Eye-tracking-based analysis of walk-around inspection behavioral characteristics in general aviation pilots

doi:10.16265/j.cnki.issn1003-3033.2025.11.0542

Abstract

Abstract:

In order to enhance the proficiency of general aviation pilots in walk-around inspections and ensure aviation safety, eye-tracking technology was employed to measure and analyze the completion rates and fixation behavior characteristics of pilots categorized by experience level. Based on the walk-around checklists and inspection procedures, Diamond DA-40D aircraft was divided into six Areas of Interest (AOI), including the engine, wings, fuselage, landing gear, and empennage. During the participants' walk-around inspections, the completion rates of the walk-around checks and the characteristics of fixation behavior for these six AOI were recorded by means of an eye tracker. The results show that the completion rates of inspections in five AOI, including the empennage, engine, right wing, left wing, and left landing gear, were significantly higher in the veteran group than in the novice group. With the increase in flight experience, the completion rates of general aviation pilots' walk-around inspections gradually improve. Significantly higher total fixation durations and total fixation counts were observed in the experienced group compared to the novice group across five AOI: the engine, right landing gear, right wing, left wing, and left landing gear. A significantly longer average fixation duration on the engine AOI was demonstrated by the novice group relative to the experienced group. Recommendations are provided for training to place greater emphasis on the empennage section, right wing, left wing, and left landing gear areas. Additionally, enhancement of novices' inspection capabilities regarding the engine and left landing gear areas is suggested.

Key words: eye-tracking measurement, general aviation pilots, walk-around inspection, inspection completion rate, fixation behavior characteristics

CLC Number:

X949

WANG Yanqing, ZHANG Chengyue, REN Jingrui, ZHANG Shuhan, LIU Di. Eye-tracking-based analysis of walk-around inspection behavioral characteristics in general aviation pilots[J]. China Safety Science Journal, 2025, 35(11): 42-48.

Figures/Tables 9

Table 1

Fig.1

Fig.2

Table 2

Fig.3

Table 3

Fig.4

Table 4

Fig.5

References 22

[1]	黄静洋, 潘璇, 付小蓉, 等. 中低空通用航空飞行计划安全风险评估[J]. 中国安全科学学报, 2023, 33 (12): 23-30. doi: 10.16265/j.cnki.issn1003-3033.2023.12.1873
	HUANG Jingyang, PAN Xuan, FU Xiaorong, et al. Safety risk assessment for low and medium altitude general aviation flight plans[J]. China Safety Science Journal, 2023, 33(12): 23-30. doi: 10.16265/j.cnki.issn1003-3033.2023.12.1873
[2]	孙卫国, 吕人力, 李凌威, 等. 低空经济面临的机遇、挑战与城市空中交通规划展望[J]. 城市交通, 2025, 23(2): 13-19,127.
	SUN Weiguo, LYU Renli, LI Lingwei, et al. Opportunities and challenges for low-altitude economy and future prospects of urban air mobility planning[J]. Urban Transport of China, 2025, 23(2): 13-19,127.
[3]	中国民用航空局飞行标准司. 通用航空飞行组织与实施安全指南[Z].2021-08-25.
[4]	Federal Aviation Administration (FAA). Advisory circular AC 20-106: aircraft inspection for the general aviation aircraft owner[Z].1978-04-01.
[5]	LOPES N M, NEVES F T, APARICIO M. Key insights from preflight planning for safety improvement in general aviation: a systematic literature review[J]. Applied Sciences, 2024, 14(9): DOI: 10.3390/app14093771.
[6]	WENNER C A, DRURY C G. Analyzing human error in aircraft ground damage incidents[J]. International Journal of Industrial Ergonomics, 2000, 26(2): 177-199. doi: 10.1016/S0169-8141(99)00065-7
[7]	李忠良, 魏麟, 刘晔璐, 等. 飞机外表面地检设备图像处理技术初探[J]. 航空维修与工程, 2018(5): 56-58.
	LI Zhongliang, WEI Lin, LIU Yelu, et al. Preliminary study on image processing technology of ground inspection equipment for aircraft[J]. Aviation Maintenance & Engineering, 2018(5): 56-58.
[8]	李忠良, 袁宇新, 张明月, 等. 基于压缩感知的机体结构图像特征提取技术分析[J]. 电子技术, 2024, 53 (4): 381-383.
	LI Zhongliang, YUAN Yuxin, ZHANG Mingyue, et al. Analysis of feature extraction technology for body structure images based on compressive sensing[J]. Electronic Technology, 2024, 53(4): 381-383.
[9]	ZHANG Di, LIU Zhijun, WANG Xuewen, et al. Research on aircraft patrol inspection method using UAV based on YOLO algorithm[C]. 2024 4^th International Conference on Electronic Information Engineering and Computer (EIECT), 2024: 412-415.
[10]	官剑文. 无人机辅助民航飞机外观检查的应用[J]. 航空维修与工程, 2022 (5): 29-30.
	GUAN Jianwen. The application of UAV in aircraft surface inspection[J]. Aviation Maintenance & Engineering, 2022 (5): 29-30.
[11]	DIDIER A R D, LOZANO T C, MELO D P F, et al. Inspection of aircrafts and airports using UAS: a review[J]. Results in Engineering, 2024, 22: DOI: 10.1016/j.rineng.2024.102330.
[12]	YASUDA Y D V, CAPPABIANCO F A M, MARTINS L E G, et al. Aircraft visual inspection: a systematic literature review[J]. Computers in Industry, 2022, 141: DOI: 10.1016/j.compind.2022.103695.
[13]	中国民用航空局. 一般运行和飞行规则[Z].2022-01-04.
[14]	中国航空运输协会通用航空委员会. 2023—2024年中国通用航空发展报告[R]. 2024.
[15]	BAUMANN C, DIERKES K. Neon accuracy test report[R]. Pupil Labs, 2023.
[16]	DREWS M, DIERKES K. Strategies for enhancing automatic fixation detection in head-mounted eye tracking[J]. Behavior Research Methods, 2024, 56(6): DOI: 10.3758/s13428-024-02360-0.
[17]	SAXENA S, VISRAM A, LOBO N, et al. Social eyes: scaling mobile eye-tracking to multi-person social settings[C]. Proceedings of the 2025 CHI Conference on Human Factors in Computing Systems, 2025. 4: 1-19.
[18]	徐明伟, 金龙哲, 田兴华, 等. 受限空间不同照度环境下VDT作业视觉疲劳[J]. 工程科学学报, 2020, 42 (12): 1605-1612.
	XU Mingwei, JIN Longzhe, TIAN Xinghua, et al. Visual fatigue of VDT operation under different illumination conditions in confined space[J]. Chinese Journal of Engineering, 2020, 42 (12): 1605-1612.
[19]	张欣悦, 吴晓莉, 王名珺, 等. 有/无人机协同操作界面的最佳交互方式评估[J/OL]. 系统工程与电子技术:1-15. [2025-08-06]. https://link.cnki.net/urlid/11.2422.tn.20250326.1413.033.html.
	ZHANG Xinyue, WU Xiaoli, WANG Mingjun, et al. Assessing optimal interaction for a cooperative operation interface of manned/unmanned aerial vehicle[J/OL]. Systems Engineering and Electronics: 1-15.[2025-08-06]. https://link.cnki.net/urlid/11.2422.tn.20250326.1413.033.html.
[20]	汪磊, 王朔, 高杉, 等. 面向特情的航线飞行员视觉注意分配研究[J]. 中国安全科学学报, 2023, 33(1): 214-220. doi: 10.16265/j.cnki.issn1003-3033.2023.01.2167
	WANG Lei, WANG Shuo, GAO Shan, et al. A study on airline pilots' visual attention allocation during emergency[J]. China Safety Science Journal, 2023, 33(1): 214-220. doi: 10.16265/j.cnki.issn1003-3033.2023.01.2167
[21]	柳忠起, 袁修干, 刘伟, 等. 飞行员注意力分配的定量测量方法[J]. 北京航空航天大学学报, 2006, 32(5):518-520, 539.
	LIU Zhongqi, YUAN Xiugan, LIU Wei, et al. Quantitative measuring method of pilots' attention allocation[J]. Journal of Beijing University of Aeronautics and Astronautics, 2006, 32(5): 518-520, 539.
[22]	汪磊, 王朔, 邹颖, 等. 基于任务情境的航线飞行员脑力负荷特征研究[J]. 安全与环境学报, 2023, 23(4): 1202-1208.
	WANG Lei, WANG Shuo, ZOU Ying, et al. A study on airline pilots' mental workload characteristics based on task situation[J]. Journal of Safety and Environment, 2023, 23(4): 1202-1208.

检查区域及编号	检查项目	检查方式/状态
1.前机身	滑油量	量尺检查
	变速箱滑油量	检查
	发动机蒙皮	外观检查
	进气口	无异物
	螺旋桨	检查
	螺旋桨整流罩	外观检查
2.前起落架	前起落架支柱	外观检查
	起落架支柱整流罩	外观检查
	轮胎、轮毂、刹车盘	外观检查
	轮舱整流罩	外观检查
	牵引杆	移走
	轮胎充气压力	压缩量正常,无超量磨损
	轮挡	移走

聚类类别(平均值±标准差)		F	p
类别1	类别2	F	p
0.94±0.04	0.67±0.11	59.11	0.00

AOI		尾翼	发动机	右机翼	右起落架	左机翼	左起落架
检查项数		13	6	16	6	20	4
被试	老手	0.91±0.12	1.00±0.00	0.95±0.05	1.00±0.00	0.93±0.06	0.90±0.32
被试	新手	0.65±0.18	0.39±0.47	0.75±0.12	0.98±0.06	0.64±0.08	0.36±0.49

注视行为指标	被试	发动机	右起落架	右机翼	尾翼	左机翼	左起落架
总注视时间/s	老手	88.10±40.02	8.94±7.76	35.54±17.22	12.50±4.88	40.22±22.55	8.18±5.91
总注视时间/s	新手	69.51±38.50	2.03±1.39	21.48±9.64	13.77±5.43	18.23±3.37	2.59±2.00
总注视次数	老手	166.30±64.27	21.20±9.58	89.90±22.48	33.20±12.01	103.70±30.32	21.00±13.57
总注视次数	新手	93.22±51.82	6.33±3.71	56.33±19.76	40.11±15.07	51.67±11.92	7.11±4.01
平均注视时间/s	老手	0.53±0.17	0.39±0.15	0.38±0.09	0.38±0.10	0.37±0.11	0.37±0.14
平均注视时间/s	新手	0.74±0.27	0.32±0.09	0.38±0.09	0.36±0.10	0.36±0.09	0.34±0.13
平均瞳孔直径/mm	老手	4.35±0.643	4.40±0.69	4.04±0.61	4.66±0.72	4.47±0.71	4.57±0.80
平均瞳孔直径/mm	新手	4.27±0.68	4.24±0.75	3.88±0.63	4.71±0.74	4.34±0.71	4.43±0.68
