装配式建筑施工风险评价模型构建及应用

doi:10.16265/j.cnki.issn1003-3033.2022.10.2119

中国安全科学学报 ›› 2022, Vol. 32 ›› Issue (10): 69-75.doi: 10.16265/j.cnki.issn1003-3033.2022.10.2119

装配式建筑施工风险评价模型构建及应用

王丹(), 梁靖涵^**()

辽宁工程技术大学工商管理学院,辽宁葫芦岛 125105

收稿日期:2022-04-13 修回日期:2022-08-12 出版日期:2022-10-28 发布日期:2023-04-28
通讯作者: 梁靖涵
作者简介:
王丹 (1978—),女,辽宁铁岭人,博士,教授,博士生导师,主要从事工程项目安全与风险管理等方面的研究。E-mail:wd-wangdan@163.com。
基金资助:
国家自然科学基金资助(51404125)

Development and application of risk assessment model for prefabricated building construction

WANG Dan(), LIANG Jinghan^**()

School of Business Administration, Liaoning Technical University, Huludao Liaoning 125105, China

Received:2022-04-13 Revised:2022-08-12 Online:2022-10-28 Published:2023-04-28
Contact: LIANG Jinghan

摘要/Abstract

摘要：

为降低装配式建筑项目施工风险,基于事故分析等方法提炼指标,建立5个一级指标、26个二级指标的装配式建筑施工风险评价指标体系;引入变权理论和贴近度替换传统物元可拓方法中的常权赋权法和关联度算法,构建基于改进物元可拓的装配式建筑施工风险评价模型;应用该模型进行案例验证,得出案例工程施工风险等级为1级,属于低风险,并通过对比改进模型与传统物元可拓模型的评价结果,验证改进模型的有效性。结果表明:应用基于改进物元可拓方法构建的装配式建筑施工风险评价模型,可以在事故发生前有效评价项目风险状况,达到提高风险管理效益的目的。

关键词: 装配式建筑, 施工风险评价, 物元可拓模型, 变权理论, 贴近度

Abstract:

In order to reduce the construction risks of prefabricated building projects, indexes were refined based on accident analysis and other methods, and the construction risk evaluation index system of prefabricated buildings with 5 primary indexes and 26 secondary ones was established. Then, the contingency theory and nearness degree were introduced to replace constant weight assignment method and correlation degree algorithm in traditional matter element extension method, and the construction risk assessment model of prefabricated buildings based on the improved matter element extension was constructed. Finally, the model was applied to validate the case whose construction risk level was obtained to be 1, namely low risk, and effectiveness of the model was verified by comparing its assessment results with those of the traditional one. The results show that the assessment model based on the improved matter element extension method can be applied to effectively evaluate the project risk status before the occurrence of accidents and achieve the purpose of improving risk management benefits.

Key words: prefabricated building, construction risk assessment, matter element extension model, contingency theory, nearness degree

王丹, 梁靖涵. 装配式建筑施工风险评价模型构建及应用[J]. 中国安全科学学报, 2022, 32(10): 69-75.

WANG Dan, LIANG Jinghan. Development and application of risk assessment model for prefabricated building construction[J]. China Safety Science Journal, 2022, 32(10): 69-75.

图/表 7

表1

表2

图1

图2

表3

图3

图4

参考文献 17

[1]	LI Hongxian, MOHAMED A H, LEI Zhen, et al. Risk identification and assessment of modular construction utilizing fuzzy analytic hierarchy process (AHP) and simulation[J]. NRC Research Press, 2013, 40(12):1184-1195.
[2]	CLYDE L Z, GEOFFREY S Q, XU Xiaoxiao, et al. Schedule risk modeling in prefabrication housing production[J]. Journal of Cleaner Production, 2017, 153(1):692-706. doi: 10.1016/j.jclepro.2016.11.028
[3]	MUHAMMAD S I, MADHAV P N, MARTIN S, et al. Current research trends and application areas of fuzzy and hybrid methods to the risk assessment of construction projects[J]. Advanced Engineering Informatics, 2017, 33:112-131. doi: 10.1016/j.aei.2017.06.001
[4]	申玲, 唐晔文, 牟月. 基于Cloud-BN的装配式住宅构件吊装安全评价[J]. 中国安全科学学报, 2019, 29(10):147-153. doi: 10.16265/j.cnki.issn1003-3033.2019.10.023
	SHEN Ling, TANG Yewen, MOU Yue. Safety assessment of component hoisting for prefabricated residence based on Cloud-BN model[J]. China Safety Science Journal, 2019, 29(10):147-153. doi: 10.16265/j.cnki.issn1003-3033.2019.10.023
[5]	段永辉, 周诗雨, 郭一斌, 等. 基于SEM的装配式建筑施工安全风险及策略[J]. 土木工程与管理学报, 2020, 37(2):70-75.
	DUAN Yonghui, ZHOU Shiyu, GUO Yibin, et al. Safety risk and strategy of prefabricated building construction based on SEM[J]. Journal of Civil Engineering and Management, 2020, 37(2):70-75.
[6]	黄桂林, 胡明路. 基于可拓学理论的装配式住宅施工过程安全风险评价研究[J]. 工业安全与环保, 2017, 43(2):33-38.
	HUANG Guilin, HU Minglu. Research on safety risk assessment in prefabricated residential construction process based on extension theory[J]. Industrial Safety and Environmental Protection, 2017, 43(2):33-38.
[7]	黄歌, 倪燕翎, 蒋丽. 基于熵权物元法的装配式建筑施工安全风险评价研究[J]. 安全, 2019, 40(11):18-24.
	HUANG Ge, Ni Yanling, JIANG Li. Research on assessment of safety risk of fabricated building construction based on entropy weight matter-element method[J]. Safety & Security, 2019, 40(11):18-24.
[8]	IBRAHIM Y W, GEOFFREY G Q, ROBERT O K, et al. Modelling the critical risk factors for modular integrated construction projects[EB/OL].(2020-05-13). https:ira.lib.polyu.edu.hk/handle/10397/89193.
[9]	IRFAN Z, IBRAHIM Y W, GEOFFREY G Q, et al. A fuzzy synthetic evaluation analysis of time overrun risk factors in highway projects of terrorism-affected countries: the case of Pakistan[J]. International Journal of Construction Management, 2022, 22(4):732-750. doi: 10.1080/15623599.2019.1647634
[10]	ROBERT O K, ALBERT P C, ERNEST E A. A fuzzy synthetic evaluation analysis of operational management critical success factors for public-private partnership infrastructure projects[J]. Benchmarking: An International Journal, 2017, 24(7):2092-2112. doi: 10.1108/BIJ-07-2016-0111
[11]	李英攀, 刘名强, 王芳, 等. 装配式建筑项目安全绩效云模型评价方法[J]. 中国安全科学学报, 2017, 27(6):115-120. doi: 10.16265/j.cnki.issn1003-3033.2017.06.020
	LI Yingpan, LIU Mingqiang, WANG Fang, et al. Safety performance assessment of fabricated building project based on cloud model[J]. China Safety Science Journal, 2017, 27(6):115-120. doi: 10.16265/j.cnki.issn1003-3033.2017.06.020
[12]	江婉舒, 周立志, 周小春. 基于熵权法的安徽省湿地重要性评估[J]. 长江流域资源与环境, 2021, 30(5):1164-1174.
	JIANG Wanshu, ZHOU Lizhi, ZHOU Xiaochun. Assessment of wetlands importance in Anhui province based on entropy weight method[J]. Resources and Environment in the Yangtze Basin, 2021, 30(5):1164-1174.
[13]	汪培庄. 模糊数学简介(Ⅰ)[J]. 数学的实践与认识, 1980, 10(2):45-59.
	WANG Peizhuang. A brief introduction of fuzzy mathematics (Ⅰ)[J]. Mathematics in Practice and Theory, 1980, 10(2):45-59.
[14]	刘文奇. 一般变权原理与多目标决策[J]. 系统工程理论与实践, 2000, 20(3):1-11. doi: 10.12011/1000-6788(2000)3-1
	LIU Wenqi. The ordinary variable weight principle and multiobjective decision-making[J]. Systems Engineering Theory and Practice, 2000, 20(3): 1-11.
[15]	刘文奇. 均衡函数及其在变权综合中的应用[J]. 系统工程理论与实践, 1997, 17(4):59-65. doi: 10.12011/1000-6788(1997)4-59
	LIU Wenqi. Balanced function and its application for variable weight synthesizing[J]. Systems Engineering Theory and Practice, 1997, 17(4): 59-65.
[16]	张晓平. 基于贴近度的模糊综合评判结果的集化[J]. 山东大学学报:理学版, 2004, 39(2):25-29.
	ZHANG Xiaoping. The definition of product about fuzzy comprehensive evaluation methods based on closeness[J]. Journal of Shandong University: Science Edition, 2004, 39(2): 25-29.
[17]	赵辉, 屈微璐, 邱玮婷, 等. 基于组合赋权法与可拓物元的海绵城市 PPP项目运作方式选择研究[J]. 科技管理研究, 2019, 39(6):200-206.
	ZHAO Hui, QU Weilu, QIU Weiting, et al. Study on the selection of PPP operation mode in sponge city based on combined weights method and extension matter element model[J]. Science and Technology Management Research, 2019, 39(6): 200-206.

KMO 取样适切性量数		0.768
巴特利特球形度检验	近似卡方	2 545.316
	自由度	1 176
	显著性	<0.001

评价指标	常权权重	评价指标	常权权重
A₁	0.033 0	B₈	0.019 3
A₂	0.108 3	B₉	0.018 0
A₃	0.040 8	C₁	0.051 0
A₄	0.023 0	C₂	0.037 7
A₅	0.099 5	C₃	0.062 7
A₆	0.025 7	C₄	0.044 1
B₁	0.023 6	C₅	0.050 2
B₂	0.024 4	D₁	0.018 0
B₃	0.018 6	D₂	0.022 8
B₄	0.014 0	D₃	0.011 3
B₅	0.024 7	D₄	0.014 7
B₆	0.016 6	E₁	0.132 0
B₇	0.016 3	E₂	0.049 8
