基于气体核密度的采空区煤自燃危险区域划分

doi:10.16265/j.cnki.issn1003-3033.2025.12.1445

摘要/Abstract

摘要：

为预防采空区煤自燃灾害,精准划分采空区煤自燃危险区域,通过统计分析现场采空区CO和O₂体积分数,得到气体体积分数随采空区长度的变化特征,确定煤自燃预警临界值范围,并提出基于气体体积分数核密度的采空区煤自燃危险区域划分方法。结果表明:采空区O₂体积分数符合线性变化且具有阶段性,拐点前的变化速率小于拐点后的变化速率;CO体积分数符合二次多项式变化特征;CO和O₂体积分数的核密度随着采空区长度的增加而降低,其最高核密度分布范围分别为0~10 m和0~30 m;拐点前O₂体积分数更加稳定,拐点后O₂体积分数波动性更大,拐点前后O₂体积分数的上、下可接受区间平均值分别为3.3%和6.3%;通过核密度划分煤自燃危险区域的CO和O₂体积分数临界值为0.009%和15.1%,将采空区划分为安全、潜在危险和危险3个危险等级4个象限。

关键词: 煤自燃, 采空区, 危险区域, 核密度, 统计学特征

Abstract:

To prevent coal spontaneous combustion disasters in the gob area and precisely delineate hazardous zones, the variation patterns of CO and O₂ volume fractions along the gob length were statistically analyzed based on field measurements. Critical warning threshold ranges for spontaneous combustion were established and a gob hazard zoning method based on gas volume fraction kernel density was proposed. The results demonstrate that O₂ volume fraction exhibits a linear variation with distinct stages, and the variation rate before the inflection point is lower than that after the point. The CO volume fraction follows a quadratic polynomial variation. The kernel densities of both CO and O₂ volume fractions decrease with increasing gob length. Their highest kernel density distributions occur within 0-10m and 0-30m, respectively. O₂ volume fraction is more stable before the inflection point but exhibits greater fluctuation afterward. The average upper and lower acceptable limits for O₂ volume fraction before and after the inflection point are 3.3% and 6.3%, respectively. The critical CO and O₂ volume fraction values for hazard zoning based on kernel density are 0.009% and 15.1%, which divides the gob area into four quadrants and three risk levels (safe, potentially hazardous, and hazardous).

Key words: coal spontaneous combustion, gob hazardous zone, coal fire early warning, kernel density, statistical characteristics

中图分类号:

X936

郭庆, 任万兴, 王圣程, 汪皓. 基于气体核密度的采空区煤自燃危险区域划分[J]. 中国安全科学学报, 2025, 35(12): 96-102.

GUO Qing, REN Wanxing, WANG Shengcheng, WANG Hao. Division of spontaneous combustion risk zones in coal mine gob areas using gas kernel density distribution[J]. China Safety Science Journal, 2025, 35(12): 96-102.

图/表 11

图1

图2

图3

图4

图5

图6

表1

图7

图8

表2

表3

参考文献 20

[1]	ZHU Hongqing, WANG Jiashuo, LI Rui, et al. Experimental and quantum chemical study of synergistic inhibitor based on physicochemical interaction in the prevention of coal spontaneous combustion[J]. Fuel, 2025,392: DOI: 10.1016/j.fuel.2025.134839.
[2]	肖旸, 张二川, 尹岚, 等. 地下煤火灾害机理及热动力演化与热能利用研究进展[J]. 煤矿安全, 2024, 55(11):1-18.
	XIAO Yang, ZHANG Erchuan, YIN Lan, et al. Research progress of underground coal fire disaster mechanism, thermodynamic evolution and thermal energy utilization[J]. Safety in Coal Mines, 2024, 55(11): 1-18.
[3]	张巨峰, 施式亮, 鲁义, 等. 矿井瓦斯与煤自燃共生灾害:耦合关系、致灾机制、防控技术[J]. 中国安全科学学报, 2020, 30(10):149-155. doi: 10.16265/j.cnki.issn 1003-3033.2020.10.021
	ZHANG Jufeng, SHI Shiliang, LU Yi, et al. Symbiotic disasters of mine gas and coal spontaneous combustion: coupling relationship, disaster mechanism, prevention and control technology[J]. China Safety Science Journal, 2020, 30(10): 149-155. doi: 10.16265/j.cnki.issn 1003-3033.2020.10.021
[4]	张家林, 杨帆, 张望, 等. 深部资源开采创新成效分析与思考[J]. 采矿与安全工程学报, 2024, 41(3):450-461.
	ZHANG Jialin, YANG Fan, ZHANG Wang, et al. Innovation effectiveness analysis and technology management reflection of deep resource exploitation[J]. Journal of Mining & Safety Engineering, 2024, 41(3): 450-461.
[5]	董宪伟, 崔静, 董轩萌, 等. 不同氧体积分数影响预氧化煤自燃特性研究[J]. 中国安全生产科学技术, 2025, 21(7):62-69.
	DONG Xianwei, CUI Jing, DONG Xuanmeng, et al. Effect of different oxygen volume fractions on spontaneous combustion characteristics of pre-oxidized coal[J]. Journal of Safety Science and Technology, 2025, 21(7): 62-69.
[6]	信亚男. 高抽巷抽采条件下采空区瓦斯与煤自燃耦合灾害的研究[D]. 徐州: 中国矿业大学, 2019.
	XIN Ya'nan. Study on coupling disasters of gas and coal spontaneous combustion in goaf under the condition of high drainage roadway[D]. Xuzhou: China University of Mining and Technology, 2019.
[7]	YAN Qingqiong, LU Yi, WANG Qiao, et al. Research progress and development trend of coal spontaneous combustion prevention technology[J]. Combustion Science and Technology, 2025, 197: DOI: 10.1080/00102202.2024.2331752.
[8]	郭军, 刘华, 金彦, 等. 地下煤自燃隐蔽火源探测方法综述及新技术展望[J]. 中国安全科学学报, 2022, 32(8):111-119. doi: 10.16265/j.cnki.issn1003-3033.2022.08.0296
	GUO Jun, LIU Hua, JIN Yan, et al. Summary of underground hidden coal spontaneous combustion fire source detection methods and prospect of new technologies[J]. China Safety Science Journal, 2022, 32(8): 111-119. doi: 10.16265/j.cnki.issn1003-3033.2022.08.0296
[9]	王德明. 煤矿热动力灾害及特性[J]. 煤炭学报, 2018, 43(1):137-142.
	WANG Deming. Thermodynamic disaster in coal mine and its characteristics[J]. Journal of China Coal Society, 2018, 43(1): 137-142.
[10]	秦波涛, 仲晓星, 王德明, 等. 煤自燃过程特性及防治技术研究进展[J]. 煤炭科学技术, 2021, 49(1):66-99.
	QIN Botao, ZHONG Xiaoxing, WANG Deming, et al. Research progress of coal spontaneous combustion process characteristics and prevention technology[J]. Coal Science and Technology, 2021, 49(1): 66-99.
[11]	任万兴, 郭庆, 石晶泰, 等. 基于标志气体统计学特征的煤自燃预警指标构建[J]. 煤炭学报, 2021, 46(6):1747-1758.
	REN Wanxing, GUO Qing, SHI Jingtai, et al. Construction of early warning indicators for coal spontaneous combustion based on statistical characteristics of index gases[J]. Journal of China Coal Society, 2021, 46(6): 1747-1758.
[12]	LEI Changkui, DENG Jun, CAO Kai, et al. A comparison of random forest and support vector machine approaches to predict coal spontaneous combustion in gob[J]. Fuel, 2018: DOI: 10.1016/j.fuel.2018.11.006.
[13]	邓军, 李青蔚, 肖旸, 等. 原煤和氧化煤的低温氧化特性[J]. 西安科技大学学报, 2018, 38(1):1-7.
	DENG Jun, LI Qingwei, XIAO Yang, et al. Characteristics of low-temperature oxidation of raw and oxidized coals[J]. Journal of Xi'an University of Science and Technology, 2018, 38(1): 1-7.
[14]	LIANG Yuntao, YANG Yalan, GUO Sida, et al. Combustion mechanism and control approaches of underground coal fires: a review[J]. International Journal of Coal Science & Technology, 2023, 10: DOI: 10.1007/S40789-023-00581-W.
[15]	GUO Qing, REN Wanxing, LU Wei. New classification method of coal spontaneous combustion three zones in the goaf based on non-parametric kernel density estimation[J]. Environmental Science and Pollution Research, 2023, 30: DOI: 10.1007/S11356-022-22528-5.
[16]	李增华, 苗国栋. 煤自燃大分子量气态产物生成规律研究[J]. 中国矿业大学学报, 2023, 52(6):1119-1128.
	LI Zenghua, MIAO Guodong. Study of the emission law of higher-molecular-weight gases during coal spontaneous combustion[J]. Journal of China University of Mining & Technology, 2023, 52(6): 1119-1128.
[17]	李金虎, 黄珏洁, 陆伟, 等. 煤中高活性含碳固体自由基与煤自燃反应性的相关关系[J]. 煤炭科学技术, 2024, 52(12):127-142.
	LI Jinhu, HUANG Juejie, LU Wei, et al. Correlation between highly active carbon-containing solid free radicals and spontaneous combustion reactivity of coal[J]. Coal Science and Technology, 2024, 52(12): 127-142.
[18]	梁运涛, 王伟, 王刚, 等. 《煤矿防灭火细则》编制原则及要点解读[J]. 煤矿安全, 2022, 53(5):230-235.
	LIANG Yuntao, WANG Wei, WANG Gang, et al. Compilation principle and key points interpretation of Coal Mine Fire Prevention and Control Rules[J]. Safety in Coal Mines, 2022, 53(5): 230-235.
[19]	曹凯, 杨海宇, 李长红, 等. 基于最适带宽的核密度估计源搜索方法[J]. 计算机仿真, 2024, 41(3):441-447.
	CAO Kai, YANG Haiyu, LI Changhong, et al. Source search method for kernel density estimation based on optimal bandwidth[J]. Computer Simulation, 2024, 41(03): 441-447.
[20]	牛文铁, 才福友, 付景静. 基于自适应带宽核密度估计的载荷外推方法研究[J]. 农业机械学报, 2021, 52(1):375-384.
	NIU Wentie, CAI Fuyou, FU Jingjing. Load extrapolation method based on adaptive bandwidth kernel density estimation[J]. Transactions of the Chinese Society for Agricultural Machinery, 2021, 52(1): 375-384.

支架	变化方程	可接受区间/%
30号	y=18.96-0.111 5x,x<30	$L{\|}_{{l}_{1}}^{{l}_{2}}$=3.1
30号	y=23.65-0.245 1x,x>30	$L{\|}_{l{\text{'}}_{1}}^{l{\text{'}}_{2}}$=5.6
45号	y=19.18-0.151 8x,x<30	$L{\|}_{{l}_{1}}^{{l}_{2}}$=5.8
45号	y=20.73-0.195 4x,x>30	$L{\|}_{l{\text{'}}_{1}}^{l{\text{'}}_{2}}$=6.4
60号	y=18.91-0.116 5x,x<30	$L{\|}_{{l}_{1}}^{{l}_{2}}$=3.5
60号	y=20.27-0.178 8x,x>30	$L{\|}_{l{\text{'}}_{1}}^{l{\text{'}}_{2}}$=6.9
75号	y=18.96-0.138 7x,x<30	$L{\|}_{{l}_{1}}^{{l}_{2}}$=3.1
75号	y=16.81-0.106 1x,x>30	$L{\|}_{l{\text{'}}_{1}}^{l{\text{'}}_{2}}$=6.1

支架编号	O₂体积分数指标对应分界点/m
支架编号	15%	5%
30	35.5	76.1
45	27.5	80.5
60	33.6	85.4
75	28.6	111.3
