Slope stability prediction model based on multi-strategy improved SSA for optimizing KELM

doi:10.16265/j.cnki.issn1003-3033.2025.03.0134

Abstract

Abstract:

In order to predict the slope state more accurately and effectively prevent the slope instability accident, an improved ISSA-KELM slope stability prediction model was proposed. Firstly, six main factors such as bulk density and cohesion in slope instability characteristics were used as prediction indexes to establish a data set for slope stability evaluation. Secondly, SSA was enhanced by incorporating Sine chaotic mapping, Levy flight strategy, dynamic adaptive weights, and fusion of optimal explosion strategy and reverse learning. These improvements aimed at enhancing the global search capability and stability of SSA. Subsequently, ISSA was employed to optimize the kernel parameter ψ and regularization coefficient C in KELM for improved prediction accuracy while avoiding overfitting issues associated with KELM. The results show that the accuracy rate, precision, recall rate and F₁ score of ISSA-KELM model reached 0.945 9, 1, 0.866 7 and 0.929, respectively, which are superior to SSA-KELM, PSO-KELM and PSO-SVM models, and the predicted results of the model are the closest to the actual values. It shows that the established ISSA-KELM model has strong generalization ability.

Key words: slope stability, prediction model, improved sparrow search algorithm (ISSA), kernel extreme learning machine (KELM), prediction index, confusion matrix

CLC Number:

X936

QI Yun, XUE Kailong, LI Xuping, WANG Wei, BAI Chenhao, JI Zhunze. Slope stability prediction model based on multi-strategy improved SSA for optimizing KELM[J]. China Safety Science Journal, 2025, 35(3): 92-98.

Figures/Tables 10

Table 1

Standard test function

测试函数	维度	取值范围
$f 1 = - ∑ i = 1 n (x i s i n (\| x i \|))$	30	[-500, 500]
$f 2 = ∑ i = 1 n [x i 2 - 10 c o s (2 π x i + 10)]$	30	[-5.12, 5.12]
$f 3 = - ∑ i = 1 n [(x - a i) (x - a i) T + c i] - 1$	30	[0, 10]
$f 4 = ∑ i = 1 n a i - x 1 (b i 2 + b i x 2) b i 2 + b i x 3 + x 4$	30	[-5, 5]

Table 1

Fig.1

Table 2

Fig.2

Table 3

Fig.3

Fig.4

Table 4

Table 5

Fig.5

References 13

[1]	WEI Zhenlei, LU Qing, SUN Hongyue, et al. Estimating the rainfall threshold of a deep seated landslide by integrating models for predicting the groundwater level and stability analysis of the slope[J]. Engineering Geology, 2019, 253: 14-26. doi: 10.1016/j.enggeo.2019.02.026
[2]	胡少伟, 李原昊, 单常喜, 等. 基于改进的PSO-BP神经网络的边坡稳定性研究[J]. 防灾减灾工程学报, 2023, 43(4):854-861.
	HU Shaowei, LI Yuanhao, SHAN Changxi, et al. Research on slope stability based on improved PSO-BP neural network[J]. Journal of Disaster Prevention and Mitigation Engineering, 2023, 43(4):854-861.
[3]	KARDANI N, ZHOU Annan, NAZEM M, et al. Improved prediction of slope stability using a hybrid stacking ensemble method based on finite element analysis and field data[J]. Journal of Rock Mechanics and Geotechnical Engineering, 2021, 13(1):188-201.
[4]	薛建凯. 一种新型的群智能优化技术的研究与应用[D]. 上海: 东华大学, 2020.
	XUE Jiankai. Research and application of a new swarm intelligent optimization technique[D]. Shanghai: Donghua University, 2020.
[5]	SEYEDALI M. SCA: a sine cosine algorithm for solving optimization problems[J]. Knowledge-Based Systems, 2016, 96: 120-133.
[6]	余修武, 彭威, 余员琴, 等. 基于SSO的铀尾矿库无线传感器网络定位算法[J]. 中国安全科学学报, 2023, 33(4):84-90. doi: 10.16265/j.cnki.issn1003-3033.2023.04.0264
	YU Xiuwu, PENG Wei, YU Yuanqin, et al. Localization algorithm for uranium tailings reservoir based on SSO in wireless sensor network[J]. China Safety Science Journal, 2023, 33(4): 84-90. doi: 10.16265/j.cnki.issn1003-3033.2023.04.0264
[7]	毛清华, 张强. 融合柯西变异和反向学习的改进麻雀算法[J]. 计算机科学与探索, 2021, 15(6):1155-1164. doi: 10.3778/j.issn.1673-9418.2010032
	MAO Qinghua, ZHANG Qiang. Improved sparrow algorithm combining Cauchy mutation and opposition-based learning[J]. Journal of Frontiers of Computer Science and Technology, 2021, 15(6): 1155-1164.
[8]	吴大飞, 杨光永, 樊康生, 等. 多策略融合的改进粒子群优化算法[J]. 计算机应用研究, 2022, 39(11):3358-3364.
	WU Dafei, YANG Guangyong, FAN Kangsheng, et al. Improved particle swarm optimization algorithm with muti-strategy fusion[J]. Application Research of Computers, 2022, 39(11):3358-3364.
[9]	HUANG Guangbin, ZHOU Hongming, DING Xiaojian, et al. Extreme learning machine for regression and multiclass classification[J]. IEEE Transactions on Systems, Man, and Cybernetics, Part B (Cybernetics), 2012, 42(2); 513-529.
[10]	FENG Xianda, LI Shuchen, YUAN Chao, et al. Prediction of slope stability using naive Bayes classifier[J]. KSCE Journal of Civil Engineering, 2018, 22(3): 941-950.
[11]	SAMUI P. Support vector classifier analysis of slope[J]. Geomatics, Natural Hazards and Risk, 2013, 4 (1): 1-12.
[12]	张凯, 张科. 基于LightGBM算法的边坡稳定性预测研究[J]. 中国安全科学学报, 2022, 32(7):113-120. doi: 10.16265/j.cnki.issn1003-3033.2022.07.1473
	ZHANG Kai, ZHANG Ke. Prediction study on slope stability based on LightGBM algorithm[J]. China Safety Science Journal, 2022, 32(7):113-120. doi: 10.16265/j.cnki.issn1003-3033.2022.07.1473
[13]	祁云, 薛凯隆, 汪伟, 等. 矿井煤与瓦斯突出事故应急救援能力评估模型[J]. 中国安全科学学报, 2024, 34(2):225-230. doi: 10.16265/j.cnki.issn1003-3033.2024.02.0983
	QI Yun, XUE Kailong, WANG Wei, et al. Assessment model of emergency response capability for coal and gas outburst accidents in mines[J]. China Safety Science Journal, 2024, 34(2): 225-230. doi: 10.16265/j.cnki.issn1003-3033.2024.02.0983

预测结果	实际结果
预测结果	破坏	稳定
破坏	TP	FP
稳定	FN	TN

编号	γ/ (kN·m^-3)	c /kPa	φ/ (°)	β/ (°)	H /m	r_u/ kPa
1	17.93	78.20	18.49	33.42	120.79	0.00
2	18.02	40.92	21.18	21.86	21.86	0.10
︙	︙	︙	︙	︙	︙	︙
149	21.03	0.00	17.72	5.79	57.31	0.00
150	25.74	0.00	17.23	30.03	80.53	0.40
151	22.40	10.00	35.00	45.00	10.00	0.40
152	19.63	11.98	20.00	22.00	12.19	0.25
︙	︙	︙	︙	︙	︙	︙
256	18.84	14.36	25.00	20.00	30.50	0.45
257	19.97	19.96	36.00	45.50	50.00	0.50

模型	模型性能
模型	A_c	P	R	F₁
ISSA-KELM	0.980 8	1	0.966 7	0.983
SSA-KELM	0.942 3	0.965 5	0.933 3	0.949
PSO-KELM	0.884 6	0.928 6	0.866 7	0.897
PSO-SVM	0.826 9	0.920 0	0. 766 7	0.836

模型	模型性能
模型	A_c	P	R	F₁
ISSA-AKELM	0.945 9	1	0.866 7	0.929
SSA-AKELM	0.916 7	0.923 0	0.857 1	0.889
PSO-AKELM	0.864 9	0.857 1	0.800 0	0.828
PSO-ASVM	0.810 8	0.785 7	0.733 3	0.828
