考虑结伴行为与情绪感染的人员疏散模型

doi:10.16265/j.cnki.issn1003-3033.2023.11.2286

中国安全科学学报 ›› 2023, Vol. 33 ›› Issue (11): 126-132.doi: 10.16265/j.cnki.issn1003-3033.2023.11.2286

考虑结伴行为与情绪感染的人员疏散模型

霍非舟¹(), 范丹丹¹, 刘昶¹, 马亚萍¹^,^**(), 吕紫含¹^,², 李梦令³

¹ 武汉理工大学安全科学与应急管理学院,湖北武汉 430070
² 武汉理工大学襄阳示范区,湖北襄阳 537134
³ 民机火灾科学与安全工程四川省重点实验室,四川广汉 618307

收稿日期:2023-05-15 修回日期:2023-08-16 出版日期:2023-11-28
通讯作者:
**马亚萍(1989—),女,河南郑州人,博士,副教授,主要从事人员疏散等公共安全与应急管理相关研究。E-mail: mayp18@whut.edu.cn。
作者简介:
霍非舟 (1987—),男,河南周口人,博士,副教授,主要从事人员疏散、风险评估等方面的研究。 E-mail: huofz@whut.edu.cn。
马亚萍副教授
李梦令副研究员
基金资助:
民机火灾科学与安全工程四川省重点实验室项目(MZ2022KF07); 国家自然科学基金资助(51808422); 国家自然科学基金资助(52204233); 中央高校基本科研业务费专项资金项目(2022IVA127)

Study on evacuation model considering companion behavior and emotion contagion

HUO Feizhou¹(), FAN Dandan¹, LIU Chang¹, MA Yaping¹^,^**(), LYU Zihan¹^,², LI Mengling³

¹ School of Safety Science and Emergency Management, Wuhan University of Technology, Wuhan Hubei 430070, China
² Wuhan University of Technology Xiangyang Demonstration Zone, Xiangyang Hubei 537134, China
³ Civil Aircraft Fire Science and Safety Engineering Key Laboratory of Sichuan Province, Guanghan Sichuan 618307, China

Received:2023-05-15 Revised:2023-08-16 Published:2023-11-28

摘要/Abstract

摘要：

为探究结伴行为与情绪感染对人员疏散的影响,将开放性-责任感-外向性-利他性-神经质(OCEAN)模型中的神经质引入易感-感染-易感(SIS)传染病模型,根据行人是否结伴分别构建独立行人与结伴行人的情绪感染模型,与元胞自动机模型相结合进行疏散仿真模拟;并讨论人员密度、结伴比例、情绪阈值、自衰减速率、亲密度等因素对疏散过程的影响特征。研究结果表明:情绪感染在一定程度上会降低疏散效率;行人总体疏散时间与密度呈正相关;疏散时间随结伴比例的增加呈现先增加后降低的趋势,在结伴比例为0.4~0.6时达到峰值,这种趋势受双重因素的影响;情绪阈值是实现平静情绪与恐慌情绪相互转化的临界值,随着情绪阈值的增大,疏散时间逐渐降低,当情绪阈值超过0.3后,疏散时间的变化趋于平缓;情绪自衰减速率与亲密度是影响情绪衰减的主要因素,情绪自衰减速率越大,亲密度越高,情绪强度的衰减越快,且情绪自衰减速率的影响效果更显著。

关键词: 结伴行为, 情绪感染, 疏散模型, 易感-感染-易感(SIS), 传染病模型

Abstract:

In order to study influence of companion behavior and emotion contagion on evacuation, combining of the Openness-Conscientiousness-Extroversion-Agreeableness-Neuroticism (OCEAN) model with SIS model, emotion contagion models of independent pedestrians and companion pedestrians were respectively constructed according to whether pedestrians walk in groups. Then, the emotion contagion model was combined with the cellular automata model to analyze the impacts of personnel density, companion ratio, emotional threshold, decay rate and intimacy on the evacuation process. The results show that emotion contagion reduces the evacuation efficiency, and the evacuation time increases with the increase of density. The evacuation time first increases and then decreases with the increase of the companion ratio, and reaches its peak when the companion ratio is in range of 0.4 to 0.6, and the trend is influenced by two factors. The emotional threshold is the critical value of the mutual transition between calm and panic. As the emotional threshold increases, the evacuation time gradually decreases. When the emotional threshold exceeds 0.3, the change in evacuation time tends to stabilize. The rate of emotional self-decay and intimacy are the main factors affecting emotional decay. The greater the rate of emotional self-decay and the higher the intimacy, the faster the decline of emotional value, and the effect of emotional self-decay rate is more significant.

Key words: companion behavior, emotion contagion, evacuation model, susceptible-infectious-susceptible (SIS), infectious diseases model

霍非舟, 范丹丹, 刘昶, 马亚萍, 吕紫含, 李梦令. 考虑结伴行为与情绪感染的人员疏散模型[J]. 中国安全科学学报, 2023, 33(11): 126-132.

HUO Feizhou, FAN Dandan, LIU Chang, MA Yaping, LYU Zihan, LI Mengling. Study on evacuation model considering companion behavior and emotion contagion[J]. China Safety Science Journal, 2023, 33(11): 126-132.

图/表 10

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

参考文献 12

[1]	陈长坤, 童蕴贺. 基于元胞自动机恐慌状态下人群疏散模型研究[J]. 中国安全生产科学技术, 2019, 15(6):12-17.
	CHEN Changkun, TONG Yunhe. Study on crowd evacuation model under panic state based on cellular automata[J]. Journal of Safety Science and Technology, 2019, 15(6):12-17.
[2]	NIU Yunyun, CHEN Yulin, KONG Detian, et al. Strategy evolution of panic pedestrians in emergent evacuation with assailants based on susceptible-infected-susceptible model[J]. Information Sciences, 2021, 570:105-123. doi: 10.1016/j.ins.2021.04.040
[3]	XIAO Qian, LI Jiayang. Pedestrian evacuation model considering dynamic emotional update in direction perception domain[J]. Complexity, 2021, (4):1-16.
[4]	WANG Guanning, CHEN Tao, CHEN Jinwei, et al. Simulation of crowd dynamics in pedestrian evacuation concerning panic contagion: a cellular automaton approach[J]. Chinese Physics B, 2022, 31(6):285-297.
[5]	CAO Mengxiao, ZHANG Guijuan, WANG Mengsi, et al. A method of emotion contagion for crowd evacuation[J]. Physica A Statal Mechanics & Its Applications, 2017, 483:250-258.
[6]	吴新杰, 王维莉, 胡志华. 突发事件下人群恐慌情绪感染模型与干预方法[J]. 计算机工程与应用, 2020, 56(12):265-272. doi: 10.3778/j.issn.1002-8331.1903-0148
	WU Xinjie, WANG Weili, HU Zhihua. Study on emotion contagion model and intervention strategies of panic in subway stations under emergency[J]. Computer Engineering and Applications, 2020, 56(12):265-272. doi: 10.3778/j.issn.1002-8331.1903-0148
[7]	谢科范, 宋钰, 梁本部. 人群疏散中的恐慌传播与干预策略研究[J]. 管理学报, 2019, 16(2):273-279.
	XIE Kefan, SONG Yu, LIANG Benbu. Panic contagion and intervention strategy in crowd evacuation: from the perspective of complexity science management[J]. Chinese Journal of Management, 2019, 16(2):273-279.
[8]	ZHOU Rui, OU Yi, TANG Weichao, et al. An emergency evacuation behavior simulation method combines personality traits and emotion contagion[J]. IEEE Access, 2020, 8:66693-66 706.
[9]	耿琦, 王维莉. 考虑小群体行为的建筑疏散试验研究[J]. 中国安全科学学报, 2021, 31(8):172-179. doi: 10.16265/j.cnki.issn1003-3033.2021.08.024
	GENG Qi, WANG Weili. Experimental study on pedestrian evacuation considering small group behavior[J]. China Safety Science Journal, 2021, 31(8):172-179. doi: 10.16265/j.cnki.issn1003-3033.2021.08.024
[10]	凤四海, 王志杰, 邓捷, 等. 引入恐慌因素的元胞自动机应急疏散模型[J]. 中国安全科学学报, 2022, 32(4):148-154. doi: 10.16265/j.cnki.issn1003-3033.2022.04.022
	FENG Sihai, WANG Zhijie, DENG Jie, et al. Cellular automata model for emergency evacuation considering panic factor[J]. China Safety Science Journal, 2022, 32(4):148-154. doi: 10.16265/j.cnki.issn1003-3033.2022.04.022
[11]	詹新, 杨立中. 人格特质-人员疏散行为选择的SVM神经网络模型研究[J]. 中国安全科学学报, 2014, 24(5):164-169.
	ZHAN Xin, YANG Lizhong. A SVM neural network model for personality traits-evacuation behavior selection[J]. China Safety Science Journal, 2014, 24(5):164-169.
[12]	霍非舟, 刘昶, 马亚萍, 等. 考虑主动避让行为的养老场所人员疏散研究[J]. 中国安全科学学报, 2022, 32(1):142-148. doi: 10.16265/j.cnki.issn1003-3033.2022.01.019
	HUO Feizhou, LIU Chang, MA Yaping, et al. Study on evacuation in elderly care places considering active avoidance behavior[J]. China Safety Science Journal, 2022, 32(1):142-148. doi: 10.16265/j.cnki.issn1003-3033.2022.01.019
