基于FRAM-PLTS扫地机器人-取暖器火灾事故分析

doi:10.16265/j.cnki.issn1003-3033.2025.12.0449

摘要/Abstract

摘要：

针对智能家电产品安全风险问题,以某地2起扫地机器人-取暖器火灾事故为研究对象,采用基于功能共振分析法(FRAM)和概率语言术语集(PLTS)的集成方法,开展系统性的风险分析。运用FRAM分析事故,得到包括导航模块、避障传感器模块、运动控制模块等在内的9大核心功能模块;通过引入PLTS量化确定功能模块输入端、输出端主要表型,确定扫地机器人-取暖器致灾系统中导致事故的4个功能共振模块。研究结果表明:传感器精度不足和用户未执行“人走断电”等是事故的主要原因;屏障体系包括物理屏障、功能屏障、无形屏障和象征屏障。

关键词: 扫地机器人, 取暖器, 功能共振分析法(FRAM), 概率语言术语集(PLTS), 火灾事故, 屏障体系

Abstract:

To address the safety risk issues of smart household appliance products, a systematic risk analysis was conducted by taking two sweeping robot-heater fire accidents in a certain location as the research subjects. An integrated method combining the FRAM and PLTS was adopted. FRAM was applied to analyze the accidents, through which nine core functional modules were identified, including navigation module, obstacle avoidance sensor module, and motion control module. Subsequently, PLTS was introduced to quantitatively determine the main characteristics of the input and output terminals of each functional module. Based on this quantitative analysis, four functional resonance modules that led to the accidents in the sweeping robot-heater were confirmed. The results show that the primary causes of the accidents include insufficient sensor accuracy and failure of users to implement the "power-off when leaving" operation. Additionally, the barrier system for risk prevention and control is identified, which consists of physical barriers, functional barriers, intangible barriers, and symbolic barriers.

Key words: sweeping robots, heaters, functional resonance analysis method (FRAM), probabilistic linguistic term set (PLTS), fire accident, barrier system

中图分类号:

X928.7火灾与爆炸事故

黄国忠, 左志勇, 邓青, 陈寒熙格, 曹正凯. 基于FRAM-PLTS扫地机器人-取暖器火灾事故分析[J]. 中国安全科学学报, 2025, 35(12): 180-186.

HUANG Guozhong, ZUO Zhiyong, DENG Qing, CHEN Hanxige, CAO Zhengkai. Fire accident analysis of sweeping robot-heater based on FRAM-PLTS[J]. China Safety Science Journal, 2025, 35(12): 180-186.

图/表 8

表1

表2

图1

表3

表4

表5

表6

表7

参考文献 22

[1]	日本东京今冬发生数起扫地机器人引发的火灾[EB/OL]. (2019-02-19). http://japan.people.com.cn/n1/2019/0219/c35421-30806049.html.
[2]	出趟门回来家被烧了,火场“真凶”竟是扫地机器人[N/OL]. 广州日报, 2024-03-19. https://news.qq.com/rain/a/20240319A09CKL00.
[3]	王超. 基于ROS的移动机器人全遍历路径规划研究[D]. 南昌: 南昌大学, 2022.
	WANG Chao. Research on full traversal path planning of mobile robot based on ROS[D]. Nanchang: Nanchang University, 2022.
[4]	申浩阳. 面向复杂空间的移动机器人路径规划问题研究[D]. 郑州: 郑州轻工业大学, 2022.
	SHEN Haoyang. Research on path planning for mobile robots in complex space[D]. Zhengzhou: Zhengzhou University of Light Industry, 2022.
[5]	刘琪亮, 叶哲闽, 吴圣龙, 等. 基于LoRa协议的扫地机器人路径区域规划[J]. 电脑知识与技术, 2022, 18(33):21-24.
[6]	谢志利, 裴广福, 魏明然. 扫地机器人跌落风险评估与测试[J]. 家电科技, 2018, 394(11):75-77,85.
	XIE Zhili, PEI Guangfu, WEI Mingran. Sweeping robot drop risk assessment and testing[J]. Journal of Appliance Science and Technology, 2018, 394(11): 75-77, 85.
[7]	邹伟, 梅飞翔, 王健, 等. 扫地机器人滚刷防缠绕技术研究[C]. 2022年中国家用电器技术大会论文集, 2023:2051-2060.
[8]	ZHANG Yanxi, LIU Tiezhong. Risk assessment based on a STPA-FMEA method: a case study of a sweeping robot[J]. Risk Analysis, 2023, 43(3): 590-604. doi: 10.1111/risa.v43.3
[9]	HOLLNAGEL E. Barriers and accident prevention[M]. London and New York: Routledge, 2016: 34-56.
[10]	高扬, 徐佳迪, 武文涛, 等. 基于FRAM-AHP法的公务航空飞行事故分析[J]. 安全与环境学报, 2019, 19(3):754-760.
	GAO Yang, XU Jiadi, WU Wentao, et al. Analysis for the accidents of business aviation flight based on the FRAM-AHP method[J]. Journal of Safety and Environment, 2019, 19(3):754-760.
[11]	潘恒毅. 基于FRAM-MC的船员疲劳事故研究[J]. 江西师范大学学报:自然科学版, 2023, 47(2):206-215.
	PAN Hengyi. The study of crew fatigue accidents based on FRAM-MC[J]. Journal of Jiangxi Normal University: Natural Science, 2023, 47(2): 206-215.
[12]	王涵宇, 谭钦文. 基于FRAM的有限空间作业安全职责半定量分析[J]. 中国安全科学学报, 2023, 33(5):88-95. doi: 10.16265/j.cnki.issn1003-3033.2023.05.1382
	WANG Hanyu, TAN Qinwen. Semi-quantitative analysis of safety duties in confined space operations based on FRAM[J]. China Safety Science Journal, 2023, 33(5): 88-95. doi: 10.16265/j.cnki.issn1003-3033.2023.05.1382
[13]	栗婧, 柳慧妍, 宫梓超, 等. 采用改进FRAM模型方法的管道爆裂事故分析[J]. 安全与环境学报, 2024, 24(4):1460-1468.
	LI Jing, LIU Huiyan, GONG Zichao, et al. Analysis of pipeline burst accident based on improved FRAM model[J]. Journal of Safety and Environment, 2024, 24(4): 1460-1468.
[14]	PANG Qi, WANG Hai, XU Zeshui. Probabilistic linguistic term sets in multi-attribute group decision making[J]. Information Sciences, 2016, 369: 128-143. doi: 10.1016/j.ins.2016.06.021
[15]	连猛猛. 基于PLTS的多属性群决策方法及其在医疗决策中的应用研究[D]. 开封: 河南大学, 2024.
	LIAN Mengmeng. Research on multi-attribute group decision-making method based on PLTS and its application in medical decision-making[D]. Kaifeng: Henan University, 2024.
[16]	王怡君. 基于改进的FRAM地铁车站施工安全事故致因分析[D]. 武汉: 武汉科技大学, 2023.
	WANG Yijun. Safety accident cause analysis in subway station construction based on improved FRAM[D]. Wuhan: Wuhan University of Science and Technology, 2023.
[17]	张杨薇. 基于FRAM的危险化学品道路运输系统恢复力提升研究[D]. 北京: 中国地质大学(北京), 2018.
	ZHANG Yangwei. Research on resilience improvement of road transportation system of dangerous chemicals based on FRAM[D]. Beijing: China University of Geosciences (Beijing), 2018.
[18]	YANG Jinhui, ZHAO Jin, SHAO Liangshan. Risk assessment of coal mine gas explosion based on fault tree analysis and fuzzy polymorphic Bayesian network: a case study of Wangzhuang coal mine[J]. Processes, 2023, 11: DOI:10.3390/pr11092619.
[19]	XU Zeshui. Deviation measures of linguistic preference relations in group decision making[J]. Omega, 2005, 33(3): 249-254. doi: 10.1016/j.omega.2004.04.008
[20]	谭谨. 有关模糊语言的多属性决策方法研究[D]. 南昌: 江西师范大学, 2023.
	TAN Jin. Research on multi-attribute decision-making method of fuzzy language[D]. Nanchang: Jiangxi Normal University, 2023.
[21]	GOU Xunjie, XU Zeshui. Novel basic operational laws for linguistic terms, hesitant fuzzy linguistic term sets and probabilistic linguistic term sets[J]. Information Sciences, 2016, 372: 407-427. doi: 10.1016/j.ins.2016.08.034
[22]	WU Xingli, LIAO Huchang. A consensus-based probabilistic linguistic gained and lost dominance score method[J]. European Journal of Operational Research, 2019, 272(3): 1017-1027. doi: 10.1016/j.ejor.2018.07.044

来源	简称	功能模块编号	描述
扫地机器人	导航模块	FM1	负责根据传感器数据规划移动路径
	避障传感器模块	FM2	依赖红外、激光或视觉传感器检测障碍物
	运动控制模块	FM3	控制扫地机器人转向和动力输出
	扫地机器人电源模块	FM4	扫地机器人的电源管理模块
取暖器	加热控制模块	FM5	调节温度输出
取暖器	取暖器电源模块	FM6	取暖器的电源管理模块
用户行为	用户响应功能	FM7	用户未在出现险情第一时间响应
	设备监管功能	FM8	用户未遵守“人走断电”原则
	设备维护功能	FM9	未定期检查扫地机器人、取暖器

要素	描述	解释
I	险情信号	传感器检测到异常传递给用户,或者险情本身被用户直接发现
O	险情响应断电	用户通过APP远程断电或手动关闭设备,切断电源避免事故
R	感知设备;用户身体机能	设备:传感器、智能终端;机能:视觉/听觉感知、手部操作能力
C	响应优先级	用户接收到不同险情信号后,响应的顺序
P	险情可以被感知;用户处于“可响应状态”	信号未被屏蔽;用户清醒且无行动障碍
T	响应时间窗口	从险情信号输入到用户响应的时间窗口

专家	工作经验	专业相关度	信心指数	教育背景	总分	权重
Z₁	9	9	9	9	36	36/98
Z₂	7	8	8	9	32	32/98
Z₃	8	7	7	8	30	30/98

功能模块编号	F	D	A	Q	主要表型
FM1	0.739	0.244	0.787	0.561	A
FM2	0.752	0.373	0.809	0.329	A
FM4	0.074	0.876	0.256	0.454	D
FM6	0.106	0.859	0.262	0.439	D
FM7	0.101	0.738	0.385	0.443	D
FM8	0.234	0.615	0.454	0.731	Q
FM9	0.357	0.632	0.451	0.242	D

功能模块编号	I	R	C	T	P	主要表型
FM1	0.817	0.761	0.745	0.278	0.347	I
FM2	0.443	0.798	0.732	0.249	0.307	R
FM3	0.673	0.781	0.711	0.306	0.352	R
FM4	0.210	0.370	0.828	0.754	0.436	C
FM5	0.640	0.637	0.516	0.742	0.197	T
FM6	0.114	0.185	0.803	0.740	0.312	C
