阻燃环氧树脂研究[J]. 中国安全科学学报, 2020, 30(7):107-113. doi: 10.16265/j.cnki.issn1003-3033.2020.07.016
	HAN Ji, SHAN Xueying, SHAO Hui, et al. Preparation of modified β-CD and flame retardancy of EP[J]. China Safety Science Journal, 2020, 30(7):107-113. doi: 10.16265/j.cnki.issn1003-3033.2020.07.016
[6]	雷天民, 吴胜宝, 张玉明, 等. 单层MoS₂的电子结构及光学性质[J]. 稀有金属材料与工程, 2013, 42(12):2477-2480.
	LEI Tianmin, WU Shengbao, ZHANG Yuming, et al. Electronic structure and optical properties of monolayer MoS₂[J]. Rare Metal Materials and Engineering, 2013, 42(12):2477-2480.
[7]	MOJTABA A, OMID Z, MINOO N. 2D transition metal dichalcogenide nanomaterials: advances, opportunities, and challenges in multifunctional polymer nanocomposites[J]. Journal of Materials Chemistry A, 2020, 8: 845-883. doi: 10.1039/C9TA10130F
[8]	张文钲. 钼酸盐阻燃抑烟剂研发现状[J]. 中国钼业, 2003, 27(1):5-7.
	ZHANG Wenzheng. Current status of research and development for flame retardant and smoke inhibitor of molybdate[J]. China Molybdenum Industry, 2003, 27(1):5-7.
[9]	ZHOU Keqing, LIU Jiajia, WEN Panyue, et al. A noncovalent functionalization approach to improve the dispersibility and properties of polymer/MoS₂ composites[J]. Applied Surface Science, 2014, 316:237-244. doi: 10.1016/j.apsusc.2014.07.136
[10]	ZHAO Ming, LIU Lizhu, ZHANG Bin, et al. Epoxy composites with functionalized molybdenum disulfide nanoplatelet additives[J]. RSC Advances, 2018, 8(61):35 170-35 178. doi: 10.1039/C7RA11259A
[11]	PENG Hongyun, WANG Dong, LI Min, et al. N-P-Zn-containing 2D supermolecular networks grown on MoS₂ nanosheets for mechanical and flame-retardant reinforcements of polyacrylonitrile fiber[J]. Chemical Engineering Journal, 2019, 372: 873-885. doi: 10.1016/j.cej.2019.04.209
[12]	WANG Xin, EHSAN N K, WANG Deyi. An in situ polymerization approach for functionalized MoS₂/nylon-6 nanocomposites with enhanced mechanical properties and thermal stability[J]. Journal of Materials Chemistry A, 2015, 3(47):24 112-24 120.
[13]	FENG Xiaming, XING Weiyi, LIU Jiajia, et al. Reinforcement of organo-modified molybdenum disulfide nanosheets on the mechanical and thermal properties of polyurethane acrylate films[J]. Composites Science and Technology, 2016, 137:188-195. doi: 10.1016/j.compscitech.2016.11.002
[14]	刘惠平, 刘宇婷, 王晗, 等. 硼酸锌对膨胀阻燃聚甲醛的协效阻燃研究[J]. 中国安全科学学报, 2020, 30(5):14-20. doi: 10.16265/j.cnki.issn1003-3033.2020.05.003
	LIU Huiping, LIU Yuting, WANG Han, et al. Synergistic flame-retardant effects of zinc borate in intumescent flame retardant applied on polyoxymethylene[J]. China Safety Science Journal, 2020, 30(5):14-20. doi: 10.16265/j.cnki.issn1003-3033.2020.05.003
[15]	YUAN Yao, WANG Wei, MA Chao, et al. The influence of highly dispersed Cu₂O-anchored MoS₂ hybrids on reducing smoke toxicity and fire hazards for rigid polyurethane foam[J]. Journal of Hazardous Materials, 2020, 382. DOI: 10.1016/j.jhazmat.2019.121028. doi: 10.1016/j.jhazmat.2019.121028
[16]	PENG Hongyun, WANG Dong, ZHANG Liping. Amorphous cobalt borate nanosheets grown on MoS₂ nanosheet for simultaneously improving the flame retardancy and mechanical properties of polyacrylonitrile composite fiber[J]. Composites Part B-Engineering, 2020, 201: DOI: 10.1016/j.compositesb.2020.108298. doi: 10.1016/j.compositesb.2020.108298
[17]	DANIEL D. Catalytic oxidation of carbon monoxide over transition metal oxides[J]. ChemCatChem, 2011, 3:24-65. doi: 10.1002/cctc.201000378
[18]	ZHOU Keqing, LIU Jiajia, HU Yuan, et al. Facile preparation of poly(methyl methacrylate)/MoS₂ nanocomposites via in site emulsion polymerization[J]. Materials Letters, 2014, 126:159-161. doi: 10.1016/j.matlet.2014.04.040
[19]	PENG Hongyun, WANG Dong, FU Shanghai. Tannic acid-assisted green exfoliation and functionalization of MoS₂ nanosheets: significantly improve the mechanical and flame-retardant properties of polyacrylonitrile composite fibers[J]. Chemical Engineering Journal, 2020, 384: DOI:10.1016/j.cej.2019.123288.
[20]	ZHOU Xia, QIU Shuilai, SONG Lei, et al. Construction of hierarchical MoS₂@TiO₂ structure for the high performance bimaleimide system with excellent fire safety and mechanical properties[J]. Chemical Engineering Journal, 2019, 369: 451-462. doi: 10.1016/j.cej.2019.02.181
[21]	刘喜山, 曹博, 纪文斐, 等. 二维层状无机物/硼酸锌复合体系对聚苯乙烯泡沫阻燃性能的影响[J]. 材料工程, 2019, 47(6):101-107.
	LIU Xishan, CAO Bo, JI Wenpei, et al. Effect of two-dimensional layered material/zincborate compounds on flame retardancy of expandable polystrene foams[J]. Journal of Materials Engineering, 2019, 47(6):101-107.
[22]	杨晓昕, 陈奇, 张宏量, 等. 普鲁士蓝/氟化超支化聚氨酯复合涂层材料及其光热转换超疏水性能[J]. 复合材料学报, 2021, 38:1-9.
	YANG Xiaoxin, CHEN Qi, ZHANG Hongliang, et al. Prussian blue/fluorinated hyperbranched polyurethane composite coating material and its photothermal conversion superhydrophobic properties[J]. Acta Materiae Compositae Sinica, 2021, 38:1-9.
[23]	杨海艳, 熊继军, 杜栓丽, 等. 2D MoS₂/高分子纳米复合材料的研究进展[J]. 高分子材料科学与工程, 2019, 35(3):178-184.
	YANG Haiyan, XIONG Jijun, DU Shuanli, et al. Overview on two-dimensional molybdenum disulfide/Polymer nanocomposites[J]. Polymer Materials Science & Engineering, 2019, 35(3):178-184.
[24]	刘贺, 刘春霞, 马凤国. 阻燃型聚氨酯的研究进展[J]. 合成材料老化与应用, 2017, 46(5):113-119.
	LIU He, LIU Chunxia, MA Fengguo. Research progress in flame-retardant polyurethane[J]. Synthetic Materials Aging and Application, 2017, 46(5):113-119.
[25]	CHATTOPADHYAY D K, DEAN C W. Thermal stability and flame retardancy of polyurethanes[J]. Progress in Polymer Science, 2009, 34: 1068-1133. doi: 10.1016/j.progpolymsci.2009.06.002
[26]	叶青, 欧红香, 郭薇, 等. ZIF-8/BC协同膨胀阻燃聚丙烯性能研究[J]. 中国安全科学学报, 2018, 28(11):59-65. doi: 10.16265/j.cnki.issn1003-3033.2018.11.010
	YE Qing, OU Hongxiang, GUO Wei, et al. Study on performance of ZIF-8/BC synergistic intumescent flame retardant for polypropylene[J]. China Safety Science Journal, 2018, 28(11):59-65. doi: 10.16265/j.cnki.issn1003-3033.2018.11.010
[27]	XU Wenzong, LI Aijiao, LIU Yucheng, et al. CuMoO₄@hexagonal boron nitride hybrid: an ecofriendly flame retardant for polyurethane elastomer[J]. Journal of Materials Science, 2018, 53(16): 11 265-11 279.
[28]	WANG Wenhuan, LI Wei, GAO Ruitang, et al. A CeFeO_x catalyst for catalytic oxidation of NO to NO₂[J]. Journal of Rare Earths, 2016, 34(9):876-881. doi: 10.1016/S1002-0721(16)60109-6
