基于CA的建筑工人不安全行为传染机制

doi:10.16265/j.cnki.issn1003-3033.2023.01.0183

摘要/Abstract

摘要：

为抑制建筑工人间不安全行为的传染,借鉴易感-暴露-感染-康复(SEIR)模型,引入行为跟随者、行为接触者、不安全行为传染者和安全行为者4类行为主体,描述建筑工人不安全行为传染过程;考虑到工人群体关系的复杂性,提出小世界网络上的元胞自动机(CA)传染模型,刻画不同行为主体行为状态转化规则;运用数值仿真方法,分析行为跟随方式、不安全行为传染者分布模式与抑制率对不安全行为传染的影响。结果表明:行为跟随者的不同跟随方式、不安全行为传染者的不同分布模式对不安全行为传染效果具有显著影响,抑制率与不安全行为传染效果负向相关,其中,综合跟随方式下的行为传染效果最为显著;小群体分散分布模式极大地扩大和强化不安全行为传染者的传染范围与能力;适度的抑制性措施能够有效抑制不安全行为传染。

关键词: 元胞自动机(CA), 建筑工人, 不安全行为, 行为传染, 传染网络

Abstract:

In order to restrain the contagion of unsafe behavior among construction workers, the susceptibility-exposure-infection-recovery (SEIR) model was used to describe the infection process of unsafe behavior among construction workers by introducing four types of behavior subjects : behavior followers, behavior contacts, unsafe behavior infectors and safety actors. Considering the complexity of workers' group relations, a CA contagion model in a small-world network was proposed to characterize the transformation rules of different actors. By using numerical simulation method, the influence of behavior following mode, distribution pattern of unsafe behavior infectors and inhibition rate on unsafe behavior infection was analyzed. The results show that the different follow-up modes of behavior followers and the different distribution modes of unsafe behavior infectors have a significant influence on the contagion performance of unsafe behavior. The inhibition rate is negatively correlated with the contagion effect of unsafe behavior. Among them, the behavioral contagion effect under the comprehensive follow-up mode performance is the most significant. The decentralized distribution pattern of small groups greatly expands and strengthens the scope and ability of the infectors of unsafe behaviors; moderate inhibitory measures can effectively inhibit the contagion of unsafe behavior.

Key words: cellular automata(CA), construction workers, unsafe behavior, behavioral contagion, contagion network

刘素霞, 唐帅帅. 基于CA的建筑工人不安全行为传染机制[J]. 中国安全科学学报, 2023, 33(1): 24-31.

LIU Suxia, TANG Shuaishuai. Research on contagion mechanism of unsafe behavior of construction workers based on CA[J]. China Safety Science Journal, 2023, 33(1): 24-31.

图/表 7

图1

图2

图3

表1

试验初始参数及其赋值规则

变量/ 参数	含义解释	取值	赋值规则
$S (0)$	初始时刻行为跟随者比例	0.95	文献[15]
$I (0)$	初始时刻不安全行为传染者比例	0.04	文献[15]
$R (0)$	初始时刻安全行为者比例	0.01	文献[15]
$g v (i, j)$	行为跟随者的从众倾向	0~1	正态分布
$p v (i, j)$	不安全行为传染者的传染能力	0~1	正态分布
$I v (i, j)$	传染率	0~1	正态分布
$R v (i, j)$	抑制率	0~1	正态分布

表1

图4

图5

图6

参考文献 29

[1]	住房和城乡建设部工程质量安全监管司. 建筑施工安全事故案例分析[M]. 北京: 中国建筑工业出版社, 2019: 8-58.
[2]	许正权, 张妮, 王华清, 等. 矿工不安全行为的网络传播性分析[J]. 科技进步与对策, 2014, 31(11): 54-56.
	XU Zhengquan, ZHANG Ni, WANG Huaqing, et al. Analysis of network transmission of miners' unsafe behavior[J]. Science & Technology Progress and Policy, 2014, 31(11): 54-56.
[3]	陈洋, 李爽, 张宇航, 等. 基于演化博弈的不安全行为的羊群效应研究[J]. 技术经济, 2020, 39(2): 144-155.
	CHEN Yang, LI Shuang, ZHANG Yuhang, et al. Research on herding effect in unsafe behavior based on evolutionary game[J]. Journal of Technology Economics, 2020, 39(2): 144-155.
[4]	JIANG Hui, WANG Jianping, HAN Yu, et al. Structural equation model analysis of factors in the spread of unsafe behavior among construction workers[J]. Information, 2018, 9(2): DOI: 10.3390/info9020039. doi: 10.3390/info9020039
[5]	GAO Yifan, GONZALEZ V A, YIU T W. Exploring the relationship between construction workers' personality traits and safety behavior[J]. Journal of Construction Engineering and Management, 2020, 146(3): DOI: 10.1061/(ASCE)CO.1943-7862.0001763. doi: 10.1061/(ASCE)CO.1943-7862
[6]	CHOI B, AHN S, LEE S H. Construction workers' group norms and personal standards regarding safety behavior: social identity theory perspective[J]. Journal of Management in Engineering, 2017, 33(4): DOI: 10.1061/(ASCE)ME.1943-5479.0000511. doi: 10.1061/(ASCE)ME.1943-5479
[7]	LIU Suxia, ZHOU Ying, CHENG Yao, et al. Multiple mediating effects in the relationship between employees' trust in organizational safety and safety participation behavior[J]. Safety Science, 2020, 125: DOI: 10.1016/j.ssci.2020.104611. doi: 10.1016/j.ssci.2020.104611
[8]	NI Guodong, ZHU Yuanyuan, ZHANG Ziyao, et al. Influencing mechanism of job satisfaction on safety behavior of new generation of construction workers based on Chinese context: the mediating roles of work engagement and safety knowledge sharing[J]. International Journal of Environmental Research and Public Health, 2020, 17(22): DOI: 10.3390/ijerph17228361. doi: 10.3390/ijerph17228361
[9]	ZHANG Peiyao, LI Nan, JIANG Zhongming, et al. An agent-based modeling approach for understanding the effect of worker-management interactions on construction workers' safety-related behaviors[J]. Automation in Construction, 2019, 97: 29-43. doi: 10.1016/j.autcon.2018.10.015
[10]	韩豫, 梅强, 周丹, 等. 群体封闭性视角下的建筑工人不安全行为传播特性[J]. 中国安全生产科学技术, 2016, 12(3): 187-192.
	HAN Yu, MEI Qiang, ZHOU Dan, et al. Propagation characteristics of unsafe behaviors for construction workers from the perspective of group closeness[J]. Journal of Safety Science and Technology, 2016, 12(3): 187-192.
[11]	刘林, 吴金南, 常志朋. 安全违规行为的人际传染效应研究[J]. 中国安全科学学报, 2021, 31(8): 22-29. doi: 10.16265/j.cnki.issn1003-3033.2021.08.004
	LIU Lin, WU Jinnan, CHANG Zhipeng. Study on interpersonal contagion effect of safety violation behaviors[J]. China Safety Science Journal, 2021, 31(8): 22-29. doi: 10.16265/j.cnki.issn1003-3033.2021.08.004
[12]	VEDADI A, WARKENTIN M. Can secure behaviors be contagious? a two-stage investigation of the influence of herd behavior on security decisions[J]. Journal of the Association for Information Systems, 2020, 21(2): 428-459.
[13]	周丹, 韩豫, 陆建飞. 建筑工人群体性调查与特性分析[J]. 建筑技术, 2016, 47(2): 182-185.
	ZHOU Dan, HAN Yu, LU Jianfei. Investigation and characteristics analysis on construction workers group[J]. Architecture Technology, 2016, 47(2): 182-185.
[14]	蔡秋晨, 董建军, 孙剑. 基于复杂网络的隧道工人群体特性分析研究[J]. 工业安全与环保, 2019, 45(8): 10-13.
	CAI Qiuchen, DONG Jianjun, SUN Jian. Analysis of tunnel workers' group characteristics based on complex network[J]. Industrial Safety and Environmental Protection, 2019, 45(8): 10-13.
[15]	唐玲玲. 建筑工人从众性不安全行为的传播及干预效应对比[D]. 泉州: 华侨大学, 2020.
	TANG Lingling. Comparison of the intervention effect and the spread of conformity unsafe behavior of construction workers[D]. Quanzhou: Huaqiao University, 2020.
[16]	张丽娟, 王福昌, 李振刚. 基于元胞自动机的病毒传播和系统仿真模型[J]. 系统仿真学报, 2021, 33(10): 2449-2459. doi: 10.16182/j.issn1004731x.joss.21-0131
	ZHANG Lijuan, WANG Fuchang, LI Zhengang. Virus propagation and system simulation based on cellular automata model[J]. Journal of System Simulation, 2021, 33(10): 2449-2459. doi: 10.16182/j.issn1004731x.joss.21-0131
[17]	张耀峰, 肖人彬. 基于元胞自动机的网络群体事件舆论同步的涌现机制[J]. 系统工程理论与实践, 2014, 34(10): 2600-2608. doi: 10.12011/1000-6788(2014)10-2600
	ZHANG Yaofeng, XIAO Renbin. Emergence mechanism of consensus synchronization in internet collective behavior based on cellular automata[J]. Systems Engineering-Theory & Practice, 2014, 34(10): 2600-2608.
[18]	苏加福, 杨涛, 张娜. 协同产品创新系统的知识传播模型及其仿真研究[J]. 科技管理研究, 2019, 39(15): 151-159.
	SU Jiafu, YANG Tao, ZHANG Na. Knowledge dissemination model and simulation of collaborative product innovation system[J]. Science and Technology Management Research, 2019, 39(15): 151-159.
[19]	谭欣欣, 戴钦武, 史鹏燕, 等. 基于元胞自动机的个体移动异质性传染病传播模型[J]. 大连理工大学学报, 2013, 53(6): 908-914.
	TAN Xinxin, DAI Qinwu, SHI Pengyan, et al. CA-based epidemic propagation model with inhomogeneity and mobility[J]. Journal of Dalian University of Technology, 2013, 53(6): 908-914.
[20]	CENTOLA D, MACY M. Complex contagions and the weakness of long ties[J]. American Journal of Sociology, 2007, 113(3): 702-734. doi: 10.1086/521848
[21]	李雯晶, 蒋青云, 刘婷. 社会传染研究综述与展望:基于行为经济学视角[J]. 管理现代化, 2020, 40(4): 105-109.
	LI Wenjing, JIANG Qingyun, LIU Ting. Literature review and prospect on social contagion research: from the perspective of behavioral economics[J]. Modernization of Management, 2020, 40(4): 105-109.
[22]	XIONG Chaohua, LIANG Kongzheng, LUO HanBin, et al. Identification of safety-related opinion leaders among construction workers: evidence from scaffolders of metro construction in Wuhan, China[J]. International Journal of Environmental Research and Public Health, 2018, 15(10): DOI: 10.3390/ijerph15102176. doi: 10.3390/ijerph15102176
[23]	CHEN Zhijun, TAKEUCHI R, SHUM C. A Social information processing perspective of coworker influence on a focal employee[J]. Organization Science, 2013, 24(6): 1618-1639. doi: 10.1287/orsc.2013.0820
[24]	倪清清, 谢媛芳, 徐晟, 等. 建筑工人群体安全压力因子的构建与评价方法[J]. 土木工程与管理学报, 2020, 37(1): 146-152.
	NI Qingqing, XIE Yuanfang, XU Sheng, et al. Construction and evaluation method of group safety stress factor of construction workers[J]. Journal of Civil Engineering and Management, 2020, 37(1): 146-152.
[25]	MAN S S, CHAN A H S, WONG H M. Risk-taking behaviors of Hong Kong construction workers: a thematic study[J]. Safety Science, 2017, 98: 25-36. doi: 10.1016/j.ssci.2017.05.004
[26]	SALANCIK G R, PFEFFER J. A Social information processing approach to job attitudes and task design[J]. Administrative Science Quarterly, 1978, 23(2): 224-253. pmid: 10307892
[27]	陈敏, 徐鹏飞, 张钱, 等. 包工组织正规化影响因素研究[J]. 土木工程与管理学报, 2020, 37(6): 31-37.
	CHEN Min, XU Pengfei, ZHANG Qian, et al. Study on the influencing factors of the normalization of contract labor organization[J]. Journal of Civil Engineering and Management, 2020, 37(6): 31-37.
[28]	韩豫, 梅强, 刘素霞, 等. 建筑工人不安全行为的模仿与学习的调查与分析[J]. 中国安全生产科学技术, 2015, 11(6): 182-188.
	HAN Yu, MEI Qiang, LlU Suxia, et al. Investigation and analysis on imitation and learning of unsafe behaviors for construction workers[J]. China Safety Science Journal, 2015, 11(6): 182-188.
[29]	张明媛, 徐琴. 施工工人不安全行为传播模型与干预效果分析[J]. 中国安全科学学报, 2021, 31(12): 1-9. doi: 10.16265/j.cnki.issn 1003-3033.2021.12.001
	ZHANG Mingyuan, XU Qin. Analysis on propagation model and intervention effects of unsafe behaviors of construction workers[J]. China Safety Science Journal, 2021, 31(12): 1-9. doi: 10.16265/j.cnki.issn 1003-3033.2021.12.001
