多储罐爆炸超压损伤演化过程研究

doi:10.16265/j.cnki.issn1003-3033.2025.11.1175

中国安全科学学报 ›› 2025, Vol. 35 ›› Issue (11): 92-97.doi: 10.16265/j.cnki.issn1003-3033.2025.11.1175

多储罐爆炸超压损伤演化过程研究

李莎莎¹^,²(), 崔铁军¹^,²^,^**()

¹ 沈阳理工大学环境与化学工程学院,辽宁沈阳 110159
² 沈阳理工大学辽宁省安全工程产业学院,辽宁沈阳 110159

收稿日期:2025-07-11 修回日期:2025-09-15 出版日期:2025-11-28
通信作者:
^** 崔铁军教授 (1983—),男,辽宁沈阳人,博士,教授,主要从事系统可靠性及系统故障演化理论方面的研究。E-mail:ctj.159@163.com。
作者简介:
李莎莎副教授 (1988—),女,辽宁盘锦人,博士,副教授,主要从事系统安全与安全管理等方面的研究。E-mail:lsslntu@163.com。
基金资助:
辽宁省属本科高校基本科研业务费专项资金资助(LJ212410144032); 辽宁省科技计划联合计划项目(2025-MSLH-584)

Research on evolution process of explosions-overpressure damage in multiple storage tank

LI Shasha¹^,²(), CUI Tiejun¹^,²^,^**()

¹ School of Environmental and Chemical Engineering, Shenyang Ligong University, Shenyang Liaoning 110159, China
² Liaoning Safety Engineering Industry School, Shenyang Ligong University, Shenyang Liaoning 110159, China

Received:2025-07-11 Revised:2025-09-15 Published:2025-11-28

摘要/Abstract

摘要： 为探究化工园区多储罐同时爆炸引起的事故风险,提出多储罐爆炸超压损伤演化过程研究方法。首先,计算单一储罐爆炸损伤概率和单一储罐爆炸损伤概率;然后,考虑多储罐同时爆炸,研究多储罐爆炸超压损伤演化过程;最后,以某化工园区为例,验证多储罐同时爆炸的区域损伤概率分布。结果表明:演化结果以储罐o₂的区域损伤概率分布为主,后继区域损伤概率分布逐渐减小。研究得到最大损伤概率储罐爆炸顺序集合、对应损伤概率集合和储罐损伤概率分布集合,可计算多储罐同时爆炸的区域损伤概率。初始爆炸时提供的能量差异与储罐爆炸超压损伤演化过程的不同,造成化工园区储罐爆炸过程的复杂性。

关键词: 多储罐爆炸, 损伤演化, 爆炸超压, 区域损伤, 概率分布

Abstract:

In order to study the accident risks caused by the simultaneous explosions of multiple storage tanks in chemical industrial parks, a research method for the overpressure damage evolution process of multiple tank explosions was proposed. First, the explosion damage probability of a single storage tank and the explosion damage probability distribution of a single storage tank were calculated. Then, considering the simultaneous explosions of multiple storage tanks, the overpressure damage evolution process of multiple tank explosions was studied. Finally, the regional damage probability distribution of the simultaneous explosions of multiple storage tanks was obtained. The results show that the evolution result is mainly based on the regional damage probability distribution of Tank o₂, and the subsequent regional damage probability distribution decreases gradually. Through the research, the tank explosion sequence set with the maximum damage probability, the corresponding damage probability set and the tank damage probability distribution set are obtained, and the calculation of the regional damage probability distribution of the simultaneous explosions of multiple storage tanks is realized. The complexity of the storage tank explosion process in chemical industrial parks is caused by the differences in the energy provided during the initial explosion and the differences in the overpressure damage evolution process of storage tank explosions.

Key words: multi-tank explosion, damage evolution, explosion overpressure, regional damage, probability distribution

中图分类号:

X937

李莎莎, 崔铁军. 多储罐爆炸超压损伤演化过程研究[J]. 中国安全科学学报, 2025, 35(11): 92-97.

LI Shasha, CUI Tiejun. Research on evolution process of explosions-overpressure damage in multiple storage tank[J]. China Safety Science Journal, 2025, 35(11): 92-97.

图/表 6

表1

储罐中存放的物质参数

储罐	物质	x/m	y/m	体积/ m³	密度/ (kg·m^-3)	物体燃烧热 Q_f/(kJ·kg^-1)	类型
$o 1$	汽油	200	800	1000	730	41868	高压
$o 2$	柴油	900	100	2000	850	40320	常压
$o 3$	乙醇	700	700	900	800	22890	高压
$o 4$	乙醇	500	450	1500	800	22890	高压

表1

图1

图2

图3

图4

图5

参考文献 17

[1]	王艳华, 戴雪松, 鲜鱼小东, 等. 化学工业重大事故的多米诺效应分析[J]. 中国安全科学学报, 2008, 18(5):129-136.
	WANG Yanhua, DAI Xuesong, XIANYU Xiaodong, et al. Analysis on domino effect of major accidents in chemical industry[J]. China Safety Science Journal, 2008, 18(5):129-136.
[2]	段仁武, 李展, 颜海春, 等. 火灾条件下开敞空间LPG储罐的BLEVE试验[J]. 爆炸与冲击, 2023, 43(12):156-167.
	DUAN Renwu, LI Zhan, YAN Haichun, et al. Experimental study of LPG storage tank BLEVE in unconfined space under fire[J]. Explosion and Shock Waves, 2023, 43(12):156-167.
[3]	赵景斌, 王彦富, 王涛, 等. 基于蒙特卡洛模拟和动态事件树的储罐脆弱性评估[J]. 化工进展, 2023, 42(5):2751-2759. doi: 10.16085/j.issn.1000-6613.2022-1376
	ZHAO Jingbin, WANG Yanfu, WANG Tao, et al. Vulnerability assessment of storage tanks based on Monte Carlo simulation and dynamic event tree[J]. Chemical Industry and Engineering Progress, 2023, 42(5): 2751-2759. doi: 10.16085/j.issn.1000-6613.2022-1376
[4]	门金龙, 亢方超, 熊碧波, 等. 基于优化TNT当量法的LPG储罐爆炸冲击波超压预测[J]. 消防科学与技术, 2023, 42(5):622-627.
	MEN Jinlong, KANG Fangchao, XIONG Bibo, et al. Calculation of LPG storage tank explosion shock wave overpressure based on optimized TNT equivalent method[J]. Fire Science and Technology, 2023, 42(5):622-627.
[5]	李敏, 朱柏坚, 谌庭苇, 等. 近20年重特大化工生产事故统计分析[J]. 中国安全科学学报, 2024, 34 (11): 43-50. doi: 10.16265/j.cnki.issn1003-3033.2024.11.0437
	LI Min, ZHU Baiian, CHEN Tingwei, et al. Stalistical analysis of major chemical work safety accidents in recent 20 years[J]. China Safety Science Journal, 2024, 34(11):43-50. doi: 10.16265/j.cnki.issn1003-3033.2024.11.0437
[6]	姜子建, 周荣义, 石云霄, 等. 基于贝叶斯网络的危化品爆炸事故隐患关联与溯源分析[J]. 中国安全科学学报, 2024, 34 (6): 173-180. doi: 10.16265/j.cnki.issn1003-3033.2024.06.1848
	JIANG Zijian, ZHOU Rongyi, SHI Yunxiao, et al. Corelation and traceability analysis of hazardous chemical explosion accidents based on Bayesian network[J]. China Safety Science Joumal, 2024, 34(6).173-180.
[7]	游波, 罗骁, 施式亮, 等. LNG储罐泄漏扩散模拟分析[J]. 中国安全科学学报, 2023, 33 (2): 125-131. doi: 10.16265/j.cnki.issn1003-3033.2023.02.0332
	YOU Bo, LUO Xiao, SH Shiliang, et al. Simulation analysis of leakage and diffusion in LNG storage tank[J]. China Safety Science Joumal, 2023, 33 (2): 125-131.
[8]	WANG Cheng, SONG Shixiang, GU Gongtian, et al. Fireball distribution characteristics and thermal radiation effects in the explosion of aviation kerosene storage tank[J]. Process Safety and Environmental Protection, 2024, 192: 707-718. doi: 10.1016/j.psep.2024.10.066
[9]	SONG Shixiang, WANG Cheng, QIAO Boyang, et al. Explosion damage effects of aviation kerosene storage tank under strong ignition[J]. Defence Technology, 2024, 37: 27-38. doi: 10.1016/j.dt.2023.12.009
[10]	DINESH M, BO C O. Computational study of a high-pressure hydrogen storage tank explosion at different heights from the ground[J]. International Journal of Hydrogen Energy, 2024, 50: 1245-1260. doi: 10.1016/j.ijhydene.2023.10.138
[11]	LUO Weiye, BI Mingshu, ZHANG Yue, et al. Multi-factor coupling analysis and identification of tanks BLEVE[J]. Process Safety and Environmental Protection, 2023, 177:880-890. doi: 10.1016/j.psep.2023.07.034
[12]	JIAO Yu, CHEN Ran, WANG Kan, et al. Simulation of scenario characteristics of LPG tank explosion accident and its contribution to emergency planning: a case study[J]. Journal of Loss Prevention in the Process Industries, 2023, 83:DOI:10.1016/J.JLP.2023.105066.
[13]	王洪德, 崔铁军. 化工园区火灾爆炸风险网格矩阵叠加分析[J]. 系统工程理论与实践, 2012, 32(5):1143-1150. doi: 10.12011/1000-6788(2012)5-1143
	WANG Hongde, CUI Tiejun. Superposition analysis of explosion risks in chemical industrial parks based on grid matrix method[J]. Systems Engineering-Theory & Practice, 2012, 32(5):1143-1150.
[14]	王洪德, 崔铁军. 化工园区初始火灾爆炸引发连锁事故概率研究[J]. 安全与环境学报, 2011, 11(4):158-163.
	WANG Hongde, CUI Tiejun. Probability of the chain-fire accidents originated from the explosion in chemical industry parks[J]. Journal of Safety and Environment, 2011, 11(4):158-163.
[15]	COZZANI V, ANTONIONI G, SPADONI G. Quantitative assessment of domino scenarios by a GIS-based software tool[J]. Journal of Loss Prevention in the Process Industries, 2006, 19(5): 463-477. doi: 10.1016/j.jlp.2005.11.007
[16]	COZZANI V, GUBINELLI G, ANTONIONI G, et al. The assessment of risk caused by domino effect in quantitative area risk analysis[J]. Journal of Hazardous Materials, 2005, 127(1/2/3): 14-30. doi: 10.1016/j.jhazmat.2005.07.003
[17]	崔铁军, 李莎莎. 基于储罐爆炸损伤演化的化工园区社会风险分布研究[J]. 灾害学, 2024, 39(3):43-47.
	CUI Tiejun, LI Shasha. Research on the social risk distribution of chemical industry parks based on tank explosion damage evolution[J]. Journal of Catastrophology, 2024, 39(3):43-47.
