货运动车组安全保障需求及关键技术方案分析

doi:10.16265/j.cnki.issn1003-3033.2022.06.2361

中国安全科学学报 ›› 2022, Vol. 32 ›› Issue (6): 60-65.doi: 10.16265/j.cnki.issn1003-3033.2022.06.2361

货运动车组安全保障需求及关键技术方案分析

梁永廷¹(), 郭鹞¹, 李芳¹, 乔珂²^,^**()

1 中车唐山机车车辆有限公司产品研发中心,河北唐山 063035
2 北京交通大学交通运输学院,北京 100044

收稿日期:2021-12-20 修回日期:2022-04-08 出版日期:2022-06-28 发布日期:2022-12-28
通讯作者: 乔珂
作者简介:
梁永廷 (1979—),男,山西大同人,学士,正高级工程师,主要从事高速铁路新产品技术研发工作。E-mail: sjc-liangyongting@tangche.com。
乔珂,讲师
基金资助:
中国中车重大课题研发计划(2021CDA009)

Analysis of safety guarantee requirements and key technical solutions of freight EMUs

LIANG Yongting¹(), GUO Yao¹, LI Fang¹, QIAO Ke²^,^**()

1 Product Research & Development Center, China Railway Rolling Stock Corporation Tangshan Co., Ltd., Tangshan Hebei 063035, China
2 School of Traffic and Transportation, Beijing Jiaotong University, Beijing 100044, China

Received:2021-12-20 Revised:2022-04-08 Online:2022-06-28 Published:2022-12-28
Contact: QIAO Ke

摘要/Abstract

摘要：

为保障货运动车组(EMUs)的运行安全,从快捷货运的特点和高铁快运的流程出发,探讨货运EMUs在货物装载、加固、搬运、途中管理等方面的安全保障难点问题,分析货运EMUs的安全保障功能需求,设计货运EMUs的标准集装器具方案、虚拟配载整体方案、便捷装卸系统整体方案、货物数据管理系统等安全保障关键技术方案,并验证方案的合理性和可行性。结果表明:货运EMUs安全保障关键技术方案符合我国EMUs的相关技术标准和高铁快运安全要求,能够全程可视化管理货物。

关键词: 货运动车组(EMUs), 高铁快运, 安全保障, 关键技术方案, 虚拟配载

Abstract:

In order to ensure the safe operation of freight EMUs, starting from the characteristics of fast freight and the process of high-speed rail express, the safety and security problems of freight EMUs in loading and unloading, reinforcement, handling and in-transit management of cargos were discussed, and the safety guarantee function requirements of freight EMUs were analyzed. According to the requirements, the key technical solutions for the safety guarantee of the freight EMUs were designed including the standard container equipment solution, the virtual stowage overall solution, the convenient handling system overall solution, and the cargo data management system. The rationality and feasibility of these solutions were verified. The results show that the key technical solutions for the safety guarantee of freight EMUs meet the relevant technical standards of China's EMUs and the safety requirements of high-speed rail express, and can provide support for the whole process of visual security management of cargo.

Key words: freight electric multiple units(EMUs), high-speed rail express, safety guarantee, key technology solutions, virtual stowage

梁永廷, 郭鹞, 李芳, 乔珂. 货运动车组安全保障需求及关键技术方案分析[J]. 中国安全科学学报, 2022, 32(6): 60-65.

LIANG Yongting, GUO Yao, LI Fang, QIAO Ke. Analysis of safety guarantee requirements and key technical solutions of freight EMUs[J]. China Safety Science Journal, 2022, 32(6): 60-65.

图/表 6

表1

图1

图2

图3

图4

图5

参考文献 12

[1]	张钰梅, 张才春, 李海鹰, 等. 利用高速动车组列车开展快捷货运的探讨[J]. 铁道运输与经济, 2013, 35(11):64-70.
	ZHANG Yumei, ZHANG Caichun, LI Haiying, et al. Discussion on developing express freight transportation by high-speed EMUs[J]. Railway Transport and Economy, 2013, 35(11):64-70.
[2]	丁立卿, 熊力, 梁永廷, 等. 高速货运动车组的研制[J]. 中国铁路, 2017(11):91-97.
	DING Liqing, XIONG Li, LIANG Yongting, et al. Development of high-speed freight EMU[J]. China Railway, 2017(11):91-97.
[3]	GERHARD T. High-speed rail freight sub-report in efficient train systems for freight transport[R]. KTH Railway Group, 2005.
[4]	张得志, 郭瑶微, 陈妍, 等. 高铁货物运输安全风险识别与计量[J]. 铁道科学与工程学报, 2019, 16(11):2676-2683.
	ZHANG Dezhi, GUO Yaowei, CHEN Yan, et al. Security risk identification and measurement of high-speed-rail freight transportation[J]. Journal of Railway Science and Engineering, 2019, 16(11):2676-2683.
[5]	蒋建政, 陈再刚, 罗天祺, 等. 货物偏载对高速货运动车组在直线线路上行车安全影响研究[J]. 铁道学报, 2021, 43(6):63-69.
	JIANG Jianzheng, CHEN Zaigang, LUO Tianqi, et al. Study on effect of freight center-of mass offset on running safety of high-speed freight EMUs[J]. Journal of the China Railway Society, 2021, 43(6):63-69.
[6]	刘海涛, 项书峰. 零散快运货物装载加固安全思考[J]. 铁道货运, 2015(10):54-58.
	LIU Haitao, XIANG Shufeng. Thoughts on the safety of loading and reinforcement of scattered and fast freight[J]. Railway Freight Transport, 2015(10):54-58.
[7]	贾宝峰, 阎美好. 铁路快运货物安全预警系统研究[J]. 中国安全科学学报, 2020, 30(增1):121-127.
	JIA Baofeng, YAN Meihao. Research on safety early warning system of railway express freight[J]. China Safety Science Journal, 2020, 30(S1):121-127. doi: 10.16265/j.cnki.issn1003-3033.2020.S1.022
[8]	李杨, 赵楠. 高铁快件业务安全监管分析[J]. 中国安全科学学报, 2018, 28(增2):105-109.
	LI Yang, ZHAO Nan. Analysis on safety supervision strengthening of CRH express fast freight[J]. China Safety Science Journal, 2018, 28(S2):105-109. doi: 10.16265/j.cnki.issn1003-3033.2018.S2.019
[9]	陈宇帆, 蔡正洪. 铁路超限货物判别和安全监测技术应用与发展[J]. 中国铁路, 2021(4): 67-73.
	CHEN Yufan, CAI Zhenghong. Application and development of identification and safety monitoring technology for railway out-of-gauge loading goods[J]. China Railway, 2021(4):67-73.
[10]	GB/T-1413—2008,系列1集装箱分类、尺寸和额定质量[S].
	GB/T-1413-2008,Series1 freight containers- classification, dimensions and ratings[S].
[11]	郭鹞, 苑丰彪, 梁永廷, 等. 高铁快运动车组关键技术需求研究[J]. 铁道机车与动车, 2019(11): 1-3.
	GUO Yao, YUAN Fengbiao, LIANG Yongting, et al. Research on the key technical requirements of high-speed express EMUs[J]. Railway Locomotive and Motor Car, 2019(11):1-3.
[12]	UIC566-1990, Loading of coach bodies and their components[S].

集装器类型	规格尺寸/ mm×mm×mm	自重/ kg	最大载重/kg	最大容积/m³
铝合金	1 150×2 700×2 300	215	625	5.9
铝合金	1 150×2 700×2 000	205	500	4.8
复合材料	1 150×2 700×2 300	175	625	5.9
保鲜	1 150×2 700×2 000	340	420	4.0
冷链	1 150×2 700×2 300	420	430	4.1
