Research on dust diffusion characteristics of dragline stacking process in open-pit coal mine

doi:10.16265/j.cnki.issn1003-3033.2023.S2.0005

Abstract

Abstract:

The Heidaigou open-pit coal mine adopts a throwing blasting-dragline stacking process to remove the overlying rock of the coal seam, and the production process has a significant impact on the air quality of the mining pit. In order to effectively control dust, understand the properties and diffusion characteristics of the main atmospheric pollutants in mining pits, and develop effective air quality control measures for mining pits, the method of on-site sampling and testing was used to study the concentration and dispersion of dust generated by loading. On this basis, the numerical simulation method was used to study the dust diffusion process in mining pits. The results show that at a radius of 100 m in the dragline workplace, the highest dust concentration is 12.5 mg/m³, and the respiratory dust concentration is 1.8 mg/m³. The proportion of dust of < 5 μ with the greatest harm to people is 77.2%. Dust first accumulates in the dumping pit and then overflows to the platform where the dragline stands. As the wind speed increases, the maximum diffusion distance of the dust cluster gradually increases, and the position of the maximum dust concentration gradually moves away from the dust production point, moving towards the position where the dragline stands and showing other diffusion characteristics.

Key words: open-pit coal mine, dragline stacking process, dust, diffusion characteristics, numerical simulation

CLC Number:

X936

WANG Yu, JIAO Xiaoliang, ZHAO Changhai, SONG Delin. Research on dust diffusion characteristics of dragline stacking process in open-pit coal mine[J]. China Safety Science Journal, 2023, 33(S2): 188-194.

Figures/Tables 12

Fig.1

Fig.2

Tab.1

Tab.2

Fig.3

Fig.4

Fig.5

Tab.3

Fig.6

Fig.7

Fig.8

Fig.9

References 14

[1]	廖贤鑫, 蒋仲安, 牛伟, 等. 采场爆破粉尘运移规律的Fluent数值模拟[J]. 安全与环境学报, 2012, 12(6):43-46.
	LIAO Xianxin, JIANG Zhongan, NIU Wei, et al. Numerical simulations of blasting dust migration with the use of Fluent in stope[J]. Journal of Safety and Environment, 2012, 12(6):43-46.
[2]	边梦龙. 露天煤矿穿孔与运输作业期间PM2.5粉尘浓度分布规律[J]. 煤矿安全, 2015, 46(4):50-53.
	BIAN Menglong. PM2. 5 dust concentration distribution law of open pit coal mine during perforation and transportion[J]. Safety in Coal Mines, 2015, 46(4):50-53.
[3]	王桂林. 基于FLUENT数值模拟的露天煤矿坑底粉尘浓度分布特征[J]. 煤炭工程, 2020, 52(增2):80-84.
	WANG Guilin. Distribution of dust concentration at the bottom of open-pit coal mine based on fluent simulation[J]. Coal Engineering, 2020, 52(S2):80-84.
[4]	宋子岭, 郭舒鹏, 回晶, 等. 露天煤矿火烧岩采装工作面粉尘逸散规律及抑尘技术[J]. 辽宁工程技术大学学报:自然科学版, 2021, 40(5):401-408.
	SONG Ziling, GUO Shupeng, HUI Jing, et al. Dust emission law and dust suppression technology of working face in burnt rocks of open-pit coal mine[J]. Journal of Liaoning Technical University:Natural Science, 2021, 40(5):401-408.
[5]	龚晓燕, 张浩, 陈龙, 等. 综掘面抽风口调控下的旋流风幕降尘优化[J]. 中国安全科学学报, 2023, 33(6):56-63. doi: 10.16265/j.cnki.issn1003-3033.2023.06.1458
	GONG Xiaoyan, ZHANG Hao, CHEN Long, et al. Optimization of cyclone air curtain dust control under control of exhaust outlet on fully mechanized excavation face[J]. China Safety Science Journal, 2023, 33(6):56-63. doi: 10.16265/j.cnki.issn1003-3033.2023.06.1458
[6]	龚晓燕, 童丹丹, 樊江江, 等. 综掘面风流调控下粉尘双目标优化研究[J]. 中国安全科学学报, 2022, 32(4):44-50. doi: 10.16265/j.cnki.issn1003-3033.2022.04.007
	GONG Xiaoyan, TONG Dandan, FAN Jiangjiang, et al. Study on dual-objective optimization of dust under airflow regulation in fully mechanized faces[J]. China Safety Science Journal, 2022, 32(4):44-50. doi: 10.16265/j.cnki.issn1003-3033.2022.04.007
[7]	丁新启, 张瑞新, 陈再明, 等. 露天煤矿穿孔环节粉尘运移规律模拟仿真研究[J]. 金属矿山, 2022(2):209-215.
	DING Xinqi, ZHANG Ruixin, CHEN Zaiming, et al. Simulation study on dust migration rule in drilling step of open pit coal mine[J]. Metal Mine, 2022(2):209-215.
[8]	郑霞忠, 杨丘, 晋良海, 等. 露天料场爆破粉尘质量浓度时空分布特征数值模拟[J]. 中国安全科学学报, 2020, 30(10):55-62. doi: 10.16265/j.cnki.issn 1003-3033.2020.10.008
	ZHENG Xiazhong, YANG Qiu, JIN Lianghai, et al. Numerical simulation on spatio-temporal distribution regularities of blasting dust mass concentration in open quarry[J]. China Safety Science Journal, 2020, 30(10):55-62. doi: 10.16265/j.cnki.issn 1003-3033.2020.10.008
[9]	郭尧, 孟海利. 路堑深孔爆破粉尘动态扩散数值模拟研究[J]. 铁道工程学报, 2022, 39(7):86-93,101.
	GUO Yao, MENG Haili. Numerical simulation research on the dust dynamic diffusion of cutting deep hole blasting[J]. Journal of Railway Engineering Society, 2022, 39(7):86-93,101.
[10]	鲁文岐, 周伟, 丁小华, 等. 露天矿卡车运输起尘时PM2.5和PM10变化规律研究[J]. 中国煤炭, 2019, 45(11):89-93.
	LU Wenqi, ZHOU Wei, DING Xiaohua, et al. Change law of PM2.5 and PM10 in open-pit coal mine truck transportion[J]. China Coal, 2019, 45(11):89-93.
[11]	陈绍杰, 祁银鸽, 李改革. 压入式通风掘进巷道粉尘悬浮运移规律研究[J]. 煤矿安全, 2022, 53(4):178-182,192.
	CHEN Shaojie, QI Yinge, LI Gaige. Study on dust suspension law in driving roadway with forced ventilation[J]. Safety in Coal Mines, 2022, 53(4):178-182,192.
[12]	王磊, 魏伟, 刘旭东, 等. 基于CFD的风流影响下综采面粉尘沿程污染机制[J]. 煤炭技术, 2022, 41(4):104-108.
	WANG Lei, WEI Wei, LIU Xudong, et al. Dust pollution mechanism in fully mechanized mining face under influence of air flow based on CFD method[J]. Coal Technology, 2022, 41(4):104-108.
[13]	郭玉峰, 郝永江, 李云龙, 等. 综放工作面转载破碎粉尘扩散运移规律分析[J]. 煤炭工程, 2022, 54(2):73-77.
	GUO Yufeng, HAO Yongjiang, LI Yunlong, et al. Dust diffusion and migration law of transferring and crushing point in fully mechanized coal caving face[J]. Coal Engineering, 2022, 54(2):73-77.
[14]	孙健东. 露天矿拉斗铲倒堆工艺系统优化理论及应用研究[D]. 北京: 中国矿业大学(北京), 2016.
	SUN Jiandong. Research on system optimization and application of dragline stripping technology in surface mine[D]. Beijing: China University of Mining & Technology(Beijing), 2016.

序号	全尘浓度/ (mg·m^-3)	呼吸性粉尘/ (mg·m^-3)	PM_2.5/ (μg·m^-3)	PM₁₀/ (μg·m^-3)	生产与环境状况
1	12.5	1.8	752	768	生产,距离约100 m,风速2.5 m/s
2	0.761	0.787	560	423	生产,距离约280 m,风速4 m/s
3	1.447	1.137	538	742	生产,距离约130 m,风速2 m/s
4	0.102	0.219	608	711	未生产,距离100 m,西北风、风速3~5 m/s
5	1.757	0.989	750	760	生产,距离100 m,西南风、风速1.5~3.9 m/s
6	1.898	0.941	750	760	生产,距离100 m,西南240°风速1.5~3.9 m/s
7	10.99	1.598	750	760	生产,距离100 m,迎风时1.5~3.9 m/s

测试地点	数量分散度/%(平均值)				备注
测试地点	<2 μm	2~5 μm	5~10 μm	>10 μm	备注
吊斗铲东北60°	48.7	28.5	18	4.8	工作状态
吊斗铲东北60°	30.5	28.5	23	18	未工作状态

参数	设置
喷射源类型	面喷射
粒径分布	罗森拉姆模型
最小粒径/m	1×10^-6
最大粒径/m	5×10^-5
喷射源材质	无烟煤
喷射源速度/(m·s^-1)	0.5
喷射源质量流率/(kg·s^-1)	0.001
扩散参数	3.5
尘源密度/(kg·m^-3)	1.25×10³
