摘要：

为提高城市洪涝灾害防范和减灾能力,以镇巴县为例,探讨洪涝灾害的耦合成灾过程及风险评估方法。通过分析近年来降雨数据和洪涝灾害统计,揭示该地区洪涝灾害的频发和严重性,以及对经济社会造成的巨大损失。利用无人机技术获取高精度地形数据,并结合土壤和水评估工具(SWAT)进行洪涝模拟,提供准确灾害数据支持。构建基于多要素风险评估矩阵,通过归一化处理得到综合洪涝风险指数。风险评估结果显示:确认14个Ⅳ级风险区域,且模型模拟结果与实际情况吻合度高。研究结果表明:所构建的耦合成灾模拟与风险评估方法能较为准确地识别高风险区域。针对高风险区域提出有效应对措施,包括提升防洪能力、加强监测预警、开展灾害宣传教育以及加强土地规划管理。

关键词: 实景三维, 城市洪涝, 风险评估, 无人机, 土壤和水评估工具(SWAT)

Abstract:

In order to enhance the capacity of urban flood prevention and disaster reduction, taking Zhenba County as an example, this paper explores the coupled disaster formation process and risk assessment methods of flood disasters. By analyzing the rainfall data and flood disaster statistics in recent years, the frequent occurrence and severity of flood disasters in this area as well as the huge losses they have caused to the economy and society were revealed. High-precision terrain data was obtained through unmanned aerial vehicle technology and combined with the SWAT for flood simulation, providing accurate disaster data support. A multi-factor risk assessment matrix was constructed, and the comprehensive flood risk index was obtained through normalization processing. The risk assessment results show that 14 areas with grade IV risks are ide.pngied, and the simulation results of the model are highly consistent with the actual situation. The research results indicate that the constructed coupled disaster formation simulation and risk assessment method can accurately ide.pngy high-risk areas. Effective countermeasures are proposed for high-risk areas, including improving flood control capacity, strengthening monitoring and early warning, conducting disaster prevention and education, and strengthening land planning and management.

Key words: 3D reality modeling, urban flooding, risk assessment, unmanned aerial vehicle, soil and water assessment tool(SWAT)
