机场飞行区CPS网络建模及韧性评估

doi:10.16265/j.cnki.issn1003-3033.2025.02.0623

摘要/Abstract

摘要：

为评估机场飞行区信息物理系统(CPS)的韧性,并为紧急情况下的快速恢复提供参考,以飞行区管制网为信息网,飞行区滑行路径网为物理网,构建精细化、实时化的机场飞行区CPS网络模型;以西安咸阳机场飞行区CPS为例,针对机场飞行区CPS网络,选取最大连通子图相对值计算网络的连通性,并结合鲁棒性、性能损失和综合韧性指标评估网络韧性;对比不同扰动-恢复策略下的机场飞行区CPS情况,以确定出最佳恢复策略。结果表明:介数扰动对管制网破坏最大,度值扰动对滑行路径网破坏最大;采用介数恢复能够使机场飞行区CPS韧性得到较快恢复;在随机扰动下,机场飞行区CPS网络展现出较高的韧性水平。

关键词: 机场飞行区, 信息物理系统(CPS), 管制网, 网络模型, 韧性评估, 介数扰动, 度值扰动, 最大连通子图相对值

Abstract:

In order to assess the resilience of CPS in airport flight areas and provide a reference for rapid recovery in emergencies, a refined and real-time airport flight area CPS network model with flight area control network as the information network and flight area taxi path network as the physical network was proposed. For CPS network in airfield areas, the connectivity of the network was calculated by selecting the relative values of the largest connected subgraphs. The network's resilience was evaluated by combining robustness, performance loss, and comprehensive resilience indicators. CPS situation in airfield areas under different disturbance recovery strategies was compared to determine the optimal recovery strategy. Taking Xi'an Xianyang Airport flight area CPS as an example, the results show that betweenness perturbation causes the greatest damage to the control network, while degree value perturbation causes the greatest damage to the taxiing path network. Using betweenness recovery can enable faster recovery of CPS resilience in airfield areas, and CPS network of the flight area of the airport shows a higher level of resilience under random perturbation. The research results can simulate and predict relevant nodes and provide certain reference significance for ensuring the safety of flight area operations.

Key words: airport flight zones, cyber-physical system (CPS), control network, network model, resilience assessment, betweeness perturbation, degree value perturbation, maximum connectivity subgraph relative values

中图分类号:

X949

王兴隆, 邱鑫, 魏奕雯. 机场飞行区CPS网络建模及韧性评估[J]. 中国安全科学学报, 2025, 35(2): 49-56.

WANG Xinglong, QIU Xin, Wei Yiwen. Modeling and resilience assessment of CPS network in airfield area[J]. China Safety Science Journal, 2025, 35(2): 49-56.

图/表 7

图1

图2

图3

图4

图5

图6

图7
