光纤传感器在锂离子电池安全监测中的应用与挑战*

doi:10.16265/j.cnki.issn1003-3033.2026.03.0239

中国安全科学学报 ›› 2026, Vol. 36 ›› Issue (3): 113-120.doi: 10.16265/j.cnki.issn1003-3033.2026.03.0239

光纤传感器在锂离子电池安全监测中的应用与挑战^*

付举¹^,²^,³(), 史家吉¹^,²^,³, 马星阳¹^,²^,³, 谢雯娜¹^,²^,³, 谢松¹^,²^,³^,^**()

¹ 中国民用航空飞行学院民航安全与工程学院, 四川广汉 618307
² 民机火灾科学与安全工程四川省重点实验室, 四川广汉 618307
³ 四川省全电通航飞行器关键技术工程研究中心, 四川广汉 618307

收稿日期:2025-10-23 修回日期:2025-12-29 出版日期:2026-03-31
通信作者:
^** 谢松(1986—),男,四川自贡人,博士,教授,主要从事锂离子电池的热安全监测及预警研究。E-mail:xiesongam@163.com。
作者简介:
付举 (1990—),女,四川成都人,博士,副教授,主要从事锂离子电池关键材料研发、电池监测及预警等方面的研究。E-mail:fj2020@cafuc.edu.cn。
基金资助:
国家重点研发计划项目(2024YFC3014400); 国家自然科学基金资助(22379162); 民航安全能力建设项目(MHAQ2024035); 四川省科技计划项目(2025YFHZ0037)

Applications and challenges of fiber optic sensors in lithium-ion battery safety monitoring

FU Ju¹^,²^,³(), SHI Jiaji¹^,²^,³, MA Xingyang¹^,²^,³, XIE Wenna¹^,²^,³, XIE Song¹^,²^,³^,^**()

¹ College of Civil Aviation Safety Engineering, Civil Aviation Flight University of China, Guanghan Sichuan 618307, China
² Civil Aircraft Fire Science and Safety Engineering Key Laboratory of Sichuan Province , Guanghan Sichuan 618307, China
³ Sichuan Key Technology Engineering Research Center for All-electric Navigable Aircraft, Guanghan Sichuan 618307, China

Received:2025-10-23 Revised:2025-12-29 Published:2026-03-31

摘要/Abstract

摘要：

为解决现有电池管理系统难以获取锂离子电池内部温度梯度、结构应变及产气等关键信号,导致安全监测与热失控早期预警能力不足的问题,系统综述光纤传感器在锂离子电池安全监测中的应用与挑战。首先,梳理电池安全监测的关键参数与需求,明确温度、应变、气体及电解液状态等可表征失效演化的监测对象;其次,归纳对比光纤布拉格光栅(FBG)、倾斜光纤光栅(TFBG)、光纤倏逝波(FOEW)及分布式光纤传感(DOFS)等典型技术的原理与性能特征;然后,按应用场景总结上述技术在温度/应变原位监测、界面折射率与老化评估、特征产气检测及热失控风险识别中的研究进展;最后,提炼目前在集成兼容性、多参数交叉敏感与信号解耦、长期稳定性与标定及成本等方面的共性障碍,并提出相应发展方向。研究结果表明:光纤传感技术可监测锂离子电池温度的多点位、毫秒级、±0.1 ℃精度、±0.1 με级的应变面、0.12%精度实时原位在线的产气、10^-3级的原位电解液折射率。通过多参数、原位、实时监测的数据导入和处理,可提升对锂电池热失控早期预警能力。

关键词: 光纤传感器, 锂离子电池, 安全监测, 热失控, 原位监测

Abstract:

To address the inability of existing battery management systems in acquiring internal temperature gradients, structural strain, and gas generation signals in lithium-ion cells, which result in inadequate safety monitoring and early-warning capability against thermal runaway, a systematic review of fiber optic sensors for lithium-ion battery safety monitoring and the challenges they face was provided. First, key safety-related monitoring parameters, including temperature, strain, gas evolution, and electrolyte state, were identified. Second, the principles and characteristics of representative sensing technologies, such as Fiber Bragg Gratings(FBG), Tilted Fiber Bragg Gratings(TFBG), Fiber Optic Evanescent Wave Sensing(FOEW), and Distributed Optic Fiber Sensing(DOFS), were reviewed. Third, the research progress in in-situ temperature and strain monitoring, electrolyte state evaluation, gas detection, and thermal runaway risk identification for each technology was summarized. Finally, major challenges in practical application, including integration compatibility, multi-parameter cross-sensitivity, long-term stability, and cost, were discussed. The survey reveals that fiber-optic sensing enables multi-point, millisecond-scale temperature monitoring with ±0.1 ℃ accuracy, strain mapping at ±0.1 με resolution, in-situ gas detection at 0.12% precision, and electrolyte refractive-index tracking down to 10^-3. Feeding these multi-parameter, in-situ, real-time data into advanced algorithms can significantly enhance early-warning capability for lithium-ion battery thermal runaway.

Key words: fiber optic sensors, lithium-ion batteries, safety monitoring, thermal runaway, in-situ monitoring

中图分类号:

X946

付举, 史家吉, 马星阳, 谢雯娜, 谢松. 光纤传感器在锂离子电池安全监测中的应用与挑战^*[J]. 中国安全科学学报, 2026, 36(3): 113-120.

FU Ju, SHI Jiaji, MA Xingyang, XIE Wenna, XIE Song. Applications and challenges of fiber optic sensors in lithium-ion battery safety monitoring[J]. China Safety Science Journal, 2026, 36(3): 113-120.

图/表 3

表1

表2

表3

参考文献 48

[1]	王志, 殷波, 史波波, 等. 纵向通风下锂离子电池热失控气体扩散特性[J]. 中国安全科学学报, 2024, 34(9): 138-144. doi: 10.16265/j.cnki.issn1003-3033.2024.09.1816
	WANG Zhi, YIN Bo, SHI Bobo, et al. Diffusion characteristics of thermal runaway gas from lithium-ion batteries under longitudinal ventilation[J]. China Safety Science Journal, 2024, 34(9): 138-144. doi: 10.16265/j.cnki.issn1003-3033.2024.09.1816
[2]	许彬, 李志远, 徐伯乐, 等. 基于光纤光栅的锂电池安全监测应用效果研究[J]. 武汉理工大学学报:信息与管理工程版, 2022, 44(5):745-751.
	XU Bin, LI Zhiyuan, XU Bole, et al. Research on application effect of lithium-ion battery safety monitoring based on fiber bragg grating[J]. Journal of Wuhan University of Technology:Information & Management Engineering, 2022, 44(5):745-751.
[3]	FLEMING J, AMIETSZAJEW T, MCTURK E, et al. Development and evaluation of in situ instrumentation for cylindrical Li-ion cells using fibre optic sensors[J]. HardwareX, 2018, 3: 100-109. doi: 10.1016/j.ohx.2018.04.001
[4]	韩冲, 李继繁, 宋文华. 光纤光栅温度监测系统在锂电池储能站安全预警中的应用研究[J]. 南开大学学报:自然科学版, 2020, 53(5): 21-25.
	HAN Chong, LI Jifan, SONG Wenhua. Research on application of fiber grating temperature monitoring system in safety early warning of lithium battery energy storage station[J]. Journal of Nankai University: Natural Science, 2020, 53(5): 21-25.
[5]	YU Yifei, VINCENT T, SANSOM J, et al. Distributed internal thermal monitoring of lithium ion batteries with fibre sensors[J]. Journal of Energy Storage, 2022:DOI: 10.1016/j.est.2022.104291.
[6]	HEDMAN J, NILEBO D, LARSSON L E, et al. Fibre optic sensor for characterisation of lithium-ion batteries[J]. ChemSusChem, 2020, 13(21):5 731-5 739. doi: 10.1002/cssc.v13.21
[7]	WAHL M S, SPITTHOFF L, MURI H I, et al. The importance of optical fibres for internal temperature sensing in lithium-ion batteries during operation[J]. Energies, 2021, 14:DOI: 10.3390/en14123617.
[8]	陆豪宇, 沈文锋, 吕大伍, 等. 锂电池热失控安全防护研究进展[J]. 材料导报, 2025, 39(14): 5-23.
	LU Haoyu, SHEN Wenfeng, LYU Dawu, et al. Research progress on safety strategies for thermal runaway in lithium ion batteries[J]. Materials Reports, 2025, 39(14): 5-23.
[9]	LI Dezhi, WANG Licheng, DUAN Chongxiong, et al. Temperature prediction of lithium-ion batteries based on electrochemical impedance spectrum: a review[J]. International Journal of Energy Research, 2022, 46(8): 10 372-10 388. doi: 10.1002/er.v46.8
[10]	KAFADAROVA N, SOTIROV S, HERBST F, et al. A system for determining the surface temperature of cylindrical lithium-ion batteries using a thermal imaging camera[J]. Batteries, 2023, 9(10):DOI:10.3390/batteries9100519.
[11]	GULSOY B, VINCENT T A, SANSOM J E H, et al. In-situ temperature monitoring of a lithium-ion battery using an embedded thermocouple for smart battery applications[J]. Journal of Energy Storage, 2022:DOI: 10.1016/j.est.2022.105260.
[12]	SUN Baichuan, XU Gaobin, XU Ji, et al. A strain-resistant flexible thermistor sensor array based on CNT/MXene hybrid materials for lithium-ion battery and human temperature monitoring[J]. Sensors and Actuators A: Physical, 2024, 368:DOI: 10.1016/j.sna.2024.115059.
[13]	YU Yifei, VINCENT T, SANSOM J, et al. Distributed internal thermal monitoring of lithium ion batteries with fibre sensors[J]. Journal of Energy Storage, 2022, 50:DOI: 10.1016/j.est.2022.104291.
[14]	REN Dongsheng, XIE Leqiong, WANG Li, et al. A practical approach to predict volume deformation of lithium-ion batteries from crystal structure changes of electrode materials[J]. International Journal of Energy Research, 2021, 45(5):7 732-7 740. doi: 10.1002/er.v45.5
[15]	KRAUSE T, NUSKO D, BAUERMANN P L, et al. Methods for quantifying expansion in lithium-ion battery cells resulting from cycling: a review[J]. Energies, 2024, 17(7): DOI: 10.3390/en17071566.
[16]	SOMMER L W, RAGHAVAN A, KIESEL P, et al. Embedded fiber optic sensing for accurate state estimation in advanced battery management systems[J]. MRS Online Proceedings Library, 2014, 1681: 1-7.
[17]	NASCIMENTO M, NOVAIS S, DING M S, et al. Internal strain and temperature discrimination with optical fiber hybrid sensors in Li-ion batteries[J]. Journal of Power Sources, 2019, 410: 1-9.
[18]	HENDRICKS C, SOOD B, PECHT M. Lithium-ion battery strain gauge monitoring and depth of discharge estimation[J]. Journal of Electrochemical Energy Conversion and Storage, 2023, 20(1): DOI:10.1115/1.4054340.
[19]	NOVAIS S, NASCIMENTO M, GRANDE L, et al. Internal and external temperature monitoring of a Li-ion battery with fiber Bragg grating sensors[J]. Sensors, 2016, 16 (9): DOI: 10.3390/s16091394.
[20]	NASCIMENTO M, NOVAIS S, LEITÃO C, et al. Lithium batteries temperature and strain fiber monitoring[C]. 24^th International Conference on Optical Fibre Sensors. SPIE, 2015:1 060-1 063.
[21]	KOCSIS S S, SZABÓ M, SZALAI S, et al. Deformation analysis of different lithium battery designs using the dic technique[J]. Energies, 2024, 17(2): DOI:10.3390/en17020323.
[22]	SOMMER L W, KIESEL P, GANGULI A, et al. Fast and slow ion diffusion processes in lithium ion pouch cells during cycling observed with fiber optic strain sensors[J]. Journal of Power Sources, 2015, 296: 46-52. doi: 10.1016/j.jpowsour.2015.07.025
[23]	LI Hanyang, WEI Feng, LI Yanzeng, et al. Optical fiber sensor based on upconversion nanoparticles for internal temperature monitoring of Li-ion batteries[J]. Journal of Materials Chemistry C, 2021, 9(41): 14 757-14 765. doi: 10.1039/D1TC03701C
[24]	DEY A. Semiconductor metal oxide gas sensors: a review[J]. Materials Science and Engineering: B, 2018, 229: 206-217. doi: 10.1016/j.mseb.2017.12.036
[25]	ZHANG Qingsong, LIU Tiantian, HAO Chaolong, et al. In situ Raman investigation on gas components and explosion risk of thermal runaway emission from lithium-ion battery[J]. Journal of Energy Storage, 2022, 56:DOI: 10.1016/j.est.2022.105905.
[26]	GACHOT G, RIBIÈRE P, MATHIRON D, et al. Gas chromatography/mass spectrometry as a suitable tool for the Li-ion battery electrolyte degradation mechanisms study[J]. Analytical Chemistry, 2011, 83(2): 478-485. doi: 10.1021/ac101948u pmid: 21155595
[27]	KOCH S, FILL A, BIRKE K P. Comprehensive gas analysis on large scale automotive lithium-ion cells in thermal runaway[J]. Journal of Power Sources, 2018, 398: 106-112. doi: 10.1016/j.jpowsour.2018.07.051
[28]	THOMAS A, RONALD N. A review: application and implementation of optic fibre sensors for gas detection[J]. Sensors, 2021, 21 (20): DOI: 10.3390/s21206755.
[29]	ZHANG Jian, QIN Ziyu, ZENG Dawen, et al. Metal-oxide-semiconductor based gas sensors: screening, preparation, and integration[J]. Physical Chemistry Chemical Physics, 2017, 19(9):6 313-6 329. doi: 10.1039/C6CP07799D
[30]	GOVARDHAN K, GRACE A N. Metal/metal oxide doped semiconductor based metal oxide gas sensors:a review[J]. Sensor Letters, 2016, 14(8): 741-750. doi: 10.1166/sl.2016.3710
[31]	ONG R C Y, MARRIOTT P J. A review of basic concepts in comprehensive two-dimensional gas chromatography[J]. Journal of Chromatographic Science, 2002, 40(5): 276-291. pmid: 12049157
[32]	CHEN Xuanren, LIN Gan, GUO Xin. Optical fiber-based gas sensing for early warning of thermal runaway in lithium-ion batteries[J]. Advanced Sensor Research, 2023, 2(12): DOI: 10.1002/adsr.202300055.
[33]	KUMAR A, PRAJESH R. The potential of acoustic wave devices for gas sensing applications[J]. Sensors and Actuators A: Physical, 2022, 339:DOI: 10.1016/j.sna.2022.113498.
[34]	WANG Qiansong, JIANG Lihua, YU Yan, et al. Progress of enhancing the safety of lithium ion battery from the electrolyte aspect[J]. Nano Energy, 2019, 55: 93-114. doi: 10.1016/j.nanoen.2018.10.035
[35]	TERBORG L, WEBER S, BLASKE F, et al. Investigation of thermal aging and hydrolysis mechanisms in commercial lithium ion battery electrolyte[J]. Journal of Power Sources, 2013, 242: 832-837. doi: 10.1016/j.jpowsour.2013.05.125
[36]	XUE Xiaobin, HAN Xile, LI Wanjun, et al. Operando battery monitoring: lab-on-fiber electrochemical sensing technologies[J]. Laser & Photonics Reviews, 2024, 18 (9): DOI: 10.1002/lpor.202301298.
[37]	NEDJALKOV A, MEYER J, GRAFENSTEIN A, et al. Refractive index measurement of lithium ion battery electrolyte with etched surface cladding waveguide Bragg gratings and cell electrode state monitoring by optical strain sensors[J]. Batteries, 2019, 5(1): DOI: 10.3390/batteries5010030.
[38]	贺元骅, 赵逸明, 张俐恒, 等. 辐射对流散热下大尺寸三元锂电池热模型[J]. 中国安全科学学报, 2023, 33(6): 49-55. doi: 10.16265/j.cnki.issn1003-3033.2023.06.1941
	HE Yuanhua, ZHAO Yiming, ZHANG Liheng, et al. Research on thermal model of large format ternary lithium battery under radiation convection heat dissipation[J]. China Safety Science Journal, 2023, 33(6): 49-55. doi: 10.16265/j.cnki.issn1003-3033.2023.06.1941
[39]	冒燕, 童杏林, 卢世刚, 等. 植入式锂离子电池光纤布拉格光栅温度传感器[J]. 激光与光电子学进展, 2023, 60(17):169-175.
	MAO Yan, TONG Xinglin, LU Shigang, et al. Implantable fiber bragg grating temperature sensor inside lithium-ion battery[J]. Laser & Optoelectronics Progress, 2023, 60(17): 169-175.
[40]	HUANG Feixia, GU Bowen, WU Qiang, et al. Real-time monitoring of internal temperature of a lithium-ion battery using embedded fiber Bragg gratings[J]. Chinese Optics Letters, 2024, 22(9): DOI: 10.3788/COL202422.091202.
[41]	MEI Wenxin, LIU Zhi, WANG Chengdong. et al. Operando monitoring of thermal runaway in commercial lithium-ion cells via advanced lab-on-fiber technologies[J]. Nature Communications, 2023, 14(1): DOI: 10.1038/s41467-023-40995-3.
[42]	PENG Jun, ZHOU Xing, JIA Shuhai, et al. High precision strain monitoring for lithium ion batteries based on fiber Bragg grating sensors[J]. Journal of Power Sources, 2019, 433:DOI: 10.1016/j.jpowsour.2019.226692.
[43]	ZHANG Yi, XIAO Xiangpeng, CHEN Weilun, et al. In operando monitoring the stress evolution of silicon anode electrodes during battery operation via optical fiber sensors[J]. Small, 2024, 20 (29): DOI:10.1002/smll.202311299.
[44]	NASCIMENTO M, FERREIRA M S, PINTO J L. Simultaneous sensing of temperature and Bi-directional strain in a prismatic Li-ion battery[J]. Batteries, 2018, 4(2): DOI: 10.3390/batteries4020023.
[45]	HAN Xile, ZHONG Hai, LI Kaiwei, et al. Operando monitoring of dendrite formation in lithium metal batteries via ultrasensitive tilted fiber Bragg grating sensors[J]. Light: Science & Applications, 2024, 13(1):153-166.
[46]	HUANG Jiaqiang, HAN Xile, LIU Fu, et al. Monitoring battery electrolyte chemistry via in-operando tilted fiber Bragg grating sensors[J]. Energy & Environmental Science, 2021, 14(12):6 464-6 475.
[47]	GHANNOUM A R, NIEVA P. Graphite lithiation and capacity fade monitoring of lithium ion batteries using optical fibers[J]. Journal of Energy Storage, 2020, 28:DOI: 10.1016/j.est.2020.101233.
[48]	KIM K J, LU Ping, CULP J T, et al. Metal-organic framework thin film coated optical fiber sensors: a novel waveguide-based chemical sensing platform[J]. ACS Sensors, 2018, 3(2): 386-394. doi: 10.1021/acssensors.7b00808

技术类型	灵敏度	空间分辨率	多参数能力	成本	应用场景
FBG	高	点式/准分布式	有限	中	温度/应变监测
TFBG	很高	点式	强	较高	化学/折射率监测
FOEW	高	点式	中	中	气体/液体监测
DOFS	中	0.01 ~1 m	弱	高	温度场分布监测

监测技术	优点	缺点
应变计^[18]	成本低;有效性高;适应性强	容易受到热和电磁干扰
贴片式FBG^[19-20]	高灵敏度和高精度;轻量化和柔性设计	交叉敏感;难以了解内部电化学变化
数字图像法^[21]	非接触式测量;精度高;不受尺寸限制	响应低;装置复杂;不适合实时监控
嵌入式FBG^[22-23]	不受强电磁和腐蚀环境干扰;检测更灵敏准确	操作复杂;价格昂贵;交叉敏感

监测技术	优点	缺点
半导体传感器^[29-30]	成本低;集成化;多路复用能力	存在火花危险问题;灵敏度相对较低
气相色谱仪^[31]	高精度;可多气体同时检测	难应用现场中;成本高;样品需预处理
光纤气体传感器^[32]	实时远程监控;多路复用	响应时间较长;成本较高;需要校准
声波气体传感器^[33]	可以在室温下工作;设备小型化	分布式应用困难;对气体的选择性差
